HITACHI 4451685 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

HITACHI 4451685 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
4451685
ZX330 ZX350H ZX350K ZX350LC-AMS ZX350LC-HCME ZX370MTH ZX380HH
Pos. Part No Qty Parts name Comments
4451685 [1]   MOTOR;OIL (1/2) This PART NO. consists of all parts shown in MOTOR;OIL(1/2) to (2/2).
1 +++++++ [1]   CASE
3 0809501 [1]   SHAFT
4 +++++++ [1]   CYL.
5 +++++++ [1]   PLATE
6 +++++++ [9]   PISTON
7 +++++++ [1]   PLATE
8 +++++++ [1]   HOLDER
9 0821801 [1]   PLATE
10 0682706 [2]   BALL;STEEL
11 +++++++ [2]   PISTON ASS'Y
12 0809503 [2]   SPRING
13 0809504 [1]   BRG.;ROL.
14 0809505A [1]   BRG.;ROL.
15 0809506 [1]   COLLAR
17 0809507 [9]   SPRING I 0419805
17 0419805 [9]   SPRING
18 0809508 [2]   PLATE;FRICTION
19 0419808 [4]   PLATE;DISK
20 0352221 [3]   PLATE;FRICTION
21 0809509 [1]   PISTON;BRAKE
22 0411419 [1]   O-RING
23 0809510 [1]   RING;BACK-UP
24 0419806 [1]   O-RING
25 0419812 [1]   RING;BACK-UP
28 0352218 [1]   SEAL;OIL
29 A811260 [1]   OｰRING
30 4506320 [4]   O-RING
31 0809511 [2]   PLUG
32 4506424 [2]   O-RING
34 +++++++ [2]   PLUG
53 0820102 [1]   PLATE;FRICTION
100 0820103 [1]   CYL. ASS'Y
200 0809513 [1]   RETAINER ASS'Y
300 0809514 [1]   CASE ASS'Y
500 0809515 [1]   KIT;SEAL NOTE) This KIT;SEAL consists of ｢MOTOR;OIL(1/2)｣ and ｢MOTOR;OIL(2/2)｣.
Parts on group MOTOR;OIL (2/2):
Pos. Part No Qty Parts name Comments
4451685 [1]   MOTOR;OIL (2/2) This PART NO. consists of all parts shown in MOTOR;OIL(1/2) to (2/2).
2 +++++++ [1]   PLATE ASS'Y
2-1. +++++++ [1]   PLATE
2-2. +++++++ [1]   SPOOL ASS'Y
2-2-1. +++++++ [1]   SPOOL
2-2-2. +++++++ [2]   VALVE;CHECK
2-2-3. +++++++ [2]   SPRING
2-2-4. +++++++ [2]   PLUG
2-2-5. +++++++ [2]   O-RING
2-3. 0163601 [2]   SEAT;SPRING
2-4. 0420002 [2]   SPRING
2-5. 0809601 [2]   SEAT;SPRING
2-6. 0820201 [2]   CAP ASS'Y
2-6-1. +++++++ [1]   CAP
2-6-2. +++++++ [1]   SCREW;SET
2-6-3. +++++++ [1]   PLUG
2-6-4. +++++++ [1]   O-RING
2-6-5. +++++++ [1]   OｰRING
2-6-6. +++++++ [4]   BOLT;SOCKET
2-7. 0802601 [2]   VALVE;RELIEF ASS'Y
2-7-1. +++++++ [1]   SEAT
2-7-2. +++++++ [1]   HOUSING;RELIEF
2-7-3. +++++++ [1]   POPPET
2-7-4. +++++++ [1]   SEAT;SPRING
2-7-5. +++++++ [1]   SPRING
2-7-6. +++++++ [1]   PLUG
2-7-7. +++++++ [1]   GUIDE;SPRING
2-7-8. +++++++ [1]   SCREW;SET
2-7-9. +++++++ [1]   NUT;LOCK
2-7-1. +++++++ [1]   PISTON
2-7-1. +++++++ [1]   O-RING
2-7-1. +++++++ [1]   O-RING
2-7-1. +++++++ [1]   O-RING
2-7-1. +++++++ [1]   O-RING
2-7-1. +++++++ [1]   RING;BACK-UP
2-7-1. +++++++ [2]   RING;BACK-UP
2-7-1. +++++++ [2]   RING;BACK-UP
2-9. +++++++ [1]   VALVE ASS'Y
2-9-1. +++++++ [1]   SPOOL
2-9-3. +++++++ [1]   FILTER
2-9-4. +++++++ [1]   O-RING
2-9-5. +++++++ [1]   OｰRING
2-9-6. +++++++ [1]   RING;BACK-UP
2-9-7. +++++++ [1]   RING;BACK-UP
2-9-8. +++++++ [1]   RING;RETAINING
2-10. 4506407 [2]   O-RING
2-11. +++++++ [2]   ORIFICE
2-13. 0820203 [1]   SPRING
2-14. 0671002 [1]   PLUG
2-15. 4506418 [2]   O-RING
2-17. 0820204 [1]   PLUG
2-19. 0352304 [2]   VALVE;CHECK
2-20. 0352305 [2]   SPRING
2-21. 0352306 [2]   PLUG
2-22. 4506429 [2]   O-RING
2-23. +++++++ [2]   ORIFICE
2-24. +++++++ [1]   ORIFICE
2-25. 0436608 [6]   PLUG
2-26. 957366 [6]   O-RING
2-27. +++++++ [1]   PLUG
2-28. +++++++ [9]   PLUG
16 0682803 [1]   PIN
26 0809604 [10]   SPRING
27 0251319 [4]   PIN
33 0168008 [9]   BOLT;SOCKET
51 +++++++ [1]   NAME-PLATE
52 +++++++ [2]   SCREW;DRIVE
400 0802602 [1]   PLATE ASS'Y NOTE) The KIT;SEAL of this system is indicated at ｢MOTOR;OIL(1/2)｣.
