HITACHI EX2500-5 EX2500-6 EX5500-5 EX5500-6 EXCAVATOR 4689082 4689083 HYDRAULIC PUMP PARTS

HITACHI EX2500-5 EX2500-6 EX5500-5 EX5500-6 EXCAVATOR 4689082 4689083 HYDRAULIC PUMP PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
4689083
EX2500-5 EX2500-6 EX5500-5 EX5500-6
Pos. Part No Qty Parts name Comments
4689083 [1]   PUMP;PISTON
11 0838201 [2]   PISTON ASS'Y
011A. +++++++ [9]   PISTON
011B. +++++++ [9]   SHOE
12 +++++++ [2]   BLOCK;CYL.
13 0703001 [1]   CYL. ASS'Y
14 0703002 [1]   CYL. ASS'Y
30 0716801 [2]   PLATE ASS'Y
030A. +++++++ [1]   PLATE
030B. +++++++ [1]   BUSHING
111 0703006 [1]   SHAFT
113 0703007 [1]   SHAFT
114 0703008 [1]   COUPLING
123 0682302 [2]   BRG.;ROL.
124 0800701 [2]   BRG.;NEEDLE
127 0339809 [4]   SPACER
130 0703010 [1]   BOOSTER
153 0718002 [2]   RETAINER
156 0682306 [2]   BUSHING
157 0682307 [18]   SPRING
158 0682308 [2]   SPACER
211 0682309 [2]   PLATE
251 0800702 [2]   SUPPORT
253 0737002 [8]   WASHER
261 0682311 [1]   COVER
263 0703012 [1]   COVER
271 0800703 [2]   CASING
311 0703014 [1]   COVER;VALVE
312 0800704 [1]   COVER;VALVE
313 +++++++ [1]   PLATE;VALVE
314 +++++++ [1]   PLATE;VALVE
401 0682316 [4]   BOLT;SOCKET
402 0703016 [4]   BOLT;SOCKET
406 M340820 [8]   BOLT;SOCKET
415 0116621 [2]   BOLT;SOCKET
416 0800705 [4]   BOLT;SOCKET
466 0236014 [2]   PLUG
468 0175233 [4]   PLUG
490 0934502 [31]   PLUG
491 0451027 [4]   SCREW
492 0934503 [5]   PLUG
530 0800706 [2]   PIN ASS'Y
530A. +++++++ [1]   PIN
530B. +++++++ [1]   PIN
532 0800707 [2]   PISTON;SERVO
534 0682319 [2]   STOPPER
535 0682320 [2]   STOPPER
702 4292386 [2]   O-RING
706 0703018 [1]   O-RING
710 0682321 [2]   O-RING
717 0682322 [4]   O-RING
718 0703019 [1]   O-RING
724 0443801 [19]   O-RING
725 4297379 [2]   O-RING
728 0443408 [4]   O-RING
732 0682324 [2]   O-RING
774 0682325 [1]   SEAL;OIL
789 0682326 [2]   RING;BACK-UP
792 0682327 [2]   RING;BACK-UP
808 0451038 [4]   NUT
824 960323 [2]   RING;RETAINING
885 0313404 [2]   PIN
886 4144353 [5]   PIN;SPRING
901 0177612 [2]   BOLT;EYE
953 0339847 [2]   SCREW
954 0682328 [2]   SCREW;SET
956 0800708 [8]   SCREW;SET
981 +++++++ [1]   NAME-PLATE
983 0625509 [2]   PIN
990 4689093 [2]   REGULATOR
  REGULATOR (1/3)
  REGULATOR (2/3)
  REGULATOR (3/3)
1000 4620698 [1]   KIT;SEAL
4689082
EX2500-5 EX2500-6 EX5500-5 EX5500-6
Pos. Part No Qty Parts name Comments
4689082 [1]   PUMP;PISTON
11 0838201 [2]   PISTON ASS'Y
011A. +++++++ [9]   PISTON
011B. +++++++ [9]   SHOE
12 +++++++ [2]   BLOCK;CYL.
13 0703001 [1]   CYL. ASS'Y
14 0703002 [1]   CYL. ASS'Y
30 0716801 [2]   PLATE ASS'Y
030A. +++++++ [1]   PLATE
030B. +++++++ [1]   BUSHING
111 0703006 [1]   SHAFT
113 0694601 [1]   SHAFT
114 0703008 [1]   COUPLING
123 0682302 [2]   BRG.;ROL
124 0800701 [2]   BRG.;NEEDLE
127 0339809 [4]   SPACER
130 0703010 [1]   BOOSTER
153 0718002 [2]   RETAINER
156 0682306 [2]   BUSHING
157 0682307 [18]   SPRING
158 0682308 [2]   SPACER
211 0682309 [2]   PLATE
251 0800702 [2]   SUPPORT
253 0738101 [8]   WASHER
261 0682311 [1]   COVER
263 0694602 [1]   COVER
264 0694603 [1]   COVER
271 0800703 [2]   CASING
311 0703014 [1]   COVER;VALVE
312 0800704 [1]   COVER;VALVE
313 +++++++ [1]   PLATE;VALVE
314 +++++++ [1]   PLATE;VALVE
401 0682316 [4]   BOLT;SOCKET
402 0703016 [4]   BOLT;SOCKET
406 M340820 [8]   BOLT;SOCKET
409 4515013 [2]   BOLT;SOCKET
415 0116621 [2]   BOLT;SOCKET
416 0800705 [4]   BOLT;SOCKET
466 0236014 [2]   PLUG
468 0175233 [4]   PLUG
490 0934502 [31]   PLUG
491 0451027 [4]   SCREW
492 0934503 [5]   PLUG
530 0800706 [2]   PIN ASS'Y
530A. +++++++ [1]   PIN
530B. +++++++ [1]   PIN
532 0800707 [2]   PISTON;SERVO
534 0682319 [2]   STOPPER
535 0682320 [2]   STOPPER
702 4292386 [2]   O-RING
706 0703018 [1]   O-RING
708 0694604 [1]   O-RING
710 0682321 [2]   O-RING
717 0682322 [4]   O-RING
718 0703019 [1]   O-RING
724 0443801 [19]   O-RING
725 4297379 [2]   O-RING
728 0443408 [4]   O-RING
732 0682324 [2]   O-RING
774 0682325 [1]   SEAL;OIL
789 0682326 [2]   RING;BACK-UP
792 0682327 [2]   RING;BACK-UP
808 0451038 [4]   NUT
824 0960323 [2]   RING;RETAINING
885 0313404 [2]   PIN
886 4144353 [5]   PIN;SPRING
901 0177612 [2]   BOLT;EYE
953 0339847 [2]   SCREW
954 0682328 [2]   SCREW;SET
956 0800708 [8]   SCREW;SET
981 +++++++ [1]   NAME-PLATE
983 0625509 [2]   PIN
990 4689093 [2]   REGULATOR
  REGULATOR (1/3)
  REGULATOR (2/3)
  REGULATOR (3/3)
1000 4620941 [1]   KIT;SEAL
