HITACHI 4309476 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

HITACHI 4309476 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
4309476
EX22 EX25 EX30UR EX30UR-2 EX30UR-2C
Pos. Part No Qty Parts name Comments
4309476 [1]   MOTOR;OIL (1/3) This PART NO. consists of all parts shown in MOTOR;OIL(1/3) to (3/3).
2 0436401 [1]   SHAFT
3 0436402 [1]   BAG.;BALL
4 0436403 [1]   SEAL;OIL
5 0472301 [1]   PLATE
6 0436405 [2]   BALL;STEEL
7 +++++++ [1]   BLOCK;CYL.
8 0436406 [1]   WASHER
9 0436407 [1]   SPRING
10 0436408 [1]   SEAT;SPRING
11 0436409 [1]   RING;RETAINING
12 0436410 [3]   PIN
13 0436411 [1]   HOLDER
14 0436412 [1]   PLATE
15 +++++++ [9]   PISTON ASSY
19 +++++++ [2]   PISTON ASSY
20 0436413 [2]   SPRING
25 0436414 [1]   PLATE;VALVE
26 0472302 [1]   PIN
27 0436415 [1]   BRG.;BALL
28 A810120 [1]   O-RING
29 4506407 [3]   O-RING
49 0397910 [2]   PIN
Parts on group MOTOR;OIL (3/3):
Pos. Part No Qty Parts name Comments
4309476 [1]   MOTOR;OIL (3/3) This PART NO. consists of all parts shown in MOTOR;OIL(1/3) to (3/3).
30 +++++++ [1]   BASE
31 +++++++ [1]   PLUNGER ASSY
31A. +++++++ [1]   PLUNGER
31B. 0398001 [2]   VALVE;CHECK
31C. 0398002 [2]   SPRING
31D. 0398003 [2]   PLUG
31E. 4506320 [2]   O-RING
36 0398004 [2]   SEAT;SPRING
37 0398005 [2]   SPRING
38 0398006 [2]   CAP
39 4506429 [2]   O-RING
40 0436601 [2]   ORIFICE
41 +++++++ [1]   SPOOL
42 0436602 [1]   SPRING
43 0311336 [2]   PLUG
44 4509180 [2]   O-RING
45 0352225 [3]   PLUG
47 0436603 [4]   ORIFICE
48 0167922 [6]   BOLT;SOCKET
50 0436604 [1]   BLOCK;VALVE ASSY
50-1. 0436605 [1]   BODY;VALVE
50-2. 0436606 [2]   VALVE;RELIEF ASSY
50-2A. +++++++ [1]   HOUSING
50-2B. +++++++ [1]   POPPET
50-2C. +++++++ [1]   SEAT;POPPET
50-2D. +++++++ [1]   SEAT;SPRING
50-2E. +++++++ [1]   SPRING
50-2F. +++++++ [1]   PLUG
50-2G. 4506424 [1]   O-RING
50-2H. 4506412 [1]   O-RING
50-2I. 4027963 [2]   RING;BACK-UP
50-2J. 0436607 [1]   PISTON
50-2K. 4506415 [1]   O-RING
50-2L. 0398010 [2]   RING;BACK-UP
50-2M. 0398011 [1]   SHIM
50-2M. 0472501 [1]   SHIM
50-3. 4506407 [3]   O-RING
50-4. 4506416 [2]   O-RING
50-5. 0310310 [4]   BOLT;SOCKET
50-6. 94-2011 [2]   PLUG
51 +++++++ [1]   NAME-PLATE
52 +++++++ [2]   SCREW;DRIVE
53 +++++++ [2]   PLUG
54 +++++++ [1]   PLUG
55 0436608 [2]   PLUG
56 957366 [2]   O-RING
