HITACHI YB60000245 YB60000246 9298855 HYDRAULIC PUMP ROTARY GROUP

Name: HITACHI YB60000245 YB60000246 9298855 HYDRAULIC PUMP ROTARY GROUP
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

HITACHI YB60000245 YB60000246 9298855 HYDRAULIC PUMP ROTARY GROUP

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

YB60000245 YB60000246 9298855 ZX670LC-5B ZX670LC-5G ZX670LCH-5B ZX670LCH-5G ZX670LCR-5G ZX870-5G ZX870H-5G ZX870LC-5G ZX870LCH-5G ZX870LCR-5G

Pos.	Part No	Qty	Parts name	Comments
	YB60000245	[1]	PUMPDRIVE
0	9313598	[1]	PUMPMISSION	I YB60000413 (for assembly of machine)
0	YB60000413	[1]	PUMPMISSION	(for transportation)
2	YB60000246	[2]	PUMP;PISTON
4	M342080	[8]	BOLT;SOCKET
5	A590920	[8]	WASHER;SPRING
6	4445928	[2]	O-RING
9	4153543	[1]	O-RING
10	J222010	[2]	WASHER
11	4700708	[1]	PUMP;GEAR
12	M341030	[2]	BOLT;SOCKET
14	YA00011362	[1]	PUMP;PISTON
15	M341656	[2]	BOLT;SOCKET
16	A590916	[2]	WASHER;SPRING
17	4153552	[1]	O-RING
19	3118683	[1]	MANIFOLD
20	M341230	[4]	BOLT;SOCKET
21	A852344	[1]	ELBOW;S
21A.	4506418	[1]	O-RING
22	A810050	[1]	O-RING
25	8121562	[1]	PIPE
26	A811035	[1]	O-RING
29	J901260	[4]	BOLT
30	A590112	[4]	WASHER;PLANE
31	4466996	[1]	TEE;S
32	A852366	[1]	ELBOW;S
32A.	4506424	[1]	O-RING
33	4713090	[1]	HOSE
35	J260816	[1]	BOLT;SEMS
35A.	J900816	[1]	BOLT
35B.	A590108	[1]	WASHER;PLANE
Parts on group PUMP;PISTON:

Pos.	Part No	Qty	Parts name	Comments
	YB60000246	[1]	PUMP;PISTON
1	9298855	[1]	PUMP;UNIT
3	9298856	[1]	REGULATOR;PUMP	I YB60000920 (for assembly of machine)
3	YB60000920	[1]	REGULATOR;PUMP	(for transportation)
5	+++++++	[1]	NAME-PLATE
6	M492564	[2]	SCREW;DRIVE
Parts on group REGULATOR;PUMP:

Pos.	Part No	Qty	Parts name	Comments
	9298856	[1]	REGULATOR;PUMP	I YB60000920 (for assembly of machine)
	YB60000920	[1]	REGULATOR;PUMP	(for transportation)
37	9322887	[1]	REGULATOR;ASSY
39	9239213	[1]	VALVE;SOLENOID
40	4154601	[1]	O-RING
41	4150302	[2]	O-RING
42	4180349	[1]	O-RING
43	M340880	[4]	BOLT;SOCKET
46	4447264	[1]	PLUG
47	4153108	[1]	O-RING
50	M341056	[4]	BOLT;SOCKET
52	4436536	[1]	SENSOR;PRES.
52A.	4153095	[1]	O-RING
100	YB00000858	[1]	KIT;SEAL
Parts on group PUMP MISSION:

Pos.	Part No	Qty	Parts name	Comments
	9313598	[1]	PUMPMISSION	I YB00000413 (for assembly of machine)
	YB00000413	[1]	PUMPMISSION	(for transportation)
0	7454	[1]	CASE;MISSION
2	2052159	[1]	GEAR
4	4160773	[3]	BRG.;BALL
6	3104843	[1]	COUPLING
7	4116290	[2]	RING;RETAINING
9	2052164	[1]	CARTRIDGE
10	4443632	[1]	O-RING
11	J271235	[10]	BOLT;SEMS
11A.	J901235	[1]	BOLT
11B.	J222012	[1]	WASHER
12	M342071	[8]	BOLT;SOCKET
14	4641671	[1]	SEAL;OIL
15	2052160	[2]	GEAR
18	2052165	[2]	CARTRIDGE
19	4637148	[2]	O-RING
20	4153532	[1]	O-RING
24	4634350	[1]	GAUGE;LEVEL
26	8121575	[1]	PIPE
27	M341036	[4]	BOLT;SOCKET
31	4174542	[3]	PLUG
31A.	4506424	[1]	O-RING
37	4187328	[1]	O-RING
38	A853368	[1]	ELBOW;S
38A.	4506424	[1]	O-RING
42	4472548	[2]	BRG.;BALL
43	4472549	[1]	BRG.;BALL
45	+++++++	[1]	NAME-PLATE
46	M492564	[2]	SCREW;DRIVE
47	4722534	[1]	BREATHER;AIR
48	8104650	[1]	PIPE
Parts on group PUMP;UNIT:

Pos.	Part No	Qty	Parts name	Comments
	9298855	[1]	PUMP;UNIT
1	4541	[1]	CASING;PUMP
3	2048195	[1]	SHAFT;DRIVE
4	488075	[2]	RING;RETAINING
5	4645955	[1]	SPACER
6	4440264	[1]	BRG.;ROL.
8	4472903	[1]	RING;RETAINING
10	1030551	[1]	PLATE
11	4343074	[2]	O-RING
12	4212842	[1]	PIN;KNOCK
13	4427347	[2]	PLUG
14	M341025	[4]	BOLT;SOCKET
16	3095197	[1]	PISTON;SERVO
18	1030456	[1]	PLATE;SWASH
19	4198956	[1]	PIN
20	4481827	[1]	PLATE;CAM
22	4473215	[1]	BUSHING;GUIDE
24	2050591	[1]	COVER
25	4632389	[1]	SEAL;OIL
26	4153552	[1]	O-RING
27	M340825	[4]	BOLT;SOCKET
29	8106487	[1]	ROTOR;GROUP
29A.	+++++++	[1]	ROTOR
29B.	+++++++	[1]	PLATE;VALVE
31	4452970	[1]	SPRING;DISC
32	3090660	[1]	BUSHING
34	3090648	[1]	RETAINER
36	8088402	[9]	PISTON
39	7287	[1]	BLOCK;PORT
41	4645945	[1]	RING
42	4472907	[1]	PIN;KNOCK
43	4472905	[1]	BRG.;NEEDLE
45	4409640	[1]	PIN;KNOCK
46	4626259	[1]	PIN
47	4436322	[2]	RING;BACK-UP
48	4180349	[2]	O-RING
50	4473983	[1]	O-RING
51	M342080	[6]	BOLT;SOCKET
52	J222020	[6]	WASHER
54	4473248	[1]	STOPPER
55	4196265	[1]	O-RING
56	4473249	[1]	STOPPER
57	4292386	[1]	O-RING
58	4427347	[2]	PLUG
59	M340825	[12]	BOLT;SOCKET
61	1030458	[1]	IMPELLER
62	2048157	[1]	COVER
63	4633509	[1]	O-RING
64	M341025	[6]	BOLT;SOCKET
66	3095201	[1]	LINK
67	4610111	[1]	LEVER
68	4116304	[1]	PIN;SPRING
69	4472909	[1]	PIN
70	4146370	[2]	RING;RETAINING
71	4200227	[1]	PIN
75	4515041	[2]	PIN;SPRING
76	4153537	[1]	O-RING
77	4180349	[3]	O-RING
80	4703324	[1]	SENSOR;PRES.
80A.	4365826	[1]	O-RING
81	4336165	[3]	PLUG
82	4366517	[3]	O-RING
84	4336166	[1]	PLUG
85	4297379	[1]	O-RING
87	4336169	[4]	PLUG
88	4153103	[4]	O-RING
90	4085511	[1]	PLUG
91	4297379	[1]	O-RING
100	YB00000857	[1]	KIT;SEAL
Parts on group VALVE;SOLENOID:

Pos.	Part No	Qty	Parts name	Comments
	9239213	[1]	VALVE;SOLENOID
1	+++++++	[1]	HOUSING
5	+++++++	[4]	PLUG
6	9761179	[2]	PLUG
7	+++++++	[1]	NAME-PLATE
8	M491832	[2]	SCREW;DRIVE
10	9239215	[1]	PLUG
10A.	4620038	[1]	O-RING
12	9306641	[1]	VALVE;SOLENOID
12A.	+++++++	[1]	SPOOL
12B.	4601048	[1]	SPRING;COMPRES.
12C.	4603163	[1]	PLATE
12D.	4489678	[1]	WASHER
12E.	4620025	[1]	O-RING
12F.	M340513	[2]	BOLT;SOCKET
12G.	+++++++	[1]	SOLENOID
12H.	+++++++	[1]	SLEEVE
12H1.	+++++++	[1]	SLEEVE
12H2.	4633888	[1]	O-RING
12H3.	4633889	[1]	O-RING
12H4.	4633890	[1]	O-RING
