HITACHI ZX240-3 EXCAVATOR TRAVEL REDUCTION GEAR

HITACHI ZX240-3 EXCAVATOR TRAVEL REDUCTION GEAR

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL DEVICE:ZX240-3 [1V1] TRAVEL DEVICE Hitachi HOP online 9243839
Pos. Part No Qty Parts name Comments
9243839 [1]   TRAVEL DEVICE I 9256989 <for assembly of machine>
-9256989 [1]   TRAVEL DEVICE <for transportation>
0 9242907 [1]   MOTOR;OIL I 9257553 <for assembly of machine>
0 -9257553 [1]   MOTOR;OIL <for transportation>
2 4634693 [1]   SEAL;GROUP
3 4246793 [2]   BRG.;ROL.
4 1032488 [1]   DRUM
5 1032489 [1]   SPROCKET
6 J932055 [20]   BOLT
7 A590920 [20]   WASHER;SPRING
9 3086531 [1]   NUT
10 4436242 [1]   PIN;KNOCK
11 4628766 [6]   BRG.;NEEDLE
12 1032487 [1]   CARRIER
13 3103053 [3]   GEAR;PLANETARY
15 4624830 [6]   PLATE;THRUST
16 4139975 [3]   PIN
17 4116309 [3]   PIN;SPRING
18 3103054 [1]   GEAR;SUN
20 1032490 [1]   GEAR;RING
21 J931640 [28]   BOLT
23 1032486 [1]   CARRIER
24 4183819 [1]   SPACER
25 3103052 [3]   GEAR;PLANETARY
26 4445529 [3]   BRG.;NEEDLE
27 4210851 [6]   PLATE;THRUST
28 4309995 [3]   PIN
29 4246358 [3]   PIN;SPRING
30 3082149 [1]   GEAR;SUN
32 1032485 [1]   CARRIER
33 4401293 [1]   SPACER
34 3103051 [3]   GEAR;PLANETARY
35 4406589 [3]   BRG.;NEEDLE
36 4148080 [6]   PLATE;THRUST
37 4210853 [3]   PIN
38 4173093 [3]   PIN;SPRING
39 2049585 [1]   SHAFT;PROP.
41 2051690 [1]   COVER
42 4478346 [1]   PIN;STOPPER
43 4609016 [12]   BOLT;SEMS
44 4245797 [3]   PLUG
46 +++++++ [1]   NAME-PLATE
47 M492564 [2]   SCREW;DRIVE
