HITACHI 4477062 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

HITACHI 4477062 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$0.00 USD
$0.00 USD
特價 售罄
結帳時計算運費。
4477062
EX2500 EX2500-5 EX2500-6 EX2600-6BH EX2600-6LD EX5500 EX5500-5 EX5500-6 EX5500E-6 EX5600-6BH EX5600-6LD EX8000 EX8000-6
Pos. Part No Qty Parts name Comments
4477062 [1]   MOTOR;OIL (TRAVEL)
11 0694701 [9]   PISTON ASS'Y
011A. +++++++ [1]   PISTON
011B. +++++++ [1]   SHOE
13 0855301 [1]   CYL. ASS'Y
013A. +++++++ [1]   CYL.
013B. +++++++ [1]   PLATE
20 0694703 [1]   VALVE;COVER ASS'Y
020A. +++++++ [1]   VALVE;COVER
020B. +++++++ [1]   PIN
21 0855302 [1]   PLATE;SWASH ASS'Y
021A. +++++++ [1]   PLATE;SWASH
021B. +++++++ [1]   CASING
22 0694705 [2]   PISTON ASS'Y
022A. +++++++ [1]   PISTON
022B. +++++++ [1]   SHOE
31 4606780 [1]   VALVE
101 0694707 [1]   SHAFT
113 0855303 [1]   BUSHING
114 0222809 [4]   SPRING
115 0222810 [1]   SHIM
123 4612147 [1]   PLATE
124 4612148 [1]   PLATE
301 0855304 [1]   CASING
304 0694712 [1]   COVER
390 0625508 [1]   NAME-PLATE
391 0625509 [2]   PIN
401 0694713 [3]   BOLT;SOCKET
402 M341656 [9]   BOLT;SOCKET
403 0291225 [6]   BOLT
404 0229812 [12]   BOLT;SOCKET
405 0222827 [14]   BOLT;SOCKET
431 991353 [1]   RING;RETAINING
432 0694714 [1]   RING;RETAINING
443 0694715 [1]   BRG.;ROL.
444 0694716 [1]   BRG.;NEEDLE
448 0694717 [1]   SPACER
463 0111537 [1]   PLUG
464 0175233 [4]   PLUG
471 0308622 [1]   O-RING
472 0222820 [1]   O-RING
473 0365423 [1]   O-RING
474 0222821 [1]   O-RING
476 0694718 [1]   O-RING
485 4506424 [4]   O-RING
491 0694719 [1]   SEAL;OIL
503 0855305 [1]   STOPPER
504 0855306 [1]   STOPPER
505 0694722 [2]   COVER
602 0222827 [8]   BOLT;SOCKET
665 0263019 [7]   PLUG
671 A811045 [2]   O-RING
697 4506408 [5]   O-RING
701 0694723 [1]   COVER
702 0694724 [1]   PISTON
703 0694725 [1]   COUPLING
705 0694726 [10]   SPRING
706 0425117 [1]   O-RING
707 0365423 [1]   O-RING
710 0694727 [1]   SHIM
720 0694728 [1]   CASING
741 0694729 [9]   PLATE
742 0694730 [8]   PLATE
761 0236014 [3]   PLUG
762 957366 [3]   O-RING
800 4485118 [1]   KIT;SEAL
