HITACHI 4698700 9301098 SWING MOTOR ROTARY GROUP AND SPARE PARTS

HITACHI 4698700 9301098 SWING MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
4698700 9301098
ZX470-5G ZX470H-5G ZX470LC-5B ZX470LC-5G ZX470LCH-5B ZX470LCH-5G ZX470LCR-5G ZX470R-5G4698700 9301098
ZX470-5G ZX470H-5G ZX470LC-5B ZX470LC-5G ZX470LCH-5B ZX470LCH-5G ZX470LCR-5G ZX470R-5GKLH
Pos. Part No Qty Parts name Comments
9301098 [1]   SWING DEVICE (L)
0 4698700 [1]   MOTOR;OIL
1 991342 [1]   RING;RETAINING
2 9300512 [1]   SWING;DEVICE
3 4614096 [8]   BOLT;SOCKET
4 4264452 [1]   PIPE
5 3074223 [1]   GAUGE;LEVEL
6 4332658 [1]   PIPE
7 4343365 [1]   BREATHER;AIR
9 +++++++ [1]   NAME-PLATE
10 M492564 [2]   SCREW;DRIVE
Parts on group MOTOR;OIL (SWING):
Pos. Part No Qty Parts name Comments
4698700 [1]   MOTOR;OIL
4698700 [1]   MOTOR;OIL
10 1119002 [1]   PISTON
10 1119002 [1]   PISTON
10A. +++++++ [9]   PISTON
10A. +++++++ [9]   PISTON
10B. +++++++ [9]   SHOE
10B. +++++++ [9]   SHOE
20 0788802 [1]   CASING
20 0788802 [1]   CASING
20A. +++++++ [1]   CASING
20A. +++++++ [1]   CASING
20B. +++++++ [2]   PIN;SPRING
20B. +++++++ [2]   PIN;SPRING
51 XB00001310 [2]   VALVE;RELIEF
51 XB00001310 [2]   VALVE;RELIEF
51A. A811030 [1]   O-RING
51A. A811030 [1]   O-RING
80 0788803 [1]   PLUNGER
80 0788803 [1]   PLUNGER
101 0788804 [1]   SHAFT;DRIVE
101 0788804 [1]   SHAFT;DRIVE
111 0788805 [1]   CYLINDER
111 0788805 [1]   CYLINDER
114 0788806 [1]   SPRING;PLATE
114 0788806 [1]   SPRING;PLATE
123 0788807 [1]   RETAINER
123 0788807 [1]   RETAINER
124 0788808 [1]   PLATE
124 0788808 [1]   PLATE
131 0788809 [1]   PLATE;VALVE
131 0788809 [1]   PLATE;VALVE
301 0788810 [1]   CASING
301 0788810 [1]   CASING
351 0409215 [2]   PLUNGER
351 0409215 [2]   PLUNGER
355 0409216 [2]   SPRING
355 0409216 [2]   SPRING
390 +++++++ [1]   NAME-PLATE
390 +++++++ [1]   NAME-PLATE
391 0625509 [2]   PIN
391 0625509 [2]   PIN
401 0365318 [4]   BOLT;SOCKET
401 0365318 [4]   BOLT;SOCKET
443 0788811 [1]   BRG.;ROL.
443 0788811 [1]   BRG.;ROL.
444 XB00001137 [1]   BRG.;ROL.
444 XB00001137 [1]   BRG.;ROL.
468 0629404 [2]   PLUG
468 0629404 [2]   PLUG
469 0692708 [2]   PLUG
469 0692708 [2]   PLUG
472 1119003 [1]   O-RING
472 1119003 [1]   O-RING
487 957366 [2]   O-RING
487 957366 [2]   O-RING
488 4506428 [2]   O-RING
488 4506428 [2]   O-RING
491 0788813 [1]   SEAL;OIL
491 0788813 [1]   SEAL;OIL
702 0788814 [1]   PISTON
702 0788814 [1]   PISTON
706 0353321 [1]   O-RING
706 0353321 [1]   O-RING
707 0425117 [1]   O-RING
707 0425117 [1]   O-RING
712 0788815 [24]   SPRING
712 0788815 [24]   SPRING
742 0788816 [3]   PLATE;FRICTION
742 0788816 [3]   PLATE;FRICTION
743 0788817 [4]   PLATE
743 0788817 [4]   PLATE
807 0788818 [1]   SPRING
807 0788818 [1]   SPRING
808 0221509 [1]   BALL
808 0221509 [1]   BALL
809 4506407 [1]   O-RING
809 4506407 [1]   O-RING
813 0263019 [2]   PLUG
813 0263019 [2]   PLUG
1000 1119004 [1]   KIT;SEAL
1000 1119004 [1]   KIT;SEAL
