HITACHI ZX180W ZX180W-AMS EXCAVATOR 4475800 TRAVEL MOTOR PARTS

HITACHI ZX180W ZX180W-AMS EXCAVATOR 4475800 TRAVEL MOTOR PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
4475800 ZX180W ZX180W-AMS
Pos. Part No Qty Parts name Comments
4475800 [1]   MOTOR;OIL
5 0898801 [1]   HOUSING
8 0898802 [1]   PLUG
9 0898803 [1]   RING;RETAINING
10 0898804 [1]   RING;SEAL
11 0898805 [1]   RING;BACK-UP
12 0898806 [1]   O-RING
13 0898802 [1]   PLUG
18 0898808 [2]   NUT
22 0898809 [1]   SHAFT;DRIVE
23 0898810 [1]   SHIM
26 0898811 [1]   RING;BACK-UP 3.15mm
26 0898812 [1]   RING;BACK-UP 3.20mm
26 0898813 [1]   RING;BACK-UP 3.25mm
26 0898814 [1]   RING;BACK-UP 3.30mm
26 0898815 [1]   RING;BACK-UP 3.35mm
26 0898816 [1]   RING;BACK-UP 3.40mm
26 0898817 [1]   RING:BACK-UP 3.45mm
26 0898818 [1]   RING;BACK-UP 3.50mm
27 0898819 [1]   RING;RETAINING
30 0898820 [1]   BRG.;ROL.
31 0898821 [1]   BRG.;ROL.
41 0898822 [1]   CYLINDER
42 0898823 [1]   PLATE
43 0898824 [1]   PIN;CENTER
44 0898825 [7]   PISTON ASS'Y
44A. 0898826 [1]   PISTON
44B. 0898827 [2]   RING
46 0898828 [1]   SHIM 4.5mm
46 0898829 [1]   SHIM 4.6mm
46 0898830 [1]   SHIM 4.7mm
46 0898831 [1]   SHIM 4.8mm
46 0898832 [1]   SHIM 4.9mm
46 0898833 [1]   SHIM 5.0mm
47 0898834 [1]   SPRING
51 4614460 [1]   VALVE;BRAKE
61 0898835 [1]   PLATE
62 0898836 [14]   SCREW
73 0898837 [1]   PLATE
73 0915901 [1]   PLATE
74 0898838 [1]   PISTON
75 0898839 [1]   TRUNNION
77 0898840 [1]   PISTON
78 0898841 [1]   PIN
85 0898842 [8]   BOLT;SOCKET
89 0898843 [2]   O-RING
90 0898844 [3]   O-RING
91 0898845 [2]   O-RING
93 0898846 [1]   BOLT;SOCKET
94 0898847 [3]   RING
96 0898848 [2]   PIN
99 0898849 [2]   PLUG
99 0915902 [2]   PLUG
103 0898850 [1]   O-RING
104 0838619 [2]   PLUG
105 0898851 [2]   PIN
115 4690012 [2]   VALVE;RELIEF
121 0898853 [1]   HOUSING
122 0898854 [1]   BUSHING
123 0898855 [1]   PISTON
124 0898856 [1]   BUSHING
125 0898857 [1]   COLLAR
126 0898858 [1]   COLLAR
127 0898859 [1]   SPRING
128 0898860 [1]   SPRING
129 0898861 [1]   SPRING
134 0898862 [1]   O-RING
135 0898863 [4]   BOLT;SOCKET
136 0838619 [2]   PLUG
137 0898864 [1]   RING;RETAINING
139 0898865 [1]   PIN
140 0898866 [1]   PIN
141 0838604 [1]   NUT
149 0898867 [1]   RING;RETAINING
151 0898868 [1]   COVER
152 0898869 [1]   SCREW
160 0898870 [4]   BOLT;SOCKET
161 0898871 [1]   O-RING
162 0838619 [1]   PLUG
163 0915903 [2]   RING;BUCKUP
164 0898872 [1]   PIN
165 0898873 [1]   PIN
166 0838617 [1]   PLUG
167 0838606 [3]   PLUG
