HITACHI 9180778 SWING DEVICE 4423009 OIL MOTOR ROTARY GROUP

Name: HITACHI 9180778 SWING DEVICE 4423009 OIL MOTOR ROTARY GROUP
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

HITACHI 9180778 SWING DEVICE 4423009 OIL MOTOR ROTARY GROUP

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

9180778 SWING DEVICE 4423009 OIL MOTOR ZX450 ZX450-3 ZX450-3F ZX450H ZX450H-HHE ZX450LC-3-DH ZX460LCH-AMS ZX460LCH-HCME ZX470H-3 ZX470H-3-HCMC ZX470H-3F ZX470R-3 ZX470R-3F ZX480MT ZX480MTH ZX500LC ZX500LC-3 ZX500LC-3F ZX500LCH ZX500W ZX520LCH-3 ZX520LCH-3F ZX520LCR-3 ZX520LCR-3F

Pos.	Part No	Qty	Parts name	Comments
	4423009	[1]	MOTOR;OIL (SWING)
	4423009	[1]	MOTOR;OIL (SWING)
10	0788801	[1]	PISTON ASS'Y
10	0788801	[1]	PISTON ASS'Y
010A.	+++++++	[9]	PISTON
010A.	+++++++	[9]	PISTON
010B.	+++++++	[9]	SHOE
010B.	+++++++	[9]	SHOE
20	0788802	[1]	CASING ASS'Y
20	0788802	[1]	CASING ASS'Y
020A.	+++++++	[1]	CASING
020A.	+++++++	[1]	CASING
020B.	+++++++	[2]	PIN;SPRING
020B.	+++++++	[2]	PIN;SPRING
51	4469527	[2]	VALVE;RELIEF
51	4469527	[2]	VALVE;RELIEF
051A.	A811030	[2]	O-RING
051A.	A811030	[2]	O-RING
80	0788803	[1]	PLUNGER
80	0788803	[1]	PLUNGER
101	0788804	[1]	SHAFT
101	0788804	[1]	SHAFT
111	0788805	[1]	CYLINDER
111	0788805	[1]	CYLINDER
114	0788806	[1]	SPRING;PLATE
114	0788806	[1]	SPRING;PLATE
123	0788807	[1]	RETAINER
123	0788807	[1]	RETAINER
124	0788808	[1]	PLATE
124	0788808	[1]	PLATE
131	0788809	[1]	PLATE;VALVE
131	0788809	[1]	PLATE;VALVE
301	0788810	[1]	CASING
301	0788810	[1]	CASING
351	0409215	[2]	PLUNGER
351	0409215	[2]	PLUNGER
355	0409216	[2]	SPRING
355	0409216	[2]	SPRING
390	0625508	[1]	NAME-PLATE	I 0817703
390	0625508	[1]	NAME-PLATE	I 0817703
390	0817703	[1]	NAME-PLATE
390	0817703	[1]	NAME-PLATE
391	0625509	[2]	PIN
391	0625509	[2]	PIN
401	0365318	[4]	BOLT;SOCKET
401	0365318	[4]	BOLT;SOCKET
443	0788811	[1]	BRG.;ROL.
443	0788811	[1]	BRG.;ROL.
444	0788812	[1]	BRG.;ROL.	I 0677203
444	0788812	[1]	BRG.;ROL.	I 0677203
444	0677203	[1]	BRG.;ROL.
444	0677203	[1]	BRG.;ROL.
467	0629404	[2]	PLUG
467	0629404	[2]	PLUG
469	0692708	[2]	PLUG
469	0692708	[2]	PLUG
472	0425115	[1]	O-RING	I 1119003
472	0425115	[1]	O-RING	I 1119003
472	1119003	[1]	O-RING
472	1119003	[1]	O-RING
487	957366	[2]	O-RING
487	957366	[2]	O-RING
488	4506428	[2]	O-RING
488	4506428	[2]	O-RING
491	0788813	[1]	SEAL;OIL
491	0788813	[1]	SEAL;OIL
702	0788814	[1]	PISTON
702	0788814	[1]	PISTON
706	0353321	[1]	O-RING
706	0353321	[1]	O-RING
707	0425117	[1]	O-RING
707	0425117	[1]	O-RING
712	0788815	[24]	SPRING;BRAKE
712	0788815	[24]	SPRING;BRAKE
742	0788816	[3]	PLATE;FRICTION
742	0788816	[3]	PLATE;FRICTION
743	0788817	[4]	PLATE
743	0788817	[4]	PLATE
807	0788818	[1]	SPRING
807	0788818	[1]	SPRING
808	0221509	[1]	BALL;STEEL
808	0221509	[1]	BALL;STEEL
809	4506407	[1]	OｰRING
809	4506407	[1]	OｰRING
813	0263019	[2]	PLUG
813	0263019	[2]	PLUG
982	0628705	[2]	PLUG	I 1192601
982	0628705	[2]	PLUG	I 1192601
982	1192601	[2]	PLUG
982	1192601	[2]	PLUG
984	0694825	[1]	PLUG	I 0817701
984	0694825	[1]	PLUG	I 0817701
984	0817701	[1]	PLUG
984	0817701	[1]	PLUG
985	0788819	[1]	PLUG	I 0817702
985	0788819	[1]	PLUG	I 0817702
985	0817702	[1]	PLUG
985	0817702	[1]	PLUG
1000	1119004	[1]	KIT;SEAL
1000	1119004	[1]	KIT;SEAL
Parts on group SWING DEVICE (R):

Pos.	Part No	Qty	Parts name	Comments
	9180778	[1]	SWING DEVICE (R)
0	4423009	[1]	MOTOR;OIL (SWING)
1	991342	[1]	RING;RETAINING
2	9180779	[1]	T.MISSION (SWING)	I 9205887
2	9205887	[1]	T.MISSION (SWING)
4	4264452	[1]	PIPE
5	3074223	[1]	GAUGE;LEVEL
6	4332658	[1]	PIPE
7	4343365	[1]	CAP
9	+++++++	[1]	NAME-PLATE
10	M492564	[2]	SCREW;DRIVE
11	4614096	[8]	BOLT;SOCKET
Parts on group SWING DEVICE (L):

Pos.	Part No	Qty	Parts name	Comments
	9180776	[1]	SWING DEVICE (L)
0	4423009	[1]	MOTOR;OIL (SWING)
1	991342	[1]	RING;RETAINING
2	9180779	[1]	T.MISSION (SWING)	I 9205887
2	9205887	[1]	T.MISSION (SWING)
4	4264452	[1]	PIPE
5	3074223	[1]	GAUGE;LEVEL
6	4332658	[1]	PIPE
7	4343365	[1]	CAP
9	+++++++	[1]	NAME-PLATE
10	M492564	[2]	SCREW;DRIVE
11	4614096	[8]	BOLT;SOCKET
