HITACHI 9180779 SWING T.MISSION

HITACHI 9180779 SWING T.MISSION

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
9180779
ZX450 ZX450-3 ZX450-3F ZX450H ZX450H-HHE ZX450LC-3-DH ZX460LCH-AMS ZX460LCH-HCME ZX470H-3 ZX470H-3-HCMC ZX470H-3F ZX470R-3 ZX470R-3F ZX480MT ZX480MTH ZX500LC ZX500LC-3 ZX500LC-3F ZX500LCH ZX500W ZX520LCH-3 ZX520LCH-3F ZX520LCR-3 ZX520LCR-3F
Pos. Part No Qty Parts name Comments
9180779 [1]   T.MISSION (SWING)
9180779 [1]   T.MISSION (SWING)
1 2043694 [1]   SHAFT;PROP.
1 2043694 [1]   SHAFT;PROP.
2 3085412 [1]   SLEEVE
2 3085412 [1]   SLEEVE
3 A811120 [1]   O-RING
3 A811120 [1]   O-RING
4 4402481 [1]   BRG.;ROL.
4 4402481 [1]   BRG.;ROL.
5 1026994 [1]   HOUSING
5 1026994 [1]   HOUSING
6 4422691 [1]   SEAL;OIL
6 4422691 [1]   SEAL;OIL
6 4604376 [1]   SEAL;OIL
6 4604376 [1]   SEAL;OIL
7 4402637 [1]   BRG.;ROL. Y 4667150
7 4402637 [1]   BRG.;ROL. Y 4667150
7 4667150 [1]   BRG.;ROL.
7 4667150 [1]   BRG.;ROL.
8 3086064 [1]   NUT
8 3086064 [1]   NUT
10 J901016 [2]   BOLT
10 J901016 [2]   BOLT
11 1026662 [1]   CARRIER
11 1026662 [1]   CARRIER
12 4187590 [1]   PLATE;THRUST
12 4187590 [1]   PLATE;THRUST
13 9750364 [3]   GEAR;PLANETARY
13 9750364 [3]   GEAR;PLANETARY
14 4336929 [6]   PLATE;THRUST
14 4336929 [6]   PLATE;THRUST
16 4027427 [3]   PIN;SPRING
16 4027427 [3]   PIN;SPRING
17 4488904 [3]   PIN
17 4488904 [3]   PIN
18 3080912 [1]   GEAR;SUN
18 3080912 [1]   GEAR;SUN
20 1025957 [1]   GEAR;RING
20 1025957 [1]   GEAR;RING
21 M341645 [12]   BOLT;SOCKET
21 M341645 [12]   BOLT;SOCKET
23 1025912 [1]   CARRIER
23 1025912 [1]   CARRIER
24 4403371 [1]   PLATE;THRUST
24 4403371 [1]   PLATE;THRUST
25 3082517 [3]   GEAR;PLANETARY
25 3082517 [3]   GEAR;PLANETARY
26 4404506 [3]   BRG.;NEEDLE
26 4404506 [3]   BRG.;NEEDLE
27 4403082 [3]   PLATE;THRUST
27 4403082 [3]   PLATE;THRUST
28 4336923 [3]   PIN
28 4336923 [3]   PIN
29 4051262 [3]   PIN;SPRING
29 4051262 [3]   PIN;SPRING
30 3084056 [1]   GEAR;SUN
30 3084056 [1]   GEAR;SUN
33 4194712 [1]   COCK
33 4194712 [1]   COCK
36 94-2024 [1]   PLUG
36 94-2024 [1]   PLUG
37 4422479 [4]   MAGNET
37 4422479 [4]   MAGNET
38 M470513 [4]   SCREW
38 M470513 [4]   SCREW
39 4474191 [1]   PLATE;LOCK
39 4474191 [1]   PLATE;LOCK
40 431578 [2]   CORK
40 431578 [2]   CORK
