HITACHI 9228435 9291582 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

HITACHI 9228435 9291582 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
9228435 9291582
ZX70-3 ZX70-3-HCME ZX75UR-3 ZX75US-3 ZX75USK-3 ZX80LCK-3 ZX85US-3 ZX85USB-3 ZX85USB-3-HCME ZX85USBN-3-HCME
Pos. Part No Qty Parts name Comments
9228435 [1]   MOTOR;OIL I 9291582 <for assembly of machine>
-9291582 [1]   MOTOR;OIL <for transportation>
1 1033855 [1]   HOUSING
2 4434402 [1]   SEAL;OIL
4 4441707 [1]   PISTON
5 3088756 [1]   SHAFT
7 4434047 [1]   BRG.;BALL
11 3088758 [9]   PISTON
12 3101178 [1]   PLATE;SWASH
13 4434042 [1]   RETAINER
14 4434041 [1]   BUSHING
15 4652336 [2]   BALL
16 4312681 [6]   SPRING;COMPRES.
17 2044951 [1]   ROTOR
19 4434043 [3]   PLATE;FRICTION
20 4434044 [3]   PLATE
22 3088757 [1]   PISTON
23 4434403 [1]   O-RING
25 4434404 [1]   O-RING
26 4434046 [1]   SPRING;DISC
28 4434405 [1]   O-RING
29 4506412 [2]   O-RING
32 4434048 [1]   BRG.;ROL.
33 9298818 [1]   VALVE;BRAKE
34 3089171 [1]   PLATE;VALVE
36 4615617 [6]   BOLT;SOCKET
Parts on group VALVE;BRAKE:
Pos. Part No Qty Parts name Comments
9298818 [1]   VALVE;BRAKE I 9299533 <for assembly of machine>
-9299533 [1]   VALVE;BRAKE <for transportation>
02 8116517 [1]   CASING ASS'Y
02A. +++++++ [1]   CASING;REAR
02B. +++++++ [1]   SPOOL
02C. +++++++ [1]   SPOOL
03 4434407 [2]   STOPPER;SPOOL
04 4434408 [2]   SPRING;COMPRES.
06 4434406 [2]   PLUG
07 4506424 [2]   O-RING
09 4509493 [1]   BALL
10 4193400 [1]   PLUG
12 4443372 [2]   POPPET
13 4434410 [2]   SPRING;COMPRES.
16 9264412 [2]   VALVE;RELIEF
17 4096496 [1]   NEEDLE
18 4443685 [1]   SPRING;COMPRES.
19 9167977 [1]   PLUG
19A. 957366 [1]   O-RING
20 4368621 [1]   ADAPTER;S
20A. 957366 [1]   O-RING
22 9134111 [1]   PLUG
22A. 4509180 [1]   O-RING
23 9134110 [2]   PLUG
23A. 957366 [1]   O-RING
24 9134109 [2]   PLUG
24A. 4506408 [1]   O-RING
25 4050968 [2]   PLUG
27 988975 [1]   PIN;SPRING
29 4446283 [1]   POPPET
30 4398846 [1]   SPRING;COMPRES.
Parts on group TRAVEL DEVICE:
Pos. Part No Qty Parts name Comments
0 9272927 [2]   TRAVEL DEVICE ASS'Y I 9290866 (for assembly of machine)
0 9290866 [2]   TRAVEL DEVICE ASS'Y (for transportation)
0 9228435 [1]   TRAVEL DEVICE ASS'Y I 9291582 (for assembly of machine)
0 9291582 [1]   TRAVEL DEVICE ASS'Y (for transportation)
