HITACHI ZX450 SWING DEVICE

HITACHI ZX450 SWING DEVICE

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group SWING DEVICE (R)(1):ZX450 SWING DEVICE (R)(1) Hitachi HOP online
Pos. Part No Qty Parts name Comments
9180778 [1]   SWING DEVICE :R (1) This PART NO. consists of all parts shown in SWING DEVICE (R)(1) to (2).
0 4423009 [1]   MOTOR;OIL
1 991342 [1]   RING;RETAINING
3 M341228 [8]   BOLT;SOCKET
4 4264452 [1]   PIPE
5 3074223 [1]   GAUGE;LEVEL
6 4332658 [1]   PIPE
7 4343365 [1]   CAP
9 3053093 [1]   NAME-PLATE
10 M492564 [2]   SCREW;DRIVE
Parts on group SWING DEVICE (R)(2):
ZX450 SWING DEVICE (R)(2) Hitachi HOP online
Pos. Part No Qty Parts name Comments
9180778 [1]   SWING DEVICE :R (2) This PART NO. consists of all parts shown in SWING DEVICE (R)(1) to (2).
1 2043694 [1]   SHAFT;PROP.
2 3085412 [1]   SLEEVE
3 A811120 [1]   O-RING
4 4402481 [1]   BRG.;ROL.
5 1026994 [1]   HOUSING
6 4422691 [1]   SEAL;OIL
6 4604376 [1]   SEAL;OIL
7 4402637 [1]   BRG.;ROL. Y 4667150
7 4667150 [1]   BRG.;ROL.
8 3086064 [1]   NUT
9 4411122 [1]   PLATE;LOCK
10 J901016 [2]   BOLT
11 1026662 [1]   CARRIER
12 4187590 [1]   PLATE;THRUST
13 9750364 [3]   GEAR;PLANETARY
14 4336929 [6]   PLATE;THRUST
15 4336925 [3]   PIN Y 4488904
15 4488904 [3]   PIN
16 4027427 [3]   PIN;SPRING
18 3080912 [1]   GEAR;SUN
20 1025957 [1]   GEAR;RING
21 M341645 [12]   BOLT;SOCKET
23 1025912 [1]   CARRIER
24 4403371 [1]   PLATE;THRUST
25 3082517 [3]   GEAR;PLANETARY
26 4404506 [3]   BRG.;NEEDLE
27 4403082 [3]   PLATE;THRUST
28 4336923 [3]   PIN
29 4051262 [3]   PIN;SPRING
30 3084056 [1]   GEAR;SUN
32 425176 [2]   CORK
33 4194712 [1]   COCK
36 94-2024 [1]   PLUG
37 4422479 [4]   MAGNET
38 M470513 [4]   SCREW
Parts on group SWING DEVICE (L)(1):
ZX450 SWING DEVICE (L)(1) Hitachi HOP online
Pos. Part No Qty Parts name Comments
9180776 [1]   SWING DEVICE :L (1) This PART NO. consists of all parts shown in SWING DEVICE (L)(1) to (2).
0 4423009 [1]   MOTOR;OIL
1 991342 [1]   RING;RETAINING
3 M341228 [8]   BOLT;SOCKET
4 4264452 [1]   PIPE
5 3074223 [1]   GAUGE;LEVEL
6 4332658 [1]   PIPE
7 4343365 [1]   CAP
9 3053093 [1]   NAME-PLATE
10 M492564 [2]   SCREW;DRIVE
Parts on group SWING DEVICE (L)(2):ZX450 SWING DEVICE (L)(2) Hitachi HOP online
Pos. Part No Qty Parts name Comments
9180776 [1]   SWING DEVICE :L (2) This PART NO. consists of all parts shown in SWING DEVICE (L)(1) to (2).
1 2043694 [1]   SHAFT;PROP.
2 3085412 [1]   SLEEVE
3 A811120 [1]   O-RING
4 4402481 [1]   BRG.;ROL.
5 1026994 [1]   HOUSING
6 4422691 [1]   SEAL;OIL
6 4604376 [1]   SEAL;OIL
7 4402637 [1]   BRG.;ROL. Y 4667150
7 4667150 [1]   BRG.;ROL.
8 3086064 [1]   NUT
9 4411122 [1]   PLATE;LOCK
10 J901016 [2]   BOLT
11 1026662 [1]   CARRIER
12 4187590 [1]   PLATE;THRUST
13 9750364 [3]   GEAR;PLANETARY
14 4336929 [6]   PLATE;THRUST
15 4336925 [3]   PIN Y 4488904
15 4488904 [3]   PIN
16 4027427 [3]   PIN;SPRING
18 3080912 [1]   GEAR;SUN
20 1025957 [1]   GEAR;RING
21 M341645 [12]   BOLT;SOCKET
23 1025912 [1]   CARRIER
24 4403371 [1]   PLATE;THRUST
25 3082517 [3]   GEAR;PLANETARY
26 4404506 [3]   BRG.;NEEDLE
27 4403082 [3]   PLATE;THRUST
28 4336923 [3]   PIN
29 4051262 [3]   PIN;SPRING
30 3084056 [1]   GEAR;SUN
32 425176 [2]   CORK
33 4194712 [1]   COCK
36 94-2024 [1]   PLUG
37 4422479 [4]   MAGNET
38 M470513 [4]   SCREW
