HITACHI YA00011362 HYDRAULIC PUMP PARTS

HITACHI YA00011362 HYDRAULIC PUMP PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
YA00011362
ZX870-5G ZX870H-5G ZX870LC-5G ZX870LCH-5G ZX870LCR-5G
Pos. Part No Qty Parts name Comments
YA00011362 [1]   PUMP;PISTON
1 XA00000134 [1]   REGULATOR;PUMP
11 XB00001198 [1]   PISTON
011A. +++++++ [9]   PISTON
011B. +++++++ [9]   SHOE
14 XB00001199 [1]   CYL.
014A. +++++++ [1]   BLOCK;CYL.
014B. +++++++ [1]   PLATE;VALVE
30 XB00001200 [1]   PLATE
030A. +++++++ [1]   PLATE
030B. +++++++ [1]   BUSHING
111 XB00001207 [1]   SHAFT
116 XB00001208 [1]   COUPLING
123 XB00001209 [1]   BRG.;ROL.
124 XB00001210 [1]   BRG.;NEEDLE
127 818508 [1]   SPACER
153 XB00001214 [1]   PLATE
156 1184310 [1]   BUSHING.
157 708012 [6]   SPRING
211 XB00001215 [1]   PLATE
251 XB00001218 [1]   SUPPORT
257 XB00001201 [1]   PIN
257A. XB00001219 [1]   PIN;LOCK
257B. XB00001234 [1]   O-RING
261 XB00001220 [1]   COVER;SEAL
271 XB00001221 [1]   CASING;PUMP
312 XB00001222 [1]   COVER
401 719309 [2]   BOLT;SOCKET
402 M341600 [2]   BOLT;SOCKET
406 846703 [4]   BOLT;SOCKET
465 719004 [1]   PLUG
466 998702 [2]   PLUG
467 1104202 [1]   PLUG
468 719101 [2]   PLUG
490 263019 [2]   PLUG
530 XB00001202 [1]   PIN
530A. +++++++ [1]   PIN
530B. +++++++ [1]   PIN
532 XB00001226 [1]   PISTON;SERVO
534 818523 [1]   STOPPER
550 XB00001203 [1]   PLUG
550A. XB00001227 [1]   PLUG
550B. XB00001228 [1]   STOPPER
550C. XB00001235 [1]   O-RING
550D. XB00001236 [1]   O-RING
550E. XB00001238 [1]   RING;BACK-UP
550F. XB00001240 [1]   NUT
550G. XB00001245 [1]   SCREW;SET
702 XB00001229 [1]   O-RING
710 XB00001230 [1]   O-RING
717 682321 [1]   O-RING
723 XB00001231 [4]   O-RING
724 XB00001232 [7]   O-RING
727 XB00001233 [2]   O-RING
732 XB00001235 [1]   O-RING
774 XB00001237 [1]   SEAL;OIL
792 XB00001239 [1]   RING;BACK-UP
808 XB00001241 [1]   NUT
824 XB00001242 [1]   RING;RETAINING
827 XB00001243 [1]   RING
886 XB00001133 [2]   PIN
901 XB00001244 [1]   BOLT;EYE
954 818525 [1]   SCREW;SET
981 +++++++ [1]   NAME-PLATE
983 XB00001134 [2]   PIN
Parts on group REGULATOR;PUMP:
Pos. Part No Qty Parts name Comments
XA00000134 [1]   REGULATOR;PUMP
41 820444 [2]   VALVE;CHEACK AS
041A. +++++++ [2]   SEAT
041B. +++++++ [2]   STOPPER
041C. +++++++ [2]   BALL;STEEL
79 XB00001266 [1]   VALVE;REDUCING
325 +++++++ [1]   CASING
402 M340616 [4]   BOLT;SOCKET
407 M340630 [4]   BOLT;SOCKET
415 M340840 [4]   BOLT;SOCKET
418 945901 [2]   BOLT;SOCKET
466 998702 [1]   PLUG
496 263019 [9]   PLUG
601 +++++++ [1]   CASING
611 +++++++ [1]   LEVER
614 +++++++ [1]   PLUG
616 +++++++ [1]   PLUG
624 +++++++ [1]   SEAT;SPRING
627 +++++++ [1]   ROD
631 +++++++ [1]   SLEEVE
643 +++++++ [1]   PISTON
646 +++++++ [1]   SPRING
651 +++++++ [1]   SLEEVE
652 +++++++ [1]   SPOOL
656 +++++++ [1]   COVER
658 +++++++ [1]   PLUG
708 XB00001260 [1]   O-RING
724 443801 [5]   O-RING
726 444004 [1]   O-RING
731 444001 [1]   O-RING
733 443803 [1]   O-RING
754 443405 [2]   O-RING
755 981201 [3]   O-RING
801 156009 [1]   NUT
875 +++++++ [1]   PIN
887 +++++++ [1]   PIN
897 +++++++ [1]   PIN
924 828501 [1]   SCREW
