HITACHI ZX650LC-3 ZX670LC-5B ZX670LC-5G ZX670LCH-3 ZX670LCH-5B ZX670LCH-5G EXCAVATOR 4651137 9313706(R) 9313711(L) SWING MOTOR ROTARY GROUP

HITACHI ZX650LC-3 ZX670LC-5B ZX670LC-5G ZX670LCH-3 ZX670LCH-5B ZX670LCH-5G EXCAVATOR 4651137 9313706(R) 9313711(L) SWING MOTOR ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
4651137 9313706(R) 9313711(L) ZX650LC-3 ZX670LC-5B ZX670LC-5G ZX670LCH-3 ZX670LCH-5B ZX670LCH-5G ZX670LCR-3 ZX670LCR-5G
Pos. Part No Qty Parts name Comments
4651137 [1]   MOTOR;OIL
4651137 [1]   MOTOR;OIL
10 0788801 [1]   PISTON ASS'Y
10 0788801 [1]   PISTON ASS'Y
010A. +++++++ [9]   PISTON
010A. +++++++ [9]   PISTON
010B. +++++++ [9]   SHOE
010B. +++++++ [9]   SHOE
20 0788802 [1]   CASING ASS'Y
20 0788802 [1]   CASING ASS'Y
020A. +++++++ [1]   CASING
020A. +++++++ [1]   CASING
020B. +++++++ [2]   PIN;SPRING
020B. +++++++ [2]   PIN;SPRING
51 4472088 [2]   VALVE;RELIEF
51 4472088 [2]   VALVE;RELIEF
051A. A811030 [2]   O-RING
051A. A811030 [2]   O-RING
80 0788803 [1]   PLUNGER
80 0788803 [1]   PLUNGER
101 0788804 [1]   SHAFT
101 0788804 [1]   SHAFT
111 0788805 [1]   CYLINDER
111 0788805 [1]   CYLINDER
114 0788806 [1]   SPRING;PLATE
114 0788806 [1]   SPRING;PLATE
123 0788807 [1]   RETAINER
123 0788807 [1]   RETAINER
124 0788808 [1]   PLATE
124 0788808 [1]   PLATE
131 0788809 [1]   PLATE;VALVE
131 0788809 [1]   PLATE;VALVE
301 0981501 [1]   CASING
301 0981501 [1]   CASING
351 0409215 [2]   PLUNGER
351 0409215 [2]   PLUNGER
355 0409216 [2]   SPRING
355 0409216 [2]   SPRING
390 +++++++ [1]   PLATE
390 +++++++ [1]   PLATE
390 0817703 [1]   PLATE
390 0817703 [1]   PLATE
391 0625509 [2]   PIN
391 0625509 [2]   PIN
401 0365318 [4]   BOLT;SOCKET
401 0365318 [4]   BOLT;SOCKET
443 0788811 [1]   BRG.;ROL.
443 0788811 [1]   BRG.;ROL.
444 0677203 [1]   BRG.;ROL.
444 0677203 [1]   BRG.;ROL.
468 0629404 [2]   PLUG
468 0629404 [2]   PLUG
469 0692708 [2]   PLUG
469 0692708 [2]   PLUG
472 1119003 [1]   O-RING
472 1119003 [1]   O-RING
487 957366 [2]   O-RING
487 957366 [2]   O-RING
488 4506428 [2]   O-RING
488 4506428 [2]   O-RING
491 0788813 [1]   SEAL;OIL
491 0788813 [1]   SEAL;OIL
702 0788814 [1]   PISTON
702 0788814 [1]   PISTON
706 0353321 [1]   O-RING
706 0353321 [1]   O-RING
707 0425117 [1]   O-RING
707 0425117 [1]   O-RING
712 0788815 [24]   SPRING;BRAKE
712 0788815 [24]   SPRING;BRAKE
742 0788816 [3]   PLATE;FRICTION
742 0788816 [3]   PLATE;FRICTION
743 0788817 [4]   PLATE
743 0788817 [4]   PLATE
807 0788818 [1]   SPRING
807 0788818 [1]   SPRING
808 0221509 [1]   BALL;STEEL
808 0221509 [1]   BALL;STEEL
809 4506407 [1]   O-RING
809 4506407 [1]   O-RING
813 0263019 [2]   PLUG
813 0263019 [2]   PLUG
1000 1119004 [1]   KIT;SEAL
1000 1119004 [1]   KIT;SEAL
Parts on group SWING DEVICE (R):
Pos. Part No Qty Parts name Comments
9313706 [1]   SWING-DEVICE (R)
0 4651137 [1]   MOTOR;OIL
1 991342 [1]   RING;RETAINING
2 9313703 [1]   SWING-DEVICE
3 4614096 [8]   BOLT;SOCKET
4 4264452 [1]   PIPE
5 3074223 [1]   GAUGE;LEVEL
6 4332658 [1]   PIPE
7 4343365 [1]   BREATHER;AIR
8 4337381 [1]   PAINTING
9 +++++++ [1]   NAME-PLATE
10 M492564 [2]   SCREW;DRIVE
Parts on group SWING DEVICE (L):
Pos. Part No Qty Parts name Comments
9313711 [1]   SWING-DEVICE (L)
0 4651137 [1]   MOTOR;OIL
1 991342 [1]   RING;RETAINING
2 9313703 [1]   SWING-DEVICE
3 4614096 [8]   BOLT;SOCKET
4 4264452 [1]   PIPE
5 3074223 [1]   GAUGE;LEVEL
6 4332658 [1]   PIPE
7 4343365 [1]   BREATHER;AIR
8 4337381 [1]   PAINTING
9 +++++++ [1]   NAME-PLATE
10 M492564 [2]   SCREW;DRIVE
