HITACHI ZX350LC-5B EXCAVATOR TRAVEL DEVICE

HITACHI ZX350LC-5B EXCAVATOR TRAVEL DEVICE

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL DEVICE:
Pos. Part No Qty Parts name Comments
9281920 [1]   TRAVEL DEVICE I 9281921
9281921 [1]   TRAVEL DEVICE
00 9281841 [1]   MOTOR;OIL I 9281842
00 9281842 [1]   MOTOR;OIL
03 4664392 [1]   SEAL;GROUP
04 4629674 [2]   BRG.;ROL.
05 1033164 [1]   DRUM
06 1033163 [1]   SPROCKET
07 A590922 [22]   WASHER;SPRING
08 J932265 [22]   BOLT
10 3094717 [1]   NUT
11 4470326 [1]   PLATE;LOCK
12 J901225 [2]   BOLT
14 1032599 [1]   CARRIER
15 4621530 [3]   SPACER
16 3103555 [4]   GEAR;PLANETARY
17 4628768 [8]   BRG.;NEEDLE
18 4269470 [8]   PLATE;THRUST
19 4269452 [4]   PIN
20 4207947 [4]   PIN;SPRING
21 3103554 [1]   GEAR;SUN
23 1032600 [1]   GEAR;RING
24 J931640 [34]   BOLT
26 1032598 [1]   CARRIER
27 3103553 [3]   GEAR;PLANETARY
28 4445531 [3]   BRG.;NEEDLE
29 4284521 [6]   PLATE;THRUST
30 4269451 [3]   PIN
31 4197763 [3]   PIN;SPRING
32 3103552 [1]   GEAR;SUN
34 1032597 [1]   CARRIER
36 3103551 [3]   GEAR;PLANETARY
37 4455098 [3]   BRG.;NEEDLE
38 4642993 [6]   PLATE;THRUST
39 4269472 [3]   PIN
40 4192020 [3]   PIN;SPRING
41 2051884 [1]   SHAFT;PROP.
43 1032596 [1]   COVER
44 4277474 [1]   PIN;STOPPER
45 4278168 [1]   BRG.;BALL
46 930451 [1]   RING;RETAINING
47 4699148 [20]   BOLT;SEMS
48 4245797 [3]   PLUG
51 +++++++ [1]   NAME-PLATE
52 M492564 [2]   SCREW;DRIVE
