HITACHI 4699092 TRAVEL MOTOR ROTARY GROUP

Name: HITACHI 4699092 TRAVEL MOTOR ROTARY GROUP
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

HITACHI 4699092 TRAVEL MOTOR ROTARY GROUP

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

4699092 ZX470-5G ZX470H-5G ZX470LC-5B ZX470LC-5G ZX470LCH-5B ZX470LCH-5G ZX470LCR-5G ZX470R-5G4699092 ZX470-5G ZX470H-5G ZX470LC-5B ZX470LC-5G ZX470LCH-5B ZX470LCH-5G ZX470LCR-5G ZX470R-5G

Pos.	Part No	Qty	Parts name	Comments
	9298565	[1]	TRAVEL-DEVICE
00	9263594	[1]	TRAVEL-DEVICE
01	4699092	[1]	MOTOR;OIL
			MOTOR;OIL (1/2)
			MOTOR;OIL (2/2)
02	4271596	[1]	O-RING
03	A590918	[4]	WASHER;SPRING
04	J911860	[4]	BOLT
05	+++++++	[1]	NAME-PLATE
06	M492564	[2]	SCREW;DRIVE
Parts on group MOTOR;OIL (1/2):

Pos.	Part No	Qty	Parts name	Comments
	4699092	[1]	MOTOR;OIL (1/2)	This PART NO. consisits of all parts shown in MOTOR;OIL (1/2) to (2/2).
1	+++++++	[1]	CASE
3	0809501	[1]	SHAFT
4	+++++++	[1]	CYL.
5	+++++++	[1]	PLATE
6	+++++++	[9]	PISTON
7	+++++++	[1]	PLATE
8	+++++++	[1]	HOLDER
9	XB00001429	[1]	PLATE
10	0682706	[2]	BALL;STEEL
11	+++++++	[2]	PISTON
12	0809503	[2]	SPRING
13	0809504	[1]	BRG.;ROL.
14	0809505	[1]	BRG.;ROL.
15	0809506	[1]	COLLAR
17	0380201	[9]	SPRING
18	0979001	[5]	PLATE;FRICTION
19	0419808	[4]	PLATE;DISK
21	0809509	[1]	PISTON;BRAKE
22	0411419	[1]	O-RING
23	0809510	[1]	RING;BACK-UP
24	0419806	[1]	O-RING
25	0419812	[1]	RING;BACK-UP
28	0979002	[1]	SEAL;OIL
29	A811260	[1]	O-RING
30	4506320	[4]	O-RING
31	0809511	[2]	PLUG
32	4506424	[2]	O-RING
34	+++++++	[2]	PLUG
100	0923602	[1]	CYL.
200	0809513	[1]	RETAINER
300	0809514	[1]	CASE
500	0979004	[1]	KIT;SEAL	NOTE) This KIT;SEAL consists of ｢MOTOR;OIL (1/2)｣ and ｢MOTOR;OIL (2/2)｣.
Parts on group MOTOR;OIL (2/2):

Pos.	Part No	Qty	Parts name	Comments
	4699092	[1]	MOTOR;OIL (2/2)	This PART NO. consisits of all parts shown in MOTOR;OIL (1/2) to (2/2).
2	+++++++	[1]	PLATE
2-1.	+++++++	[1]	PLATE
2-2.	+++++++	[1]	SPOOL
2-2-1.	+++++++	[1]	SPOOL
2-2-2.	+++++++	[2]	VALVE;CHECK
2-2-3.	+++++++	[2]	SPRING
2-2-4.	+++++++	[2]	PLUG
2-2-5.	+++++++	[2]	O-RING
2-3.	0356914	[2]	SEAT;SPRING
2-4.	0417802	[2]	SPRING
2-5.	0809601	[2]	SEAT;SPRING
2-6.	0979101	[2]	CAP;
2-6-1.	+++++++	[1]	CAP
2-6-2.	+++++++	[1]	O-RING
2-6-3.	+++++++	[4]	BOLT;SOCKET
2-7.	0806602	[2]	VALVE;RELIEF
2-7-1.	+++++++	[1]	SEAT
2-7-2.	+++++++	[1]	HOUSING;RELIEF
2-7-3.	+++++++	[1]	POPPET
2-7-4.	+++++++	[1]	SEAT;SPRING
2-7-5.	+++++++	[1]	SPRING
2-7-6.	+++++++	[1]	PLUG
2-7-7.	+++++++	[1]	GUIDE;SPRING
2-7-8.	+++++++	[1]	SCREW;SET
2-7-9.	+++++++	[1]	NUT;LOCK
2-7-10.	+++++++	[1]	PISTON
2-7-11.	+++++++	[1]	O-RING
2-7-12.	+++++++	[1]	O-RING
2-7-13.	+++++++	[1]	O-RING
2-7-14.	+++++++	[1]	O-RING
2-7-15.	+++++++	[1]	RING;BACK-UP
2-7-16.	+++++++	[2]	RING;BACK-UP
2-7-17.	+++++++	[2]	RING;BACK-UP
2-9.	+++++++	[1]	SPOOL
2-11.	+++++++	[2]	ORIFICE
2-13.	XB00001457	[1]	SPRING
2-14.	0671002	[2]	PLUG
2-15.	4506418	[2]	O-RING
2-19.	0352304	[2]	VALVE;CHECK
2-20.	0352305	[2]	SPRING
2-21.	0352306	[2]	PLUG
2-22.	4506429	[2]	O-RING
2-23.	+++++++	[2]	ORIFICE
2-24.	+++++++	[1]	ORIFICE
2-25.	0436608	[6]	PLUG
2-26.	957366	[6]	O-RING
2-27.	+++++++	[1]	PLUG
2-28.	+++++++	[7]	PLUG
16	0682803	[1]	PIN
26	809604	[10]	SPRING
27	0251319	[4]	PIN
33	0168008	[9]	BOLT;SOCKET
51	+++++++	[1]	NAME-PLATE
52	+++++++	[2]	SCREW;DRIVE
400	XB00001431	[1]	PLATE	NOTE) The KIT;SEAL of this system is indicated at ｢MOTOR;OIL (1/2)｣.
