HITACHI EX1200-5 EX1200-5C EX1200-5D EX2500-5 EX2500-6 EXCAVATOR 4438786 4474766 4474886 HYDRAULIC MOTOR ROTARY GROUP AND SPARE PARTS

HITACHI EX1200-5 EX1200-5C EX1200-5D EX2500-5 EX2500-6 EXCAVATOR 4438786 4474766 4474886 HYDRAULIC MOTOR ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
4438786
4474766 4474886
EX1200-5 EX1200-5C EX1200-5D EX2500-5 EX2500-6
Pos. Part No Qty Parts name Comments
4438786 [1]   MOTOR;OIL
1 4474766 [1]   MOTOR;PISTON
1-1. 4474886 [1]   MOTOR;PISTON
1-4. 0833801 [2]   FLANGE
1-5. 4299297 [1]   PLUG
1-6. 0833802 [8]   BOLT;SOCKET
1-9. 0624503 [2]   O-RING
1-10. +++++++ [1]   NAME-PLATE
2 4474767 [1]   VALVE-BLOCK
Parts on group MOTOR;PISTON:
Pos. Part No Qty Parts name Comments
4474886 [1]   MOTOR;PISTON
1 4474887 [1]   ROTARY GROUP
3 0833901 [1]   HOUSING
4 0833902 [1]   COVER
5 0833903 [1]   PIN
6 0628207 [1]   O-RING
7 0295007 [2]   BOLT;SOCKET
10 0234905 [4]   BOLT;SOCKET
Parts on group ROTARY GROUP:
Pos. Part No Qty Parts name Comments
4474887 [1]   ROTARY GROUP
1 +++++++ [1]   ROTOR
2 +++++++ [1]   SHAFT
3 +++++++ [1]   CASE
4 0834001 [1]   SEAL;CASE
5 +++++++ [1]   SHIM
7 +++++++ [1]   PLATE
9 0834002 [1]   RING;RETAINING
10 +++++++ [1]   BRG.
11 +++++++ [1]   BRG.
13 0834003 [1]   RING;RETAINING
14 0312102 [1]   SEAL;OIL
15 4367827 [1]   O-RING
17 +++++++ [2]   SHIM 0.1
18 +++++++ [1]   SHIM 0.3
20 +++++++ [7]   SCREW
21 +++++++ [1]   KEY
100 4662205 [1]   KIT;SEAL
Parts on group VALVE-BLOCK:
Pos. Part No Qty Parts name Comments
4474767 [1]   VALVE-BLOCK
1 +++++++ [1]   BODY
2 +++++++ [1]   PLUNGER
3 +++++++ [1]   PLUG
4 0724603 [1]   SPRING
5 +++++++ [2]   PLUG
6 0645506 [6]   BOLT;SOCKET
7 0624504 [2]   PLUG
8 0389321 [2]   O-RING
9 0834201 [1]   O-RING
10 0624503 [2]   O-RING
11 0724605 [1]   VALVE;RELIEF
12 +++++++ [1]   NAME-PLATE
13 +++++++ [2]   SCREW;DRIVE
