HIATCHI 4269355 SWING MOTOR ROTARY GROUP

HIATCHI 4269355 SWING MOTOR ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
4269355
EX22 EX25 EX30UR EX30UR-2 EX30UR-2C
Pos. Part No Qty Parts name Comments
4269355 [1]   MOTOR;OIL (2/3) This PART NO. consists of all parts shown in MOTOR;OIL(1/3) to (3/3).
101 0434601 [1]   CASE
103 +++++++ [1]   BLOCK;CYL.
104 0434602 [1]   SHAFT
105 0397914 [1]   PLATE;VALVE
106 +++++++ [9]   PISTON
107 0397909 [1]   PLATE
108 0397908 [1]   HOLDER
109 0396807 [1]   PLATE;THRUST
111 0434004 [1]   BRG.;BALL
112 0397915 [1]   BRG.;BALL
113 0434005 [3]   PIN
114 0397905 [1]   COLLAR
115 0434006 [1]   SPRING
116 0434007 [1]   WASHER
117 0396815 [1]   RING;RETAINING
118 0396814 [2]   PIN
119 0396703 [1]   PIN
121 094-2010 [1]   PLUG
122 0434008 [1]   O-RING
123 A811125 [1]   O-RING
300 0167923 [4]   BOLT;SOCKET
500 0434009 [1]   BLOCK;CYL. KIT
Parts on group MOTOR;OIL (3/3):
Pos. Part No Qty Parts name Comments
4269355 [1]   MOTOR;OIL (3/3) This PART NO. consists of all parts shown in MOTOR;OIL(1/3) to (3/3).
102 0434701 [1]   VALVE ASSY
102-1. 0434102 [1]   BODY
102-2. 0158849 [2]   VALVE;CHECK
102-3. 0434103 [2]   SPRING
102-4. 0311336 [3]   PLUG
102-5. 0434702 [2]   VALVE;RELIEF ASSY
102-5A. 4506424 [1]   O-RING
102-6. +++++++ [1]   NAME-PLATE
102-7. +++++++ [2]   SCREW;DRIVE
102-8. 4509180 [3]   O-RING
102-9. 94-2010 [2]   PLUG
120 M341245 [3]   BOLT;SOCKET
