HITACHI 4484662 SWING MOTOR ROTARY GROUP AND SPARE PARTS

HITACHI 4484662 SWING MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
4484662
ZX55UR ZX55UR-HHE
Pos. Part No Qty Parts name Comments
4484662 [1]   MOTOR;OIL (1/2) 0854600<BR>This PART NO. consists of all parts shown in MOTOR;OIL(1/2) to (2/2).
1 0854601 [1]   CASE
3 +++++++ [1]   BLOCK;CYL.
4 0732002 [1]   SHAFT
5 0732003 [1]   PLATE;VALVE
6 +++++++ [9]   PISTON
7 0732004 [1]   PLATE
8 0397908 [1]   HOLDER
9 0396807 [1]   PLATE;THRUST
11 0732005 [1]   BRG.;BALL
12 0397915 [1]   BRG.;BALL
13 0434005 [3]   PIN
14 0397905 [1]   COLLAR
15 0434006 [1]   SPRING
16 0434007 [1]   WASHER
17 0396815 [1]   RING;RETAINING
18 0444104 [2]   PIN
19 0396703 [1]   PIN
22 0631413 [1]   O-RING
24 0680801 [1]   PISTON
25 0631406 [1]   COLLAR
26 0631407 [2]   PLATE;FRICTION
27 0631408 [2]   PLATE;DISK
28 0732006 [22]   SPRING
29 A811105 [1]   O-RING
30 A811115 [1]   O-RING
34 0436608 [1]   PLUG
35 957366 [1]   O-RING
36 A811120 [1]   O-RING
43 +++++++ [1]   PLUG
100 0732007 [1]   BLOCK;CYL. KIT
200 0732008 [1]   KIT;REPAIR NOTE) This KIT;REPAIR consists of MOTOR;OIL(1/2) and MOTOR;OIL(2/2).
Parts on group MOTOR;OIL (2/2):
Pos. Part No Qty Parts name Comments
4484662 [1]   MOTOR;OIL (2/2) 0854700<BR>This PART NO. consists of all parts shown in MOTOR;OIL(1/2) to (2/2).
2 0854701 [1]   COVER
2-1. 0647002 [1]   BODY
2-2. 0647003 [2]   VALVE;CHECK
2-3. 0647004 [2]   SPRING
2-4. 0311336 [3]   PLUG
2-5. 0854702 [2]   VALVE;RELIEF
2-5-1. +++++++ [1]   HOUSING
2-5-2. +++++++ [1]   POPET
2-5-3. +++++++ [1]   SEAT
2-5-4. +++++++ [1]   SEAT;SPRING
2-5-5. +++++++ [1]   SPRING
2-5-6. +++++++ [1]   PLUG
2-5-7. +++++++ [1]   ADJUSTER
2-5-8. 4506424 [1]   O-RING
2-5-9. 4506408 [1]   O-RING
2-5-1. +++++++ [1]   O-RING
2-5-1. 4506412 [1]   O-RING
2-5-1. +++++++ [2]   RING;BACK-UP
2-5-1. 4027963 [2]   RING;BACK-UP
2-5-1. +++++++ [1]   PISTON
2-5-1. +++++++ [1]   SCREW;SET
2-5-1. +++++++ [1]   NUT
2-6. 4509180 [3]   O-RING
2-7. 0647006 [2]   PLUG
2-8. 4506408 [2]   O-RING
20 0158883 [3]   BOLT;SOCKET
40 +++++++ [1]   NAME-PLATE
41 +++++++ [2]   SCREW;DRIVE
42 +++++++ [4]   PLUG
+++++++ [1]   KIT;REPAIR NOTE) The KIT;REPAIR of this system is indicated at MOTOR;OIL(1/2).
