HITACHI EX1200-6 ZX650LC-3 ZX670LCH-3 ZX670LCR-3 ZX850-3 ZX850-3F ZX850LC-3-DH ZX870H-3 ZX870H-3F ZX870H-3-HCMC ZX870R-3 ZX870R-3F EXCAVATOR 4635645 HYDRAULIC PISTON PUMP ROTARY GROUP

HITACHI EX1200-6 ZX650LC-3 ZX670LCH-3 ZX670LCR-3 ZX850-3 ZX850-3F ZX850LC-3-DH ZX870H-3 ZX870H-3F ZX870H-3-HCMC ZX870R-3 ZX870R-3F EXCAVATOR 4635645 HYDRAULIC PISTON PUMP ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
4635645
EX1200-6 ZX650LC-3 ZX670LCH-3 ZX670LCR-3 ZX850-3 ZX850-3F ZX850LC-3-DH ZX870H-3 ZX870H-3F ZX870H-3-HCMC ZX870R-3 ZX870R-3F
Pos. Part No Qty Parts name Comments
9249785 [1]   PUMP DEVICE
0 9249786 [1]   9249786A I 9276421
0 9276421 [1]   PUMP;MISSION
2 4635645 [2]   PUMP;PISTON
4 M342080 [8]   BOLT;SOCKET
5 A590920 [8]   WASHER;SPRING
6 4445928 [2]   O-RING
9 4153543 [1]   O-RING
10 A590110 [2]   WASHER;PLANE
11 9217993 [1]   PUMP;GEAR
12 M341030 [2]   BOLT;SOCKET
14 4635787 [1]   PUMP;PISTON
15 M341656 [4]   BOLT;SOCKET
16 A590916 [4]   WASHER;SPRING
17 4153552 [1]   O-RING
19 8101484 [1]   PIPE
20 J901280 [8]   BOLT
21 A590112 [8]   WASHER;PLANE
22 A810050 [1]   O-RING
23 4093624 [1]   PLUG
23A. 957366 [1]   O-RING
25 3104158 [1]   BLOCK
26 966993 [1]   O-RING
Parts on group PUMP;PISTON:
Pos. Part No Qty Parts name Comments
4635645 [1]   PUMP;PISTON This PART NO. consists of all parts shown in PUMP;UNIT and PUMP;REGULATOR.
01 4661507 [1]   PUMP;REGULATOR
011 0718001 [1]   PISTON ASS'Y
011A. +++++++ [9]   PISTON
011B. +++++++ [9]   SHOE
014 0703002 [1]   CYL. ASS'Y
014A. +++++++ [1]   BLOCK;CYL.
014B. +++++++ [1]   PLATE;VALVE
030 0716801 [1]   PLATE ASS'Y
030A. +++++++ [1]   PLATE
030B. +++++++ [1]   BUSHING
0111 0682301 [1]   SHAFT;DRIVE
0123 0682302 [1]   BRG.;ROL.
124 0682303 [1]   BRG.;NEEDLE
127 0339809 [1]   SPACER
130 0682304 [1]   BOOSTER
153 0718002 [1]   RETAINER
156 0828401 [1]   BUSHING
157 0682307 [9]   SPRING
211 0682309 [1]   PLATE
251 0981101 [1]   SUPPORT
261 0682311 [1]   COVER
263 0981102 [1]   COVER
271 0800703 [1]   CASING
312 0682314 [1]   COVER
325 0682315 [1]   COVER
401 0682316 [4]   BOLT;SOCKET
403 0111530 [6]   BOLT;SOCKET
406 M340820 [4]   BOLT;SOCKET
408 0102411 [3]   BOLT;SOCKET
466 0236014 [2]   PLUG
468 0175233 [2]   PLUG
490 0263019 [27]   PLUG
491 0451027 [2]   SCREW
492 0451028 [2]   PLUG
530 0800706 [1]   PIN ASS'Y
530A. +++++++ [1]   PIN
530B. +++++++ [1]   PIN
532 0800707 [1]   PISTON;SERVO
534 0682319 [1]   STOPPER
535 0682320 [1]   STOPPER
702 4292386 [1]   O-RING
706 0443413 [1]   O-RING
710 0682321 [1]   O-RING
717 0682322 [2]   O-RING
719 0682323 [1]   O-RING
724 0443801 [10]   O-RING
725 4297379 [4]   O-RING
728 0443408 [2]   O-RING
732 0682324 [1]   O-RING
774 0682325 [1]   SEAL;OIL
789 0682326 [1]   RING;BACK-UP
792 0682327 [1]   RING;BACK-UP
808 0451038 [2]   NUT
824 960323 [1]   RING;RETAINING
885 0313404 [1]   PIN
887 4144353 [2]   PIN;SPRING
901 0134458 [2]   BOLT;EYE
953 0339847 [1]   SCREW
954 0682328 [1]   SCREW;SET
981 +++++++ [1]   PLATE
983 0625509 [2]   PIN
Parts on group PUMP MISSION:
Pos. Part No Qty Parts name Comments
9249786 [1]   PUMP;MISSION I 9276421
9276421 [1]   PUMP;MISSION
0 0005271 [1]   CASE;MISSION
02 2052159 [1]   GEAR
04 4160773 [3]   BRG.;BALL
06 3104841 [1]   COUPLING
07 4116290 [2]   RING;RETAINING
09 2052164 [1]   CARTRIDGE
10 4443632 [1]   O-RING
11 J271235 [10]   BOLT;SEMS
11A. J901235 [1]   BOLT
11B. J222012 [1]   WASHER
12 M342071 [8]   BOLT;SOCKET
14 4641671 [1]   SEAL;OIL
15 2052160 [2]   GEAR
18 2052165 [2]   CARTRIDGE
19 4637148 [2]   O-RING
20 4153532 [1]   O-RING
23 4651440 [1]   GAUGE;LEVEL
25 8103382 [1]   PIPE
27 M341036 [4]   BOLT;SOCKET
30 4174542 [1]   PLUG
30A. 4506424 [1]   O-RING
31 4174542 [3]   PLUG
31A. 4506424 [1]   O-RING
37 4187328 [1]   O-RING
38 A853368 [1]   ELBOW;S
38A. 4506424 [1]   O-RING
42 4472548 [2]   BRG.;BALL
43 4472549 [1]   BRG.;BALL
45 +++++++ [1]   NAME-PLATE
46 M492564 [2]   SCREW;DRIVE
47 4298488 [1]   BREATHER;AIR I 4722534
47 4722534 [1]   BREATHER;AIR
49 8092124 [1]   PIPE I 8104650
49 8104650 [1]   PIPE
Parts on group REGULATOR;PUMP:
Pos. Part No Qty Parts name Comments
4661507 [1]   PUMP;REGULATOR This PART NO. consists of all parts shown in PUMP;UNIT and PUMP;REGULATOR.
041 0708004 [2]   VALVE;CHECK ASS'Y
041A. +++++++ [1]   SEAT
041B. +++++++ [1]   STOPPER
041C. +++++++ [1]   BALL;STEEL
079 4469585 [1]   VALVE;REDUCING
325 +++++++ [1]   CASING
402 0237902 [4]   BOLT;SOCKET
407 0211510 [4]   BOLT;SOCKET
408 M340640 [1]   BOLT;SOCKET
415 0135904 [6]   BOLT;SOCKET
418 0667626 [2]   BOLT;SOCKET
466 0878301 [1]   PLUG
496 0263019 [9]   PLUG
601 +++++++ [1]   CASING
611 +++++++ [1]   LEVER
614 +++++++ [1]   PLUG
624 +++++++ [1]   SEAT;SPRING
627 +++++++ [1]   STEM;ADJUST
631 +++++++ [1]   SLEEVE
643 +++++++ [1]   PIN
646 +++++++ [1]   SPRING
651 +++++++ [1]   SLEEVE
652 +++++++ [1]   SPOOL
656 +++++++ [1]   COVER
708 0682502 [1]   O-RING
724 0443801 [5]   O-RING
731 0703101 [1]   O-RING
733 0443803 [2]   O-RING
755 4297379 [1]   O-RING
756 0703102 [2]   O-RING
757 0443406 [1]   O-RING
801 0156009 [1]   NUT
887 +++++++ [1]   PIN
897 +++++++ [1]   PIN
924 0828501 [1]   SCREW
