HITACHI ZX450 TRANSMISSION (TRAVEL)(MT TRACK)

HITACHI ZX450 TRANSMISSION (TRAVEL)(MT TRACK)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRANSMISSION (TRAVEL)(MT TRACK):ZX450 TRANSMISSION (TRAVEL)(MT TRACK) Hitachi HOP online
Pos. Part No Qty Parts name Comments
9189960 [2]   T.MISSION (TRAVEL)
1 4353496 [1]   HOLDER
2 4353497 [3]   GEAR;PLANETARY
3 4246786 [3]   BRG.;NEEDLE
4 4353498 [6]   WASHER;THRUST
5 4353499 [3]   SHAFT
6 4105691 [3]   PIN;SPRING
7 4476041 [1]   WASHER
8 4353501 [1]   HOLDER
9 4353502 [3]   GEAR;PLANETARY
10 4289648 [3]   BRG.;NEEDLE
11 4353503 [6]   WASHER;THRUST
12 4353504 [3]   SHAFT
13 4144018 [3]   PIN;SPRING
14 4353505 [1]   WASHER
15 4353506 [1]   HOLDER
16 4476044 [4]   GEAR;PLANETARY
17 4452484 [8]   BRG.;NEEDLE
18 4353508 [8]   WASHER;THRUST
19 4472150 [4]   SHAFT
20 4144028 [4]   PIN;SPRING
21 4476046 [1]   GEAR;DRIVE
22 4353511 [1]   GEAR;SUN
23 4476043 [1]   GEAR;SUN
24 4476045 [1]   GEAR;RING
25 4476047 [1]   FLANGE
26 4350347 [1]   SEAL;GROUP
27 4200411 [2]   BRG.;ROL.
28 4353515 [1]   NUT
29 4353516 [1]   PLATE;LOCK
30 4353517 [2]   BOLT
31 4353518 [1]   HOUSING
32 4353519 [4]   PIN
33 4353520 [1]   COVER
34 4353521 [1]   BUTTON
35 4274541 [1]   BRG.;BALL
36 M221440 [20]   BOLT
37 A590914 [20]   WASHER;SPRING
38 94-2014 [3]   PLUG
