HITACHI 9213431 9231673 TRAVEL MOTOR PARTS

Name: HITACHI 9213431 9231673 TRAVEL MOTOR PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

HITACHI 9213431 9231673 TRAVEL MOTOR PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

9213431 9231673 ZX330 ZX330-HHE ZX350H ZX350K ZX350LC-AMS ZX370MTH

Pos.	Part No	Qty	Parts name	Comments
	9213431	[1]	MOTOR;OIL	I 9231673 <for assembly of machine>
	9231673	[1]	MOTOR;OIL	<for transportation>
00	4501	[1]	HOUSING
02	4396696	[1]	SEAL;OIL
03	4355728	[2]	BALL
05	4462038	[1]	PISTON
06	4475147	[1]	SPRING;COMPRES.
08	2047884	[1]	SHAFT
09	4396755	[1]	BRG.;ROL.
11	991345	[1]	RING;RETAINING
12	959501	[1]	RING;RETAINING
14	3094361	[1]	PLATE;SWASH	Y 3106086
14	3106086	[1]	PLATE;SWASH
15	2047885	[1]	ROTOR	T 2052854
				8100811
				3103258
15	2052854	[1]	ROTOR


17	4468258	[6]	SPRING;COMPRES.
18	4461908	[1]	BUSHING	I 4627480
18	4627480	[1]	BUSHING	I 4642740
18	4642740	[1]	BUSHING
20	3094362	[1]	RETAINER	T 3103491
				4627480
20	3103491	[1]	RETAINER	I 3094362
20	3094362	[1]	RETAINER
21	8092512	[9]	PISTON	T 2052854
				8100811
				3103258
21	8100811	[9]	PISTON


23	3096779	[4]	PLATE;FRICTION
24	3094376	[4]	PLATE
26	3094377	[1]	PISTON
27	4468248	[1]	O-RING
29	4468249	[1]	O-RING
30	4468250	[1]	SPRING;DISC
32	4506415	[2]	O-RING
33	9213241	[1]	VALVE;BRAKE	I 9264410 <for assembly of machine>


33	-9229962	[1]	VALVE;BRAKE	<for transportation>


33	9263854	[1]	VALVE;BRAKE	I 9264410 <for assembly of machine>


33	-9264410	[1]	VALVE;BRAKE	<for transportation>


35	4472355	[1]	BRG.;NEEDLE
36	4461910	[1]	PIN;KNOCK
38	3098526	[1]	PLATE;VALVE	I 3103022
38	3103022	[1]	PLATE;VALVE	T 2052854
				8100811
				3103258
38	3103258	[1]	PLATE;VALVE


39	4468244	[1]	O-RING
41	M342056	[8]	BOLT;SOCKET
42	9134112	[1]	PLUG
42A.	4506418	[1]	O-RING
Parts on group VALVE;BRAKE:

Pos.	Part No	Qty	Parts name	Comments
	9213241	[1]	VALVE;BRAKE	I 9229962 <for assembly of machine>
	-9229962	[1]	VALVE;BRAKE	<for transportation>
01	8087943	[1]	CASING ASS'Y
01A.	+++++++	[1]	CASING;REAR
01B.	+++++++	[1]	SPOOL
01C.	+++++++	[1]	SPOOL
02	4461905	[2]	STOPPER
05	4276526	[2]	PLUG
06	4485473	[2]	SPRING;COMPRES.
07	4506429	[2]	O-RING
08	4470238	[2]	POPPET
10	4396771	[2]	SPRING;COMPRES.
11	4509493	[1]	BALL
13	4311662	[1]	SEAT
14	9213855	[2]	VALVE;RELIEF
16	4297257	[1]	SPRING;COMPRES.
17	9167977	[1]	PLUG
17A.	957366	[1]	O-RING
19	4050968	[2]	PLUG
21	9089484	[2]	PLUG
21A.	4506408	[1]	O-RING
23	9089485	[3]	PLUG
23A.	957366	[1]	O-RING
Parts on group VALVE;BRAKE:

Pos.	Part No	Qty	Parts name	Comments
	9263854	[1]	VALVE;BRAKE	I 9264410 <for assembly of machine>
	-9264410	[1]	VALVE;BRAKE	<for transportation>
01	8104695	[1]	CASING ASS'Y
01A.	+++++++	[1]	CASING;REAR
01B.	+++++++	[1]	SPOOL
01C.	+++++++	[1]	SPOOL
02	4461905	[2]	STOPPER
05	4276526	[2]	PLUG
06	4485473	[2]	SPRING;COMPRES.
07	4506429	[2]	O-RING
08	4470238	[2]	POPPET
10	4396771	[2]	SPRING;COMPRES.
11	4509493	[1]	BALL
13	4311662	[1]	SEAT
14	9213855	[2]	VALVE;RELIEF
16	4297257	[1]	SPRING;COMPRES.
17	9167977	[1]	PLUG
17A.	957366	[1]	O-RING
19	4050968	[2]	PLUG
21	9089484	[2]	PLUG
21A.	4506408	[1]	O-RING
23	9089485	[3]	PLUG
23A.	957366	[1]	O-RING
Parts on group VALVE;RELIEF:

Pos.	Part No	Qty	Parts name	Comments
	9213855	[2]	VALVE;RELIEF
1	3095161	[1]	SLEEVE
2	4506418	[1]	O-RING
4	4033725	[2]	RING;BACK-UP
5	9758777	[1]	CARTRIDGE
05A.	+++++++	[1]	CARTRIDGE
05B.	+++++++	[1]	POPPET
7	4473064	[1]	GUIDE;SPRING
8	4396836	[1]	SPRING;COMPRES.
10	4506420	[1]	O-RING
11	4027959	[2]	RING;BACK-UP
13	4462422	[1]	PISTON
14	4473080	[1]	PLUG;RELIEF
16	4506429	[1]	O-RING
17	A590103	[1]	WASHER;PLANE
