HITACHI ZX60-HCMC EXCAVATOR 4678268 TRAVEL MOTOR ROTARY GROUP

HITACHI ZX60-HCMC EXCAVATOR 4678268 TRAVEL MOTOR ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
4678268 ZX60-HCMC
Pos. Part No Qty Parts name Comments
4678268 [1]   MOTOR;OIL (1/4) This PART NO. consists of all parts shown in MOTOR;OIL (1/4) to (4/4).
26 0396703 [1]   PIN
29 4506407 [4]   O-RING
30 +++++++ [1]   PLATE
31 +++++++ [1]   SPOOL ASS'Y
31A. +++++++ [1]   SPOOL
31B. +++++++ [2]   VALVE;CHECK
31C. +++++++ [2]   SPRING
31D. +++++++ [2]   PULG
31E. +++++++ [2]   O-RING
36 0398004 [2]   SEAT;SPRING
37 1159602 [2]   SPRING
38 0831902 [2]   CAP
39 4506429 [2]   O-RING
40 0158826 [4]   ORIFICE
41 +++++++ [1]   SPOOL
41A. +++++++ [1]   SPOOL
41B. +++++++ [1]   SPOOL
42 0921904 [1]   SPRING
43 0921910 [1]   PLUG
44 4509180 [2]   O-RING
45 0352225 [3]   PLUG
46 0921905 [1]   PLUG
47 0436603 [4]   ORIFICE
48 0167922 [8]   BOLT;SOCKET
49 0397910 [4]   PIN
55 94-2010 [1]   PLUG
57 4506408 [2]   O-RING
58 0855901 [2]   PLUG
59 +++++++ [2]   PLUG
60 0921906 [1]   PISTON
61 0921907 [2]   DISC
62 0726903 [8]   SPRING
63 0921908 [1]   COLLER
64 0921909 [1]   PLATE;FRICTION
65 0949201 [1]   O-RING
66 4154332 [1]   O-RING
67 A811125 [1]   O-RING
68 0949202 [1]   RING;BACK-UP
69 0949203 [1]   RING-BACK-UP
70 4305023 [1]   RING;BACK-UP
71 0436603 [2]   ORIFICE
72 0921911 [1]   SEAT;SPRING
73 0311336 [2]   PLUG
74 4509180 [2]   O-RING
100 4621965 [1]   KIT;SEAL
101 4621966 [1]   KIT;SEAL
102 1159601 [1]   BASE PLATE
Parts on group MOTOR;OIL (2/4):
Pos. Part No Qty Parts name Comments
4678268 [1]   MOTOR;OIL (2/4) This PART NO. consists of all parts shown in MOTOR;OIL (1/4) to (4/4).
2 0629801 [1]   SHAFT
3 0397902 [1]   BRG.;BALL
4 0732301 [1]   SEAL;OIL
5 0922001 [1]   PLATE
6 0732302 [2]   BALL;STEEL
7 +++++++ [1]   BLOCK;CYL.
8 +++++++ [1]   COLLAR
9 +++++++ [1]   SPRING
10 +++++++ [1]   WASHER
11 +++++++ [1]   RING;RETAINING
12 +++++++ [3]   PIN
13 +++++++ [1]   HOLDER
14 +++++++ [1]   PLATE
15 +++++++ [9]   PISTON
19 +++++++ [2]   PISTON
20 0922002 [2]   SPRING
25 0732003 [1]   PLATE;VALVE
27 0397915 [1]   BRG.;BALL
28 A811140 [1]   O-RING
103 1159701 [1]   BLOCK;CYL.
104 0922004 [1]   KIT;HOLDER
+++++++ [1]   KIT;SEAL
Parts on group MOTOR;OIL (4/4):
Pos. Part No Qty Parts name Comments
4678268 [1]   MOTOR;OIL (4/4)
50 0864701 [1]   VALVE ASS'Y
50-1. +++++++ [1]   BODY;VALVE
50-2. +++++++ [1]   SPOOL
50-3. +++++++ [2]   SPRING
50-4. +++++++ [2]   SEAT;SPRING
50-5. +++++++ [2]   PLUG
50-6. 4509180 [2]   O-RING
50-7. 4506412 [3]   O-RING
50-8. 0864706 [3]   BOLT;SOCKET
51 +++++++ [1]   NAME-PLATE
52 +++++++ [2]   SCREW;DRIVE
+++++++ [1]   KIT;SEAL
