HITACHI 270CLCJD EX200-5ZJPN EX270-5 EX280H-5 ZX270 ZX270-HHE ZX280LC-AMS ZX280LC-HCME EXCAVATOR 9150848 9156041 TRAVEL DEVICE

HITACHI 270CLCJD EX200-5ZJPN EX270-5 EX280H-5 ZX270 ZX270-HHE ZX280LC-AMS ZX280LC-HCME EXCAVATOR 9150848 9156041 TRAVEL DEVICE

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL DEVICE:
Pos. Part No Qty Parts name Comments
9185359 [2]   TRAVEL DEVICE I 9185360 (for assembly of machine)
9230046 [2]   TRAVEL DEVICE I 9232359 (for assembly of machine)
9185360 [2]   TRAVEL DEVICE (for transportation)
9232359 [2]   TRAVEL DEVICE (for transportation)
0 9150848 [1]   MOTOR;OIL I 9156041 (for assembly of machine)
0 9214849 [1]   MOTOR;OIL I 9231672 (for assembly of machine)
0 9156041 [1]   MOTOR;OIL (for transportation)
0 9231672 [1]   MOTOR;OIL (for transportation)
2 1022194 [1]   HOUSING
3 4066695 [1]   SEAL;GROUP
4 4192975 [2]   BRG.;ROL.
5 1022179 [1]   DRUM
6 1022168 [1]   SPROCKET
7 A590920 [20]   WASHER;SPRING
8 J932060 [20]   BOLT
10 3036256 [1]   NUT
10 3094717 [1]   NUT
11 4192974 [1]   PLATE;LOCK
11 4470326 [1]   PLATE;LOCK
12 J901222 [2]   BOLT I J901225
12 J901225 [2]   BOLT
13 4401293 [3]   SPACER
14 1022198 [1]   CARRIER
16 3075003 [3]   GEAR;PLANETARY
17 4455088 [6]   BRG.;NEEDLE
18 4269470 [6]   PLATE;THRUST
19 4269452 [3]   PIN
20 4192021 [3]   PIN;SPRING
21 3075005 [1]   GEAR;SUN
23 1022195 [1]   GEAR;RING
24 J931640 [28]   BOLT
25 4455099 [3]   BRG.;NEEDLE
26 1022197 [1]   CARRIER
27 3075002 [3]   GEAR;PLANETARY
29 4284521 [6]   PLATE;THRUST
30 4269451 [3]   PIN
31 4197763 [3]   PIN;SPRING
32 3074989 [1]   GEAR;SUN
34 1022196 [1]   CARRIER
36 3075001 [3]   GEAR;PLANETARY
38 4284520 [6]   PLATE;THRUST
39 4269472 [3]   PIN
40 4192020 [3]   PIN;SPRING
41 2038915 [1]   SHAFT;PROP.
41 2048000 [1]   SHAFT;PROP.
44 4277474 [1]   PIN;STOPPER
45 4278168 [1]   BRG.;BALL
46 930451 [1]   RING;RETAINING
47 J011230 [16]   BOLT;SEMS I 4609016
47 4609016 [16]   BOLT;SEMS
48 4245797 [3]   PLUG
49 2045031 [1]   COVER
50 4269473 [1]   O-RING
51 4287213 [4]   WASHER;SPRING
52 M341885 [4]   BOLT;SOCKET
53 4455098 [3]   BRG.;NEEDLE
54 +++++++ [1]   NAME-PLATE
55 M492564 [2]   SCREW;DRIVE
