HITACHI EX2500 EX2500-5 EX2500-6 EX5600-6BH EX5600-6LD EXCAVATOR HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

HITACHI EX2500 EX2500-5 EX2500-6 EX5600-6BH EX5600-6LD EXCAVATOR HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
4427045
EX2500 EX2500-5 EX2500-6 EX5600-6BH EX5600-6LD
Pos. Part No Qty Parts name Comments
4427045 [1]   PUMP;PISTON
11 0708001 [1]   PISTON ASS'Y
011A. +++++++ [9]   PISTON
011B. +++++++ [9]   SHOE
14 0708002 [1]   CYLINDER ASS'Y
014A. +++++++ [1]   BLOCK;CYL.
014B. +++++++ [1]   PLATE;VALVE
30 0708003 [1]   PLATE ASS'Y
030A. +++++++ [1]   PLATE;SWASH
030B. +++++++ [1]   BUSHING
41 0708004 [2]   VALVE;CHECK ASS'Y
041A. +++++++ [1]   SEAT
041B. +++++++ [1]   STOPPER
041C. +++++++ [1]   BALL;STEEL
42 0708005 [2]   VALVE;CHECK ASS'Y
042A. +++++++ [1]   SEAT
042B. +++++++ [1]   STOPPER
042C. +++++++ [1]   BALL;STEEL
111 0708006 [1]   SHAFT
114 0708007 [1]   COUPLING
123 0708008 [1]   BRG.;ROL.
124 0708009 [1]   BRG.;NEEDLE
127 0175208 [2]   SPACER
153 0708010 [1]   PLATE
156 0708011 [1]   BUSHING
157 0708012 [9]   SPRING
158 0708013 [1]   SPACER
211 0100014 [1]   PLATE
251 0708014 [1]   SUPPORT
261 0708015 [1]   COVER
271 0708016 [1]   CASING;PUMP
312 0708017 [1]   COVER;VALVE
325 0708018 [1]   CASING
326 0708019 [1]   PLATE
401 0708020 [4]   BOLT;SOCKET
406 M340820 [4]   BOLT;SOCKET
407 0155616 [3]   BOLT;SOCKET
408 4040040 [4]   BOLT;SOCKET
466 0236014 [2]   PLUG
468 +++++++ [2]   PLUG
490 0263019 [11]   PLUG
530 0708021 [2]   PIN ASS'Y
530A. +++++++ [1]   PIN
530B. +++++++ [1]   PIN
532 0708022 [1]   PISTON
534 0708023 [1]   STOPPER
535 0708024 [1]   STOPPER
702 A811035 [1]   O-RING
709 A811085 [1]   O-RING
710 A811095 [1]   O-RING
717 A811145 [2]   O-RING
724 4506408 [10]   O-RING
725 957366 [2]   O-RING
728 4506424 [2]   O-RING
732 4506418 [1]   O-RING
774 0708025 [1]   SEAL;OIL
789 4033725 [1]   RING;BACK-UP
792 0708026 [1]   RING;BACK-UP
805 0124325 [1]   NUT;LOCK
806 0131108 [1]   NUT;LOCK
808 0451038 [1]   NUT
824 962002 [1]   RING;RETAINING
885 0175240 [1]   PIN
886 0244604 [2]   PIN;SPRING
901 04091248 [1]   BOLT;EYE
953 0708027 [1]   SCREW;SET
954 0708028 [1]   SCREW;SET
990 4464752 [1]   REGULATOR
