HITACHI EX30UR EXCAVATOR SWING REDUCTION GEAR

HITACHI EX30UR EXCAVATOR SWING REDUCTION GEAR

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group MOTOR;OIL (1/3):
Pos. Part No Qty Parts name Comments
4269355 [1]   MOTOR;OIL (1/3) This PART NO. consists of all parts shown in MOTOR;OIL(1/3) to (3/3).
201 0434501 [1]   CASE
202 0434502 [1]   SHAFT;PINION
203 0434503 [1]   PLATE
204 0434504 [1]   BRG.;BALL
205 0251311 [1]   SEAL;OIL
206 310003 [1]   BRG.;BALL
207 +++++++ [1]   SHIM 0.05
208 +++++++ [2]   SHIM 0.1
209 +++++++ [2]   SHIM 0.3
210 962002 [1]   RING;RETAINING
211 0434505 [1]   HOLDER ASSY
211A. 0434506 [1]   HOLDER
211B. 0433908 [3]   RACE;INNER
211C. 0433909 [3]   BRG.;NEEDLE
211D. 0434507 [3]   GEAR;PLANETARY
211E. 0434508 [1]   PLATE;THRUST
211F. 0434509 [3]   SCREW
212 0434510 [1]   GEAR
213 0434511 [1]   HOLDER ASSY
213A. 0434512 [1]   HOLDER
213B. 0434513 [3]   RACE;INNER
213C. 0434514 [3]   BRG.;NEEDLE
213D. 0434515 [3]   GEAR;PLANETARY
213E. +++++++ [1]   PLATE;THRUST
213F. +++++++ [1]   PLATE;THRUST
213G. 4015383 [3]   PIN;SPRING
214 0434516 [1]   GEAR;DRIVE
600 0434517 [1]   SHIM SET
700 0434518 [1]   PLATE;THRUST SET
