HITACHI 4466812 9212252 TRAVEL MOTOR PARTS

HITACHI 4466812 9212252 TRAVEL MOTOR PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
4466812 9212252
ZX55UR ZX55UR-HHE
Pos. Part No Qty Parts name Comments
4466812 [1]   MOTOR;OIL (2/3) 0855900<BR>This PART NO. consists of all parts shown in MOTOR;OIL(1/3) to (3/3).
2 0629801 [1]   SHAFT
3 0397902 [1]   BRG.;BALL
4 0732301 [1]   SEAL;OIL
5 0629802 [1]   PLATE
6 0732302 [2]   BALL;STEEL
7 +++++++ [1]   BLOCK;CYL.
8 +++++++ [1]   COLLAR
9 +++++++ [1]   SPRING
10 +++++++ [1]   WASHER
11 +++++++ [1]   RING;RETAINING
12 +++++++ [3]   PIN
13 +++++++ [1]   HOLDER
14 +++++++ [1]   PLATE
15 +++++++ [9]   PISTON
19 +++++++ [2]   PISTON
20 0629805 [2]   SPRING
25 0732003 [1]   PLATE;VALVE
26 0396703 [1]   PIN
27 0397915 [1]   BRG.;BALL
28 0158833 [1]   O-RING
29 4506407 [3]   O-RING
30 +++++++ [1]   PLATE
31 +++++++ [1]   SPOOL ASS'Y
31A. +++++++ [1]   SPOOL
31B. +++++++ [2]   VALVE;CHECK
31C. +++++++ [2]   SPRING
31D. +++++++ [2]   PLUG
31E. +++++++ [2]   O-RING
36 0398004 [2]   SEAT;SPRING
37 0398005 [2]   SPRING
38 0831902 [2]   CAP
39 4506429 [2]   O-RING
40 0158826 [2]   ORIFICE
41 +++++++ [1]   SPOOL
42 0436602 [1]   SPRING
43 0311336 [3]   PLUG
44 4509180 [4]   O-RING
45 0352225 [2]   PLUG
46 0732304 [1]   PLUG
47 0436603 [4]   ORIFICE
48 0398007 [6]   BOLT;SOCKET
49 0397910 [2]   PIN
53 +++++++ [2]   PLUG
54 +++++++ [1]   PLUG
55 94-2011 [1]   PLUG
57 4113154 [2]   O-RING
58 0855901 [2]   PLUG
59 0825105 [2]   PLUG
200 0855902 [1]   KIT;SEAL
300 0732305 [1]   BLOCK;CYL. KIT
400 0855903 [1]   PLATE KIT
Parts on group MOTOR;OIL (3/3):
Pos. Part No Qty Parts name Comments
4466812 [1]   MOTOR;OIL (3/3) 0856000<BR>This PART NO. consists of all parts shown in MOTOR;OIL(1/3) to (3/3).
50 0847901 [1]   VALVE ASS'Y
50-1. +++++++ [1]   BODY;VALVE
50-2. +++++++ [2]   VALVE;CHECK
50-3. +++++++ [2]   SPRING
50-4. +++++++ [2]   PLUG
50-5. 4509180 [2]   O-RING
50-6. 4506412 [3]   O-RING
50-7. +++++++ [3]   BOLT;SOCKET
51 +++++++ [1]   NAME-PLATE
52 +++++++ [2]   SCREW;DRIVE
Parts on group TRAVEL DEVICE:
Pos. Part No Qty Parts name Comments
9212252 [2]   TRAVEL DEVICE
0 4466812 [1]   MOTOR;OIL
2 1013768 [1]   SPROCKET Y 1032012
2 1032012 [1]   SPROCKET
4 4317650 [9]   BOLT
5 J254014 [9]   WASHER Y J222014
5 J222014 [9]   WASHER
