HITACHI ZX330 EXCAVATOR SWING DEVICE 2044704

HITACHI ZX330 EXCAVATOR SWING DEVICE 2044704

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group SWING DEVICE:ZX330 [1HH] SWING DEVICE Hitachi HOP online 2044704
Pos. Part No Qty Parts name Comments
1 2044704 [1]   SHAFT;PROP.
2 3088071 [1]   SLEEVE
3 4412650 [1]   O-RING
4 4430716 [1]   BRG.;ROL.
5 4430715 [1]   SEAL;OIL
6 1027932 [1]   HOUSING
7 4402481 [1]   BRG.;ROL.
8 3088070 [1]   NUT
9 4430563 [1]   PLATE;LOCK
11 2044703 [1]   CARRIER
13 3088069 [3]   GEAR;PLANETARY
14 4445254 [6]   BRG.;NEEDLE
15 4430663 [6]   PLATE;THRUST Y 4644567
15 4644567 [6]   PLATE;THRUST
16 4430714 [3]   PIN
17 4404947 [3]   PIN;SPRING
18 3075692 [1]   GEAR;SUN
19 J901016 [2]   BOLT
20 1027953 [1]   GEAR;RING
21 M342050 [12]   BOLT;SOCKET
22 4194454 [2]   PLATE;THRUST
23 1027952 [1]   CARRIER
24 3088063 [3]   GEAR;PLANETARY
25 4190117 [3]   BRG.;NEEDLE
26 4430667 [6]   PLATE;THRUST
27 4144558 [3]   PIN
28 4144525 [3]   PIN;SPRING
30 3088062 [1]   GEAR;SUN
32 3088126 [1]   PIPE
35 4445354 [2]   PLUG
36 94-2012 [1]   PLUG
51 3080001 [1]   PACKING (for transportation)
52 3080000 [1]   COVER (for transportation)
53 M341228 [4]   BOLT;SOCKET I 4614096
53 4614096 [4]   BOLT;SOCKET (for transportation)
100 4419718 [1]   MOTOR;OIL
101 M341228 [12]   BOLT;SOCKET
101 4614096 [12]   BOLT;SOCKET
102 959499 [1]   RING;RETAINING
104 4264452 [1]   PIPE
105 3074223 [1]   GAUGE;LEVEL
106 4388529 [1]   PIPE
107 4343365 [1]   CAP
108 3053093 [1]   NAME-PLATE
109 M492564 [2]   SCREW;DRIVE
200 9204194 [1]   SWING DEVICE (WITHOUT MOTOR)
