HITACHI ZX70-3 EXCAVATOR SWING REDUCTION GEAR

HITACHI ZX70-3 EXCAVATOR SWING REDUCTION GEAR

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group SWING DEVICE:
Pos. Part No Qty Parts name Comments
9270522 [1]   SWING-DEVICE I 4684827 <for assembly of machine>
-4684827 [1]   SWING-DEVICE <for transportation>
0 2053919 [1]   HOUSING
1 2053920 [1]   SHAFT;PROP.
2 4662074 [1]   SPACER
3 4662075 [1]   PLATE
4 4662076 [1]   SEAL
5 4662105 [1]   BRG.;ROL.
6 4662106 [1]   SEAL;OIL
7 4662107 [1]   BRG.;ROL.
8 4662111 [1]   WASHER;ADJUST.
9 4662112 [1]   WASHER;ADJUST.
10 4662113 [1]   WASHER;ADJUST.
11 4662114 [1]   WASHER;ADJUST.
12 4662115 [1]   WASHER;ADJUST.
13 4662116 [1]   WASHER;ADJUST.
15 2053917 [1]   CARRIER
16 4662108 [1]   PLATE;THRUST 2.3mm
17 3109161 [3]   GEAR;PLANETARY
18 4662109 [6]   PLATE;THRUST 0.8mm
19 4662110 [3]   PIN
20 4134502 [3]   PIN;SPRING
21 4685043 [3]   PIN;SPRING
22 4662132 [3]   BRG.;NEEDLE
23 3109160 [1]   GEAR;SUN
25 2053918 [1]   GEAR;RING
26 M341436 [13]   BOLT;SOCKET
27 4672166 [3]   BRG.;NEEDLE
28 2053916 [1]   CARRIER
29 3109159 [3]   GEAR;PLANETARY
30 4605115 [3]   RING;INNER
32 3109158 [1]   GEAR;SUN
33 4662133 [1]   PLATE
34 942517 [3]   RING;RETAINING
