HITACHI ZX670LC-5G T.MISSION (TRAVEL)

HITACHI ZX670LC-5G T.MISSION (TRAVEL)

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group T.MISSION (TRAVEL):
Pos. Part No Qty Parts name Comments
4641493 [1]   T.MISSION (TRAVEL)
1 985601 [1]   CARRIER
2 985602 [3]   GEAR;PLANETARY
3 985603 [3]   BRG.;NEEDLE
4 985604 [6]   WASHER;THRUST
5 985605 [3]   SHAFT
6 985606 [3]   PIN;SPRING
7 985607 [1]   WASHER
8 985634 [1]   CARRIER
9 985635 [3]   GEAR;PLANETARY
11 1108008 [6]   WASHER;THRUST
12 1108009 [3]   SHAFT
13 985613 [3]   PIN;SPRING
14 985614 [1]   WASHER
15 985615 [1]   CARRIER
16 985616 [4]   GEAR;PLANETARY
17 985611 [8]   WASHER;THRUST
18 985617 [4]   SHAFT
19 985618 [4]   PIN;SPRING
20 985619 [1]   GEAR;SUN
21 985637 [1]   GEAR;SUN
22 985636 [1]   GEAR;SUN
23 985622 [1]   GEAR;RING
24 985623 [1]   CASE
25 4350347 [1]   SEAL;GROUP
26 4200411 [2]   BRG.;ROL.
27 4353515 [1]   NUT
28 985625 [1]   PLATE;LOCK
29 985626 [2]   BOLT
30 985627 [1]   CASE
31 985628 [4]   PIN
32 4672724 [1]   COVER
33 985630 [1]   BUTTON
34 985631 [1]   BRG.;BALL
35 985632 [20]   BOLT
36 124934 [3]   BOLT;SOCKET
37 985633 [20]   WASHER;SPRING
