HITACHI 9205359 9205360 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

HITACHI 9205359 9205360 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
9205359 9205360
ZX330 ZX350H ZX350K ZX350LC-AMS ZX350LC-HCME ZX370MTH
Pos. Part No Qty Parts name Comments
9205359 [1]   MOTOR;OIL I 9205360 <for assembly of machine>
9205360 [1]   MOTOR;OIL <for transportation>
02 1019564 [1]   CASING;MOTOR
03 2040523 [1]   DISC;DRIVING
06 4199108 [1]   BRG.;ROL.
07 4199072 [1]   BRG.;ROL.
09 4191665 [1]   NUT;BRG.
10 4389598 [1]   SPACER
11 4191666 [1]   SEAL;OIL
12 4038529 [1]   RING;RETAINING
13 2040520 [1]   ROTOR
16 8068583 [7]   PISTON
18 3078298 [1]   SHAFT;CENTER
20 4194362 [1]   SPRING;COMPRES.
21 4198956 [1]   PIN
24 3036457 [4]   PLATE;FRICTION
25 3036456 [5]   PLATE
26 4193996 [1]   SPACER
27 3078190 [1]   PISTON
29 4252401 [1]   D-RING
30 4269474 [1]   D-RING
31 3054505 [1]   SPRING;DISC
33 4269473 [1]   O-RING
34 4506415 [1]   O-RING
35 9157762 [1]   VALVE;BRAKE I 9158391 <for assembly of machine>
35 -9158391 [1]   VALVE;BRAKE <for transportation>
38 M341850 [4]   BOLT;SOCKET
40 2035236 [1]   PLATE
42 4364104 [2]   PIN;KNOCK
44 2040522 [1]   VALVE
46 4234628 [1]   BUSHING
49 4255238 [2]   PLUG
50 2040803 [1]   LINK
51 4262561 [1]   BOLT;REAMER
52 3093136 [1]   PISTON;SERVO
57 4265579 [1]   O-RING
61 9134112 [1]   PLUG
61A. 4506418 [1]   O-RING
62 9134110 [1]   PLUG
62A. 957366 [1]   O-RING
63 9134109 [1]   PLUG
63A. 4506408 [1]   O-RING
64 4332406 [1]   COVER
65 M341225 [4]   BOLT;SOCKET
