HITACHI 9196318 9234159 9237803 FINAL DRIVE TRAVEL MOTOR ROTARY GROUP

HITACHI 9196318 9234159 9237803 FINAL DRIVE TRAVEL MOTOR ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
9196318 9234159
9237803
ZX200 ZX225US ZX225US-E ZX225US-HCME ZX225USR ZX225USR-E ZX225USR-HCME ZX225USRK ZX230 ZX230-HHE ZX240H ZX240K ZX240LC-HHE ZX250-AMS ZX250-HCME ZX450
Pos. Part No Qty Parts name Comments
9234159 [1]   MOTOR;OIL 9196318
9237803 [1]   MOTOR;OIL
0 1031123 [1]   HOUSING
2 4212841 [1]   SEAL;OIL Y 4613831
HMGF40CA:-H004050
HMGF40DA:-H000284
2 4613831 [1]   SEAL;OIL
HMGF40CA:H004051-
HMGF40DA:H000285-
3 4601724 [1]   PISTON
7 2049166 [1]   SHAFT
8 Z959499 [1]   RING;RETAINING
9 4600108 [2]   PIN
10 4600133 [1]   BRG.;ROL.
15 8075190 [9]   PISTON
16 3081570 [1]   RETAINER
17 4397757 [1]   BUSHING
18 2050569 [1]   PLATE;SWASH
19 4396747 [6]   SPRING;COMPRES.
20 2042060 [1]   ROTOR
22 3081593 [4]   PLATE;FRICTION
23 3081592 [4]   PLATE
25 3081595 [1]   PISTON
26 4396775 [1]   O-RING
28 4396774 [1]   O-RING
29 3081594 [1]   SPRING;DISC
30 4420958 [1]   O-RING
31 4506415 [2]   O-RING
34 9234016 [1]   VALVE;BRAKE
34 -9237801 [1]   VALVE;BRAKE
35 4396759 [1]   BRG.;NEEDLE
36 4610452 [2]   PIN;KNOCK
38 3101081 [1]   PLATE;VALVE
40 M341850 [9]   BOLT;SOCKET
Parts on group VALVE;BRAKE:
Pos. Part No Qty Parts name Comments
9234016 [1]   VALVE;BRAKE I 9195450 <for assembly of machine>
-9237801 [1]   VALVE;BRAKE <for transportation>
1 8091818 [1]   CASING ASS'Y
01A. +++++++ [1]   CASING;REAR
01B. +++++++ [1]   SPOOL
01C. +++++++ [1]   SPOOL
2 4602024 [2]   STOPPER;SPOOL
3 4409389 [2]   SPRING;COMPRES.
5 4229631 [2]   PLUG
7 4506429 [2]   O-RING
8 4397022 [2]   POPPET
10 4396771 [2]   SPRING;COMPRES.
11 4509493 [1]   BALL
13 4398281 [1]   SEAT
15 9185757 [2]   VALVE;RELIEF
16 4297257 [1]   SPRING;COMPRES.
17 9167977 [1]   PLUG
17A. 957366 [1]   O-RING
20 9134112 [1]   PLUG
20A. 4506418 [1]   O-RING
22 9134110 [4]   PLUG
22A. 957366 [1]   O-RING
23 9134109 [1]   PLUG
23A. 4506408 [1]   O-RING
25 4050968 [3]   PLUG
