HITACHI ZX60-HCMC EXCAVATOR 4679499 SWING MOTOR ROTARY GROUP

HITACHI ZX60-HCMC EXCAVATOR 4679499 SWING MOTOR ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
4679499 ZX60-HCMC
Pos. Part No Qty Parts name Comments
4679499 [1]   MOTOR;OIL
1 0993201 [1]   CASE
2 0732005 [1]   BRG.;BALL
3 0732002 [1]   SHAFT
4 0396807 [1]   PLATE;THRUST
5 +++++++ [1]   BLOCK;CYL.
6 0397905 [1]   COLLAR
7 0434006 [1]   SPRING
8 0434007 [1]   WASHER
9 0396815 [1]   RING;RETAINING
10 0434005 [3]   PIN
11 0946302 [1]   HOLDER
12 0732004 [1]   PLATE
13 +++++++ [9]   PISTON
14 0733403 [1]   DISK
15 0733404 [1]   PISTON
16 A811110 [1]   O-RING
17 A811135 [1]   O-RING
18 0733405 [2]   SEAT;SPRING
19 0733406 [1]   SPRING;DISK
20 0158830 [1]   O-RING
21 0733407 [1]   COVER
22 0397915 [1]   BRG.;BALL
23 0396703 [1]   PIN
24 0732003 [1]   PLATE;VALVE
25 311313 [2]   PIN
26 985099 [2]   O-RING
27 0168006 [5]   BOLT;SOCKET
28 0397916 [1]   ORIFICE
38 4679978 [2]   VALVE;RELIEF
38A. +++++++ [1]   HOUSING
38B. +++++++ [1]   POPET
38C. +++++++ [1]   SEAT
38D. +++++++ [1]   SEAT;SPRING
38E. +++++++ [1]   SPRING
38F. +++++++ [1]   PLUG
38G. +++++++ [1]   ADJUSTER
38H. 4506424 [1]   O-RING
38I. 4506320 [1]   O-RING
38J. +++++++ [1]   O-RING
38K. 4506412 [1]   O-RING
38L. +++++++ [2]   RING;BACK-UP
38M. 4027963 [2]   RING;BACK-UP
38N. +++++++ [1]   PISTON
39 0647003 [2]   VALVE;CHECK
40 0647004 [2]   SPRING
41 0311336 [2]   PLUG
42 4509180 [2]   O-RING
43 0647006 [2]   PLUG
44 4506408 [2]   O-RING
45 0436608 [1]   PLUG
46 957366 [1]   O-RING
60 +++++++ [1]   NAME-PLATE
61 +++++++ [2]   SCREW;DRIVE
62 +++++++ [4]   PLUG
63 +++++++ [1]   PLUG
100 4631798 [1]   BLOCK;CYL. KIT
200 4631797 [1]   KIT;SEAL
