HITACHI 4266817 HYDRAULIC PUMP PARTS

HITACHI 4266817 HYDRAULIC PUMP PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
4266817
EX30UR
Pos. Part No Qty Parts name Comments
0 4266817 [1]   PUMP;PISTON
1 J011235 [2]   BOLT;SEMS
4 7025182 [1]   COVER;PUMP
5 J901030 [6]   BOLT
6 J950010 [2]   NUT
7 A590910 [8]   WASHER;SPRING
9 4277337 [1]   COUPLING;RUBBER
10 3059556 [1]   COUPLING
11 4245228 [1]   SEAL;OIL
12 A882030 [1]   PLUG
Parts on group PUMP;PISTON (1/2):
Pos. Part No Qty Parts name Comments
4266817 [1]   PUMP;PISTON (1/2) This PART NO. consists of all parts shown in PUMP;PISTON(1/2) to (2/2).
2 +++++++ [1]   BODY
15 +++++++ [1]   SPRING
19 +++++++ [1]   ROD;PUSH
27 985098 [1]   O-RING
30 0473905 [5]   BOLT;SOCKET
32 0476901 [1]   SCREW
33 0476902 [1]   NUT
34 A590910 [5]   WASHER;SPRING
39 +++++++ [1]   BODY
40 +++++++ [1]   GEAR
41 +++++++ [1]   GEAR
42 +++++++ [2]   BUSHING
43 +++++++ [2]   BUSHING
44 4509181 [4]   O-RING
45 A811050 [1]   O-RING
46 0429724 [2]   PIN
47 0429725 [4]   BOLT;SOCKET
48 0476101 [4]   WASHER;SPRING
Parts on group PUMP;PISTON (2/2):
Pos. Part No Qty Parts name Comments
4266817 [1]   PUMP;PISTON (2/2) This PART NO. consists of all parts shown in PUMP;PISTON(1/2) to (2/2).
1 +++++++ [1]   BODY
3 +++++++ [1]   SHAFT
4 +++++++ [1]   BLOCK
5 +++++++ [1]   PLATE;VALVE
6 +++++++ [10]   PISTON
7 +++++++ [10]   SHOE
8 +++++++ [1]   HOLDER
9 +++++++ [1]   HOLDER
10 +++++++ [1]   PLATE;SWASH
11 +++++++ [3]   NEEDLE
12 +++++++ [2]   PIN
13 0477001 [1]   PACKING
14 +++++++ [1]   SPRING
16 +++++++ [1]   PIN
17 +++++++ [1]   PIN
18 +++++++ [2]   RETAINER
20 +++++++ [2]   PIN
21 0477002 [1]   BRG.;BALL
22 0429818 [1]   BRG.;NEEDLE
23 0429819 [1]   SEAL;OIL
24 991722 [1]   RING;RETAINING
25 0477003 [1]   RING;RETAINING
26 942517 [1]   RING;RETAINING
28 957366 [1]   O-RING
29 +++++++ [2]   WASHER
31 J75382 [1]   PLUG
35 0429826 [1]   PIN;SPRING
36 +++++++ [2]   SPRING;FLUSH
37 +++++++ [2]   SPRING;FLUSH
