HITACHI 9213431 9231673 TRAVEL MOTOR ROTARY GROUP

HITACHI 9213431 9231673 TRAVEL MOTOR ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
9213431 9231673
ZX330 ZX330-HHE ZX350H ZX350K ZX350LC-AMS ZX370MTH
Pos. Part No Qty Parts name Comments
9213431 [1]   MOTOR;OIL I 9231673 <for assembly of machine>
9231673 [1]   MOTOR;OIL <for transportation>
00 4501 [1]   HOUSING
02 4396696 [1]   SEAL;OIL
03 4355728 [2]   BALL
05 4462038 [1]   PISTON
06 4475147 [1]   SPRING;COMPRES.
08 2047884 [1]   SHAFT
09 4396755 [1]   BRG.;ROL.
11 991345 [1]   RING;RETAINING
12 959501 [1]   RING;RETAINING
14 3094361 [1]   PLATE;SWASH Y 3106086
14 3106086 [1]   PLATE;SWASH
15 2047885 [1]   ROTOR T 2052854
8100811
3103258
15 2052854 [1]   ROTOR
17 4468258 [6]   SPRING;COMPRES.
18 4461908 [1]   BUSHING I 4627480
18 4627480 [1]   BUSHING I 4642740
18 4642740 [1]   BUSHING
20 3094362 [1]   RETAINER T 3103491
4627480
20 3103491 [1]   RETAINER I 3094362
20 3094362 [1]   RETAINER
21 8092512 [9]   PISTON T 2052854
8100811
3103258
21 8100811 [9]   PISTON
23 3096779 [4]   PLATE;FRICTION
24 3094376 [4]   PLATE
26 3094377 [1]   PISTON
27 4468248 [1]   O-RING
29 4468249 [1]   O-RING
30 4468250 [1]   SPRING;DISC
32 4506415 [2]   O-RING
33 9213241 [1]   VALVE;BRAKE I 9264410 <for assembly of machine>
33 -9229962 [1]   VALVE;BRAKE <for transportation>
33 9263854 [1]   VALVE;BRAKE I 9264410 <for assembly of machine>
33 -9264410 [1]   VALVE;BRAKE <for transportation>
35 4472355 [1]   BRG.;NEEDLE
36 4461910 [1]   PIN;KNOCK
38 3098526 [1]   PLATE;VALVE I 3103022
38 3103022 [1]   PLATE;VALVE T 2052854
8100811
3103258
38 3103258 [1]   PLATE;VALVE
39 4468244 [1]   O-RING
41 M342056 [8]   BOLT;SOCKET
42 9134112 [1]   PLUG
42A. 4506418 [1]   O-RING
Parts on group VALVE;BRAKE:
Pos. Part No Qty Parts name Comments
9213241 [1]   VALVE;BRAKE I 9229962 <for assembly of machine>
-9229962 [1]   VALVE;BRAKE <for transportation>
01 8087943 [1]   CASING ASS'Y
01A. +++++++ [1]   CASING;REAR
01B. +++++++ [1]   SPOOL
01C. +++++++ [1]   SPOOL
02 4461905 [2]   STOPPER
05 4276526 [2]   PLUG
06 4485473 [2]   SPRING;COMPRES.
07 4506429 [2]   O-RING
08 4470238 [2]   POPPET
10 4396771 [2]   SPRING;COMPRES.
11 4509493 [1]   BALL
13 4311662 [1]   SEAT
14 9213855 [2]   VALVE;RELIEF
16 4297257 [1]   SPRING;COMPRES.
17 9167977 [1]   PLUG
17A. 957366 [1]   O-RING
19 4050968 [2]   PLUG
21 9089484 [2]   PLUG
21A. 4506408 [1]   O-RING
23 9089485 [3]   PLUG
23A. 957366 [1]   O-RING
Parts on group VALVE;BRAKE:
Pos. Part No Qty Parts name Comments
9263854 [1]   VALVE;BRAKE I 9264410 <for assembly of machine>
-9264410 [1]   VALVE;BRAKE <for transportation>
01 8104695 [1]   CASING ASS'Y
01A. +++++++ [1]   CASING;REAR
01B. +++++++ [1]   SPOOL
01C. +++++++ [1]   SPOOL
02 4461905 [2]   STOPPER
05 4276526 [2]   PLUG
06 4485473 [2]   SPRING;COMPRES.
07 4506429 [2]   O-RING
08 4470238 [2]   POPPET
10 4396771 [2]   SPRING;COMPRES.
11 4509493 [1]   BALL
13 4311662 [1]   SEAT
14 9213855 [2]   VALVE;RELIEF
16 4297257 [1]   SPRING;COMPRES.
17 9167977 [1]   PLUG
17A. 957366 [1]   O-RING
19 4050968 [2]   PLUG
21 9089484 [2]   PLUG
21A. 4506408 [1]   O-RING
23 9089485 [3]   PLUG
23A. 957366 [1]   O-RING
Parts on group VALVE;RELIEF:
Pos. Part No Qty Parts name Comments
9213855 [2]   VALVE;RELIEF
1 3095161 [1]   SLEEVE
2 4506418 [1]   O-RING
4 4033725 [2]   RING;BACK-UP
5 9758777 [1]   CARTRIDGE
05A. +++++++ [1]   CARTRIDGE
05B. +++++++ [1]   POPPET
7 4473064 [1]   GUIDE;SPRING
8 4396836 [1]   SPRING;COMPRES.
10 4506420 [1]   O-RING
11 4027959 [2]   RING;BACK-UP
13 4462422 [1]   PISTON
14 4473080 [1]   PLUG;RELIEF
16 4506429 [1]   O-RING
17 A590103 [1]   WASHER;PLANE
