HITACHI ZX330 EXCAVATOR TRAVEL DEVICE 9197359

HITACHI ZX330 EXCAVATOR TRAVEL DEVICE 9197359

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL DEVICE (MTH TRACK): 9197359
Pos. Part No Qty Parts name Comments
9197359 [2]   TRAVEL DEVICE I 9203778 (for assembly of machine)
9203778 [2]   TRAVEL DEVICE (for transportation)
0 4451685 [1]   MOTOR;OIL
2 1027942 [1]   HOUSING
4 4344155 [1]   SEAL;GROUP
5 1015882 [1]   DRUM
7 4200411 [2]   BRG.;ROL.
8 J932270 [24]   BOLT
9 A590922 [24]   WASHER;SPRING
10 3043140 [1]   NUT
11 3043141 [1]   PLATE;LOCK
12 J901222 [2]   BOLT
12 J901225 [2]   BOLT
13 1015883 [1]   CARRIER
14 3053195 [4]   GEAR;PLANETARY
15 4452484 [8]   BRG.;NEEDLE
16 4219595 [8]   PLATE;THRUST
17 4263903 [4]   PIN
18 4207947 [4]   PIN;SPRING
19 3053786 [1]   GEAR;SUN
21 1028494 [1]   SPROCKET Y 1010956
21 1010956 [1]   SPROCKET
22 4203187 [1]   O-RING
23 1018360 [1]   GEAR;RING
24 J931845 [30]   BOLT
27 1015523 [1]   CARRIER
28 4263905 [2]   SPACER
29 3053194 [3]   GEAR;PLANETARY
30 4452483 [3]   BRG.;NEEDLE
31 4201968 [6]   PLATE;THRUST
32 4263902 [3]   PIN
33 4203180 [3]   PIN;SPRING
34 3053785 [1]   GEAR;SUN
35 1024285 [1]   CARRIER
37 3079038 [3]   GEAR;PLANETARY
38 4452480 [3]   BRG.;NEEDLE
39 4269295 [6]   PLATE;THRUST
40 4263901 [3]   PIN
41 4222030 [3]   PIN;SPRING
42 2046005 [1]   SHAFT;PROP.
43 A590918 [4]   WASHER;SPRING
44 4279343 [3]   PLUG
46 4288767 [1]   PIN;STOPPER
49 J911860 [4]   BOLT
50 4274541 [1]   BRG.;BALL
51 991725 [1]   RING;RETAINING
52 +++++++ [1]   NAME-PLATE
53 M492564 [2]   SCREW;DRIVE
55 4271596 [1]   O-RING
56 1024284 [1]   COVER
57 4373463 [16]   BOLT;SHOE
