HITACHI ZW220 ZW220-HCMF WHEEL LOADER 263G7-12021 263G7-12022 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

HITACHI ZW220 ZW220-HCMF WHEEL LOADER 263G7-12021 263G7-12022 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
263G7-12021 263G7-12022 ZW220 ZW220-HCMF
Pos. Part No Qty Parts name Comments
263G7-12021 [1]   PUMP;MAIN I 263G7-12022
263G7-12022 [1]   PUMP;MAIN
0 +++++++++++ [1]   PUMP
1 263G7-17591 [1]   REGULATOR;PUMP
2 263G7-17031 [1]   PUMP;GEAR
02A. 263H7-17271 [1]   SEAL KIT
3 263G7-17041 [1]   O-RING
4 HLM341030 [2]   BOLT;SOCKET
5 263G7-17051 [2]   WASHER;SPRING
6 263G7-17911 [2]   WASHER
7 263G7-17061 [2]   SCREW;DRIVE
8 +++++++++++ [1]   NAME-PLATE
11 263G7-12011 [1]   SPACER
12 HLM341245 [4]   BOLT;SOCKET
13 263G7-12051 [1]   O-RING
Parts on group PUMP:
Pos. Part No Qty Parts name Comments
+++++++++++ [1]   PUMP
0 +++++++++++ [1]   CASING;FRONT
1 263G7-17121 [1]   SHAFT;DRIVE
2 263G7-17131 [1]   RACE;INNER
3 263G7-17141 [1]   RING;RETAINING
4 263G7-17151 [1]   BRG.;ROL.
5 02100-00045 [2]   RING;RETAINING
6 263G7-17161 [1]   PIN;KNOCK
7 263G7-17171 [1]   PLATE;CRADLE
8 HLM340830 [4]   BOLT;SOCKET
9 263G7-17181 [1]   PLATE;SWASH
10 263G7-17951 [1]   PLATE
11 263G7-17201 [1]   PIN
13 263G7-17211 [7]   SPRING;COMPRES.
14 263G7-17221 [1]   BUSHING
15 263G7-17231 [1]   RETAINER
17 263G7-17251 [1]   O-RING
18 +++++++++++ [1]   CASING;PUMP
19 263G7-17261 [1]   BRG.;NEEDLE
20 263G7-17271 [1]   PIN;KNOCK
22 263G7-17281 [3]   PISTON;SERVO
23 263G7-17291 [1]   PIN;KNOCK
24 263G7-17301 [1]   PIN
25 263G7-17921 [2]   RING;BACK-UP
26 263G7-17311 [2]   O-RING
27 263G7-17321 [1]   PIN
28 263G7-17331 [1]   LINK
29 263G7-17341 [1]   PIN
30 263G7-17881 [1]   PIN
31 02270-04016 [1]   PIN;SPRING
32 263G7-17931 [1]   PIN;SPRING
33 HLM341460 [8]   BOLT;SOCKET
35 263G7-17351 [2]   PLUG
35A. 03320-00080 [1]   O-RING
36 263G7-17361 [1]   PLUG
36A. 03320-00110 [1]   O-RING
37 263G7-17371 [1]   PLUG
37A. 03320-00140 [1]   O-RING
38 263G7-17381 [5]   PLUG
39 HL4668254 [1]   SENSOR;PRES.
39A. HL4365826 [1]   O-RING
40 02270-04010 [2]   PIN;SPRING
41 263G7-17391 [1]   O-RING
42 263G7-17311 [5]   O-RING
43 263G7-17401 [1]   O-RING
44 263G7-17411 [1]   SEAL;OIL
45 02110-00068 [1]   RING;RETAINING
46 263G7-17571 [7]   PISTON
47 263G7-17541 [1]   ROTOR I 263G7-17951
47 263G7-17951 [1]   ROTOR
61 263G7-17421 [1]   ORIFICE
62 263G7-17431 [2]   ORIFICE
63 HLA885008 [2]   PLUG
63A. 03320-00290 [1]   O-RING
64 263G7-17441 [1]   PLUG
65 03320-00380 [1]   O-RING
67 263G7-17451 [1]   PLUG
68 263G7-17461 [1]   SEAT
69 263G7-17471 [1]   VALVE
70 263G7-17481 [1]   SPRING
71 263G7-17491 [1]   SCREW
72 263G7-17501 [2]   GASKET
73 263G7-17511 [1]   NUT
74 263G7-17521 [1]   NUT;CAP
75 263G7-17531 [1]   SPRING;COMPRES.
76 +++++++++++ [1]   SPOOL
