HITACHI ZX70-3 EXCAVATOR TRAVEL REDUCTION GEAR

HITACHI ZX70-3 EXCAVATOR TRAVEL REDUCTION GEAR

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL DEVICE:
Pos. Part No Qty Parts name Comments
9272927 [1]   TRAVEL DEVICE I 9290866 (for assembly of machine)
-9290866 [1]   TRAVEL DEVICE (for transportation)
2 1034158 [1]   GEAR;RING
3 4663049 [2]   BRG.;BALL
4 4082631 [1]   SEAL;GROUP
5 4663251 [1]   RING
7 1033840 [1]   SPROCKET
8 J931635 [16]   BOLT
9 3111063 [4]   GEAR;PLANETARY
10 3109251 [1]   NUT
11 4663247 [1]   PLATE;THRUST
12 4663048 [2]   PLATE;THRUST 2.3mm
13 4676978 [4]   BRG.;NEEDLE
14 4663237 [4]   RING
17 4663250 [1]   PLATE;THRUST
19 4627913 [4]   BOLT;FLUSH
20 3109249 [1]   GEAR;SUN
21 4663219 [1]   RING;RETAINING
22 2054049 [1]   CARRIER
23 4663218 [1]   PLATE;THRUST 3.2mm
24 4663248 [3]   PLATE;THRUST 1.0mm
25 4663208 [3]   RING
26 4663214 [3]   BRG.;NEEDLE
27 3109436 [3]   GEAR;PLANETARY
29 927488 [3]   RING;RETAINING
30 4665626 [1]   PLATE;THRUST
31 3109437 [1]   SHAFT;PROP.
33 4468678 [1]   COVER
34 4468679 [1]   PIN
35 4407802 [1]   O-RING
36 4392320 [1]   RING
37 4245797 [3]   PLUG
39 M492564 [2]   SCREW;DRIVE
40 +++++++ [1]   NAME-PLAT
