HITACHI 9242907 9257553 9243839 9256989 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

HITACHI 9242907 9257553 9243839 9256989 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
9242907 9257553 OIL MOTOR
9243839 9256989 TRAVEL DEVICE
ZX200 ZX240-3 ZX240-3-HCMC ZX240-3G ZX240-5G ZX240LC-3G ZX240LC-5G ZX250H-3 ZX250H-3G ZX250H-5G ZX250K-3 ZX250K-3G ZX250K-5G ZX250LC-3-HCMC ZX250LC-3-HCME ZX250LC-3G ZX250LC-5B ZX250LCH-5G ZX250LCK-5G ZX250LCN-5B ZX260LCH-3G
Pos. Part No Qty Parts name Comments
9242907 [1]   MOTOR;OIL
9257553 [1]   MOTOR;OIL
00 1031123 [1]   HOUSING
01 4613831 [1]   SEAL;OIL
03 4601724 [1]   PISTON
07 2049166 [1]   SHAFT
08 959499 [1]   RING;RETAINING
09 4600108 [2]   PIN
10 4600133 [1]   BRG.;ROL.
14 8099321 [9]   PISTON
16 3081570 [1]   RETAINER
17 4397757 [1]   BUSHING
18 2050565 [1]   PLATE;SWASH
19 4396747 [6]   SPRING;COMPRES.
21 2051451 [1]   ROTOR
22 3081593 [4]   PLATE;FRICTION
23 3081592 [4]   PLATE
25 3081595 [1]   PISTON
26 4396775 [1]   O-RING
28 4396774 [1]   O-RING
29 3081594 [1]   SPRING;DISC
30 4420958 [1]   O-RING
31 4506415 [2]   O-RING
32 9247662 [1]   VALVE;BRAKE
32 9260003 [1]   VALVE;BRAKE
33 4631910 [1]   BRG.;NEEDLE
37 4630921 [2]   PIN;KNOCK
39 3106481 [1]   PLATE;VALVE
40 M341850 [9]   BOLT;SOCKET
Parts on group VALVE;BRAKE:
Pos. Part No Qty Parts name Comments
9247662 [1]   VALVE;BRAKE I 9260003 <for assembly of machine>
-9260003 [1]   VALVE;BRAKE <for transportation>
01 8099406 [1]   CASING ASSY
01A. +++++++ [1]   CASING
01B. +++++++ [1]   SPOOL
01C. +++++++ [1]   SPOOL
02 4602024 [2]   STOPPER;SPOOL
03 4409389 [2]   SPRING;COMPRES.
05 4229631 [2]   PLUG
07 4506429 [2]   O-RING
08 4397022 [2]   POPPET;CHECK
10 4396771 [2]   SPRING;COMPRES.
11 4509493 [1]   BALL
13 4398281 [1]   SEAT
15 9185757 [2]   VALVE;RELIEF
16 4297257 [1]   SPRING;COMPRES.
17 9167977 [1]   PLUG
17A. 957366 [1]   O-RING
20 9134112 [1]   PLUG
20A. 4506418 [1]   O-RING
22 9134110 [4]   PLUG
22A. 957366 [1]   O-RING
23 9134109 [1]   PLUG
23A. 4506408 [1]   O-RING
25 4050968 [3]   PLUG
Parts on group VALVE;RELIEF:
Pos. Part No Qty Parts name Comments
01 9185757 [1]   VALVE;RELIEF
02 4506418 [1]   O-RING
04 4033725 [2]   RING;BACK-UP
16 4506429 [1]   O-RING
