HITACHI 9256125 9257348 HYDRAULIC PUMP PARTS

Name: HITACHI 9256125 9257348 HYDRAULIC PUMP PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

HITACHI 9256125 9257348 HYDRAULIC PUMP PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

9256125 9257348 ZX240-3 ZX240-3-AMS ZX240-3-HCMC ZX240-3F ZX240N-3F-HCME ZX240N-3FAMS ZX250-3-AMS ZX250H-3 ZX250H-3-HCMC ZX250H-3F ZX250K-3 ZX250K-3F ZX250LC-3-HCMC ZX250LC-3-HCME ZX250LC-3F-HCME ZX250LCN-3FAMS ZX250LCN-3FHCME

Pos.	Part No	Qty	Parts name	Comments
	9256125	[1]	PUMP DEVICE
	9257348	[1]	PUMP DEVICE
1	1033158	[1]	CASING;GEAR
5	3063840	[1]	GEAR;PILOT
6	3055594	[1]	SHAFT;GEAR
10	958740	[2]	BRG.;BALL
11	962002	[1]	RING;RETAINING
12	991725	[1]	RING;RETAINING
34	4099290	[2]	PIN;SPRING
43	4310055	[1]	SEAL;OIL
44	991725	[1]	RING;RETAINING
61	4438059	[1]	GAUGE;LEVEL
62	9743977	[1]	PIPE;GAUGE
63	9742779	[1]	PACKING
64	M340816	[2]	BOLT;SOCKET
83	94-0649	[1]	ELBOW
84	4645330	[1]	PLUG
86	4234782	[1]	PLUG
87	4092534	[1]	PLUG
87A.	4509180	[1]	O-RING
103	+++++++	[1]	PUMP;UNIT
112	+++++++	[1]	NAME-PLATE
113	M492564	[2]	SCREW;DRIVE
117	9256847	[1]	PUMP;REGULATOR (1)
118	9256848	[1]	PUMP;REGULATOR (2)
119	9218005	[1]	PUMP;GEAR
121	M341030	[2]	BOLT;SOCKET
122	984054	[2]	WASHER;SPRING
123	4114402	[2]	WASHER
127	4631943	[1]	PIPE
130	4293950	[2]	ELBOW;S
130A.	957366	[1]	O-RING
133	4641504	[1]	COUPLING
133A.	4463992	[1]	HUB
133B.	4334899	[2]	SCREW;SET
133C.	4101345	[4]	PIN;SPRING
133D.	4463993	[4]	INSERT
133E.	4334894	[4]	BOLT;SOCKET
133F.	4654760	[1]	ELEMENT
136	8058352	[1]	PACKING
137	J901645	[6]	BOLT
138	A590916	[6]	WASHER;SPRING
200	4451036	[1]	KIT;SEAL
ZX240-3 ZX250H-3 ZX250K-3 ZX250LC-3 ZX250LCN-3

Pos.	Part No	Qty	Parts name	Comments
	+++++++	[1]	PUMP;UNIT
0	1032319	[1]	CASING;PUMP
2	2052079	[1]	DISC;DRIVING
5	2052080	[1]	DISC;DRIVING
9	4178173	[2]	NUT;BRG.
10	4338907	[1]	RING;THRUST
11	4410050	[2]	BRG.;ROL.
12	4333170	[2]	SEAL;OIL
13	4116290	[2]	RING;RETAINING
14	4339171	[2]	RING
15	4233165	[1]	PLUG
16	957366	[1]	O-RING
17	4622945	[2]	BRG.;ROL.
19	8050658	[14]	PISTON
21	4337035	[2]	SHAFT;CENTER
22	4198956	[2]	PIN
23	4179181	[2]	SPRING;COMPRES.
25	2052956	[2]	ROTOR
27	2052073	[1]	VALVE
28	2052067	[1]	VALVE
29	4179179	[4]	PIN
31	3104058	[2]	LINK
32	9724756	[4]	LEVER
33	4179177	[4]	PIN
34	4179176	[2]	PIN
35	4146370	[12]	RING;RETAINING
36	4200227	[2]	PIN
41	1032517	[1]	HEAD
42	3069541	[2]	PISTON;SERVO
43	4338053	[2]	PIN
44	4337812	[2]	SCREW;SET
46	4355085	[2]	O-RING
47	4338060	[2]	STOPPER
50	4355083	[2]	O-RING
51	4338061	[2]	STOPPER
54	4180349	[20]	O-RING
55	M340825	[16]	BOLT;SOCKET
57	3070581	[1]	RING;BACKUP
58	4099290	[2]	PIN;SPRING
59	4342840	[1]	O-RING
60	M341245	[12]	BOLT;SOCKET
65	4436271	[2]	SENSOR;PRES.
65A.	4365826	[1]	O-RING
67	9134110	[2]	PLUG
67A.	957366	[1]	O-RING
72	4515041	[4]	PIN;SPRING
73	4343074	[4]	O-RING
74	4348665	[2]	O-RING
79	4274552	[2]	RING;RETAINING
80	9134111	[2]	PLUG
80A.	4509180	[1]	O-RING
89	3100993	[1]	GEAR
90	3100994	[1]	GEAR
100	4451039	[1]	KIT;SEAL
Parts on group PUMP DEVICE <240>:

Pos.	Part No	Qty	Parts name	Comments
0	+++++++	[1]	PUMP ASS'Y	(for assembly of machine)
0	+++++++	[1]	PUMP DEVICE	(for transportation)
00A.	9256125	[1]	PUMP ASS'Y	I 9257348
00B.	4668180	[1]	PUMP;GEAR
00C.	4677898	[1]	KIT;SEAL
00D.	3092248	[1]	SHAFT;GEAR
Parts on group PUMP;REGULATOR (1):

Pos.	Part No	Qty	Parts name	Comments
	9256847	[1]	PUMP;REGULATOR (1)
1	1033182	[1]	CASING;REG.
2	4179155	[1]	SLEEVE
3	4179156	[1]	SPOOL
5	4375722	[1]	CYL.;LOAD
6	4360590	[1]	PISTON
7	4150302	[1]	O-RING
8	4085607	[1]	RING;BACK-UP
9	4297380	[1]	O-RING
10	4368619	[1]	STOPPER
12	4179161	[2]	STOPPER
14	4342843	[3]	O-RING
15	4342841	[2]	O-RING
16	4068898	[2]	NUT
17	M500807	[2]	NUT
20	4179171	[1]	PISTON
22	4451498	[1]	CYL.
24	4347107	[1]	STOPPER;INNER
27	4346522	[1]	SLEEVE
28	4346521	[1]	SPOOL
29	4265964	[1]	SCREW;SET
34	J950010	[1]	NUT
35	3103629	[1]	COVER;REAR
36	4611012	[1]	PISTON
37	M340820	[8]	BOLT;SOCKET
38	4433327	[1]	COVER
39	4447264	[1]	PLUG
41	4342846	[1]	O-RING
43	M341056	[4]	BOLT;SOCKET
47	4616531	[1]	SPRING;COMPRES.
48	4616533	[1]	SPRING;COMPRES.
49	4350928	[1]	SPRING;COMPRES.
52	4436536	[1]	SENSOR;PRES.
52A.	4153095	[1]	O-RING
58	9134110	[1]	PLUG
58A.	957366	[1]	O-RING
100	4455719	[1]	KIT;SEAL
Parts on group PUMP;REGULATOR (2):

Pos.	Part No	Qty	Parts name	Comments
	9256848	[1]	PUMP;REGULATOR (2)
1	1026282	[1]	CASING
2	4179155	[1]	SLEEVE
3	4179156	[1]	SPOOL
5	4375722	[1]	CYL.;LOAD
6	4360590	[1]	PISTON
7	4150302	[1]	O-RING
8	4085607	[1]	RING;BACK-UP
9	4297380	[1]	O-RING
10	4368619	[1]	STOPPER
12	4179161	[2]	STOPPER
14	4342843	[3]	O-RING
15	4342841	[2]	O-RING
16	4068898	[2]	NUT
17	M500807	[2]	NUT
20	4179171	[1]	PISTON
22	4451498	[1]	CYL.
24	4347107	[1]	STOPPER;INNER
27	4346522	[1]	SLEEVE
28	4346521	[1]	SPOOL
29	4265964	[1]	SCREW;SET
34	J950010	[1]	NUT
35	3103629	[1]	COVER;REAR
36	4611012	[1]	PISTON
37	M340820	[8]	BOLT;SOCKET
38	4433327	[1]	COVER
43	M341056	[2]	BOLT;SOCKET
47	4616531	[1]	SPRING;COMPRES.
48	4616533	[1]	SPRING;COMPRES.
49	4350928	[1]	SPRING;COMPRES.
50	9254306	[1]	VALVE;SOLENOID
50A.	4150302	[1]	O-RING
50B.	4153534	[1]	O-RING
50C.	4153087	[1]	O-RING
52	M341080	[2]	BOLT;SOCKET
53	M341030	[2]	BOLT;SOCKET
55	4436536	[1]	SENSOR;PRES.
55A.	4153095	[1]	O-RING
57	4174541	[1]	PLUG
57A.	4506418	[1]	O-RING
59	4629372	[1]	PIPE
60	4255304	[1]	FITTING;PIPE
60A.	957366	[1]	O-RING
61	4293950	[1]	ELBOW;S
61A.	957366	[1]	O-RING
100	4455733	[1]	KIT;SEAL
Parts on group PUMP;GEAR:

Pos.	Part No	Qty	Parts name	Comments
	9218005	[1]	PUMP;GEAR
1	+++++++	[1]	HOUSING
2	2050209	[1]	FLANGE
3	3097272	[1]	SEAL;OIL
5	447068	[1]	RING;RETAINING
6	1031045	[2]	SEAL
7	4605732	[1]	COVER
9	4487250	[2]	RING;BACK-UP
10	4484119	[2]	KEY
12	4488720	[2]	O-RING
13	+++++++	[1]	GEAR
14	+++++++	[1]	GEAR
15	4605742	[4]	WASHER
16	4605670	[4]	BOLT
26	+++++++	[2]	BUSH
27	+++++++	[2]	BUSH
28	400613	[4]	PIN
100	4487340	[1]	KIT;SEAL
