HITACHI 4466809 HYDRAULIC PUMP ROTARY GROUP

HITACHI 4466809 HYDRAULIC PUMP ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
4466809
ZX55UR ZX55UR-HHE
Pos. Part No Qty Parts name Comments
4466809 [1]   PUMP;PISTON 854800
1 +++++++ [1]   BODY
2 +++++++ [1]   BODY
3 0842101 [1]   SHAFT
4 +++++++ [1]   BUSHING
5 +++++++ [1]   PLATE;VALVE
6 +++++++ [11]   PISTON
7 +++++++ [11]   SHOE
8 +++++++ [1]   HOLDER;SHOE
9 +++++++ [1]   HOLDER
10 0842102 [1]   PLATE
11 +++++++ [3]   NEEDLE
12 0842103 [2]   PIN
13 +++++++ [1]   PACKING
14 +++++++ [1]   SPRING
15 0842104 [1]   SPRING
16 0800005 [1]   HOLDER
17 0630612 [1]   GUIDE;SPRING
18 0429816 [3]   PIN
19 +++++++ [3]   RETAINER
20 0842105 [1]   PIN;STOPPER
21 0800007 [1]   SPRING
22 0630606 [1]   HOLDER
23 0842106 [1]   SLEEVE
24 +++++++ [1]   PISTON
25 +++++++ [1]   O-RING
26 0429817 [1]   BRG.;BALL
27 +++++++ [1]   BRG.;NEEDLE
28 +++++++ [1]   SEAL;OIL
29 988850 [1]   RING;RETAINING
30 446751 [1]   RING;RETAINING
31 942517 [1]   RING;RETAINING
32 0630505 [1]   PLUG
33 +++++++ [1]   O-RING
34 +++++++ [1]   O-RING
35 0800010 [7]   BOLT;SOCKET
36 0655913 [1]   SCREW
37 0630509 [1]   NUT
38 +++++++ [1]   WASHER;SEAL
39 +++++++ [1]   PUMP;GEAR ASS'Y
40 0800012 [1]   COUPLING
41 +++++++ [2]   BALL;STEEL
42 +++++++ [4]   BOLT;SOCKET
43 +++++++ [2]   BRG.
44 +++++++ [4]   WASHER
45 +++++++ [1]   O-RING
46 0630506 [1]   PLUG
47 +++++++ [1]   O-RING
48 +++++++ [1]   VALVE
48A. 4506420 [1]   O-RING
48B. 0842107 [2]   O-RING
48C. 0842802 [1]   RING;BACK-UP
48D. 0842108 [1]   O-RING
48E. 0842109 [1]   O-RING
48F. 0842601 [1]   RING;BACK-UP
49 0664917 [1]   PLUG
50 +++++++ [1]   O-RING
51 +++++++ [3]   PLUG
52 +++++++ [1]   CHOKE
54 +++++++ [1]   GASKET
200 0842111 [1]   CYL. BARREL KIT
300 0842112 [1]   KIT;SEAL
Parts on group PUMP DEVICE:
Pos. Part No Qty Parts name Comments
0 4466809 [1]   PUMP;PISTON
2 4477320 [2]   BOLT
3 2047668 [1]   COVER;PUMP
4 J041030 [6]   BOLT;SEMS I 4609014
4 4609014 [6]   BOLT;SEMS
6 J231210 [2]   NUT I J950010
6 J950010 [2]   NUT
7 J252210 [2]   WASHER;SPRING I A590910
7 A590910 [2]   WASHER;SPRING
11 4245228 [1]   SEAL;OIL
12 A882030 [1]   PLUG
13 4402125 [1]   COUPLING
13A. 4417517 [1]   COUPLING
13B. 4246158 [1]   COUPLING;RUBBER
