HITACHI 9190296 9195488 TRAVEL MOTOR PARTS

HITACHI 9190296 9195488 TRAVEL MOTOR PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
9190296 9195488
ZX330 ZX330-HHE ZX350H ZX350K ZX350LC-AMS ZX350LC-HCME ZX360LC-HHE ZX370MTH
Pos. Part No Qty Parts name Comments
9190296 [1]   MOTOR;OIL 9195488
-9195488 [1]   MOTOR;OIL
02 1019564 [1]   CASING;MOTOR
03 2040523 [1]   DISC;DRIVING
06 4199108 [1]   BRG.;ROL.
07 4199072 [1]   BRG.;ROL.
09 4191665 [1]   NUT;BRG.
10 4389598 [1]   SPACER
11 4191666 [1]   SEAL;OIL
12 4038529 [1]   RING;RETAINING
13 2040520 [1]   ROTOR
16 8068583 [7]   PISTON
18 3078298 [1]   SHAFT;CENTER
20 4194362 [1]   SPRING;COMPRES.
21 4198956 [1]   PIN
24 3036457 [4]   PLATE;FRICTION
25 3036456 [5]   PLATE
26 4193996 [1]   SPACER
27 3078190 [1]   PISTON
29 4252401 [1]   D-RING
30 4269474 [1]   D-RING
31 3054505 [1]   SPRING;DISC
33 4269473 [1]   O-RING
34 4506415 [1]   O-RING
35 9157762 [1]   VALVE;BRAKE I 9158391 <for assembly of machine>
35 -9158391 [1]   VALVE;BRAKE <for transportation>
38 M341850 [4]   BOLT;SOCKET
40 2035236 [1]   PLATE
42 4364104 [2]   PIN;KNOCK
44 2040522 [1]   VALVE
46 4234628 [1]   BUSHING
49 4255238 [2]   PLUG
50 2040803 [1]   LINK
51 4262561 [1]   BOLT;REAMER
52 9157588 [1]   PISTON;SERVO
55 4260308 [2]   RING;PISTON
57 4265579 [1]   O-RING
61 9134112 [1]   PLUG
61A. 4506418 [1]   O-RING
63 9134109 [1]   PLUG
63A. 4506408 [1]   O-RING
64 4438768 [1]   COVER
65 M341225 [4]   BOLT;SOCKET
Parts on group VALVE;BRAKE:
Pos. Part No Qty Parts name Comments
9157762 [1]   VALVE;BRAKE I 9158391 <for assembly of machine>
9157762 [1]   VALVE;BRAKE I 9158391 <for assembly of machine>
-9158391 [1]   VALVE;BRAKE <for transportation>
-9158391 [1]   VALVE;BRAKE <for transportation>
01 7032724 [1]   CASING
01 7032724 [1]   CASING
01A. +++++++ [1]   HEAD
01A. +++++++ [1]   HEAD
01B. +++++++ [2]   POPPET
01B. +++++++ [2]   POPPET
01C. +++++++ [1]   SPOOL
01C. +++++++ [1]   SPOOL
07 4276785 [2]   SPRING;COMPRES.
07 4276785 [2]   SPRING;COMPRES.
09 4276691 [2]   STOPPER
09 4276691 [2]   STOPPER
11 4276526 [2]   PLUG
11 4276526 [2]   PLUG
12 4506429 [2]   O-RING
12 4506429 [2]   O-RING
16 4365007 [2]   SPRING;COMPRES.
16 4365007 [2]   SPRING;COMPRES.
17 9089488 [2]   PLUG
17 9089488 [2]   PLUG
17A. 4506424 [1]   O-RING
17A. 4506424 [1]   O-RING
21 9134147 [2]   VALVE;RELIEF
21 9134147 [2]   VALVE;RELIEF
23 4354415 [1]   SPOOL
23 4354415 [1]   SPOOL
24 4185136 [1]   SPRING;COMPRES.
24 4185136 [1]   SPRING;COMPRES.
25 9089486 [1]   PLUG
25 9089486 [1]   PLUG
25A. 4509180 [1]   O-RING
25A. 4509180 [1]   O-RING
29 4509493 [2]   BALL
29 4509493 [2]   BALL
30 4311662 [2]   SEAT
30 4311662 [2]   SEAT
33 9089485 [4]   PLUG
33 9089485 [4]   PLUG
33A. 957366 [1]   O-RING
33A. 957366 [1]   O-RING
35 9089484 [10]   PLUG
35 9089484 [10]   PLUG
35A. 4506408 [1]   O-RING
35A. 4506408 [1]   O-RING
Parts on group VALVE;BRAKE:
Pos. Part No Qty Parts name Comments
9157762 [1]   VALVE;BRAKE I 9158391 <for assembly of machine>
9157762 [1]   VALVE;BRAKE I 9158391 <for assembly of machine>
-9158391 [1]   VALVE;BRAKE <for transportation>
-9158391 [1]   VALVE;BRAKE <for transportation>
01 7032724 [1]   CASING
01 7032724 [1]   CASING
01A. +++++++ [1]   HEAD
01A. +++++++ [1]   HEAD
01B. +++++++ [2]   POPPET
01B. +++++++ [2]   POPPET
01C. +++++++ [1]   SPOOL
01C. +++++++ [1]   SPOOL
07 4276785 [2]   SPRING;COMPRES.
07 4276785 [2]   SPRING;COMPRES.
09 4276691 [2]   STOPPER
09 4276691 [2]   STOPPER
11 4276526 [2]   PLUG
11 4276526 [2]   PLUG
12 4506429 [2]   O-RING
12 4506429 [2]   O-RING
16 4365007 [2]   SPRING;COMPRES.
16 4365007 [2]   SPRING;COMPRES.
17 9089488 [2]   PLUG
17 9089488 [2]   PLUG
17A. 4506424 [1]   O-RING
17A. 4506424 [1]   O-RING
21 9134147 [2]   VALVE;RELIEF
21 9134147 [2]   VALVE;RELIEF
23 4354415 [1]   SPOOL
23 4354415 [1]   SPOOL
24 4185136 [1]   SPRING;COMPRES.
24 4185136 [1]   SPRING;COMPRES.
25 9089486 [1]   PLUG
25 9089486 [1]   PLUG
25A. 4509180 [1]   O-RING
25A. 4509180 [1]   O-RING
29 4509493 [2]   BALL
29 4509493 [2]   BALL
30 4311662 [2]   SEAT
30 4311662 [2]   SEAT
33 9089485 [4]   PLUG
33 9089485 [4]   PLUG
33A. 957366 [1]   O-RING
33A. 957366 [1]   O-RING
35 9089484 [10]   PLUG
35 9089484 [10]   PLUG
35A. 4506408 [1]   O-RING
35A. 4506408 [1]   O-RING
