HITACHI 4698624 9293650 SWING DEVICE ROTARY GROUP

HITACHI 4698624 9293650 SWING DEVICE ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
4698624 9293650
ZX870-5G ZX870H-5G ZX870LC-5B ZX870LC-5G ZX870LCH-5G ZX870LCR-5G
Pos. Part No Qty Parts name Comments
9293650 [1]   SWING-DEVICE
00 4698624 [1]   MOTOR;OIL
01 959499 [1]   RING;RETAINING
03 9293649 [1]   SWING-DEVICE
04 3107447 [1]   GAUGE;LEVEL
07 4449144 [1]   PIPE
08 4640541 [1]   PIPE
10 4343365 [1]   BREATHER;AIR
12 4614096 [12]   BOLT;SOCKET
Parts on group SWING DEVICE:
Pos. Part No Qty Parts name Comments
9293649 [1]   SWING-DEVICE
9293649 [1]   SWING-DEVICE
0 1034400 [1]   HOUSING
0 1034400 [1]   HOUSING
2 2054830 [1]   SHAFT;PROP.
2 2054830 [1]   SHAFT;PROP.
3 4430716 [1]   BRG.;ROL.
3 4430716 [1]   BRG.;ROL.
5 3111316 [1]   SLEEVE
5 3111316 [1]   SLEEVE
6 4412650 [1]   O-RING
6 4412650 [1]   O-RING
7 4422479 [4]   MAGNET
7 4422479 [4]   MAGNET
8 M470513 [4]   SCREW
8 M470513 [4]   SCREW
9 4723568 [1]   SEAL;OIL
9 4723568 [1]   SEAL;OIL
11 4402481 [1]   BRG.;ROL.
11 4402481 [1]   BRG.;ROL.
12 3101122 [1]   NUT
12 3101122 [1]   NUT
14 4430563 [1]   PLATE;LOCK
14 4430563 [1]   PLATE;LOCK
15 J901016 [2]   BOLT
15 J901016 [2]   BOLT
17 1035296 [1]   GEAR;RING
17 1035296 [1]   GEAR;RING
18 M342050 [12]   BOLT;SOCKET
18 M342050 [12]   BOLT;SOCKET
20 2054831 [1]   CARRIER
20 2054831 [1]   CARRIER
21 4194454 [2]   PLATE;THRUST
21 4194454 [2]   PLATE;THRUST
22 3088069 [3]   GEAR;PLANETARY
22 3088069 [3]   GEAR;PLANETARY
23 4430714 [3]   PIN
23 4430714 [3]   PIN
24 4404947 [3]   PIN;SPRING
24 4404947 [3]   PIN;SPRING
25 4445254 [6]   BRG.;NEEDLE
25 4445254 [6]   BRG.;NEEDLE
26 4644567 [3]   PLATE;THRUST
26 4644567 [3]   PLATE;THRUST
27 3111317 [1]   GEAR;SUN
27 3111317 [1]   GEAR;SUN
30 1034401 [1]   CARRIER
30 1034401 [1]   CARRIER
32 3098513 [3]   GEAR;PLANETARY
32 3098513 [3]   GEAR;PLANETARY
33 4144558 [3]   PIN
33 4144558 [3]   PIN
34 4144525 [3]   PIN;SPRING
34 4144525 [3]   PIN;SPRING
35 4685231 [3]   BRG.;NEEDLE
35 4685231 [3]   BRG.;NEEDLE
36 4430667 [3]   PLATE;THRUST
36 4430667 [3]   PLATE;THRUST
37 3101105 [1]   GEAR;SUN
37 3101105 [1]   GEAR;SUN
39 +++++++ [1]   NAME-PLATE
39 +++++++ [1]   NAME-PLATE
40 M492564 [2]   SCREW;DRIVE
40 M492564 [2]   SCREW;DRIVE
42 456336 [2]   CORK
42 456336 [2]   CORK
44 4194712 [2]   COCK
44 4194712 [2]   COCK
45 94-2024 [2]   PLUG
45 94-2024 [2]   PLUG
Parts on group MOTOR;OIL (SWING):
Pos. Part No Qty Parts name Comments
4698624 [1]   MOTOR;OIL
4698624 [1]   MOTOR;OIL
10 0816201 [1]   PISTON
10 0816201 [1]   PISTON
010A. +++++++ [9]   PISTON
010A. +++++++ [9]   PISTON
010B. +++++++ [9]   SHOE
010B. +++++++ [9]   SHOE
20 0816202 [1]   CASING
20 0816202 [1]   CASING
020A. +++++++ [1]   CASING
020A. +++++++ [1]   CASING
020B. +++++++ [2]   PIN
020B. +++++++ [2]   PIN
31 0960201 [1]   VALVE
31 0960201 [1]   VALVE
33 0218824 [3]   BOLT;SOCKET
33 0218824 [3]   BOLT;SOCKET
51 XB00001361 [2]   VALVE;RELIEF
51 XB00001361 [2]   VALVE;RELIEF
051A. A811030 [1]   O-RING
051A. A811030 [1]   O-RING
101 0816205 [1]   SHAFT
101 0816205 [1]   SHAFT
111 0816206 [1]   CYL.
111 0816206 [1]   CYL.
114 0816207 [1]   SPRING;PLATE
114 0816207 [1]   SPRING;PLATE
123 0816208 [1]   RETAINER
123 0816208 [1]   RETAINER
124 0816209 [1]   PLATE
124 0816209 [1]   PLATE
131 0816210 [1]   PLATE;VALVE
131 0816210 [1]   PLATE;VALVE
301 0976202 [1]   CASING
301 0976202 [1]   CASING
351 0803007 [2]   PLUNGER
351 0803007 [2]   PLUNGER
355 0803008 [2]   SPRING
355 0803008 [2]   SPRING
390 0817703 [1]   NAME-PLATE
390 0817703 [1]   NAME-PLATE
391 0625509 [2]   PIN
391 0625509 [2]   PIN
401 0365318 [4]   BOLT;SOCKET
401 0365318 [4]   BOLT;SOCKET
443 0816212 [1]   BRG.;ROL
443 0816212 [1]   BRG.;ROL
444 0872302 [1]   BRG.;ROL
444 0872302 [1]   BRG.;ROL
468 0629404 [2]   PLUG
468 0629404 [2]   PLUG
469 0803009 [2]   PLUG
469 0803009 [2]   PLUG
472 0976204 [1]   O-RING
472 0976204 [1]   O-RING
487 957366 [2]   O-RING
487 957366 [2]   O-RING
488 984614 [2]   O-RING
488 984614 [2]   O-RING
491 0365328 [1]   SEAL;OIL
491 365328 [1]   SEAL;OIL
702 0816214 [1]   PISTON
702 0816214 [1]   PISTON
706 XB00001359 [1]   O-RING
706 XB00001359 [1]   O-RING
707 XB00001360 [1]   O-RING
707 XB00001360 [1]   O-RING
712 0747307 [20]   SPRING
712 0747307 [20]   SPRING
742 0816215 [3]   PLATE;FRICTION
742 0816215 [3]   PLATE;FRICTION
743 0816216 [4]   PLATE
743 0816216 [4]   PLATE
1000 0976205 [1]   KIT;SEAL
1000 0976205 [1]   KIT;SEAL
