TM100VD travel motor parts

TM100VD travel motor parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。

Nabtesco GM70 TM70 TM100 hydraulic final drive motor parts used for Daewoo DH420, XCMG XE335 excavator

DNB60 K1003132 DX340LC DX350LC
Pos. Part No Qty Parts name Comments
*. 2401-9264KT [1]   SEAL KIT;MOTOR
-. K1003132 [2]   TRAVEL MOTOR
-. 170403-00104 [2]
101 K9002261 [1]   SHAFT;DRIVE   K9002261A
101 K9002261A [1]   SHAFT;DRIVE
102 109-00143 [1]   BEARING;ROLLER   K9009896
102 K9009896 [1]   BEARING;ROLLER
103 109-00144 [1]   BEARING;NEEDLE
107 S6500500 [1]   RING;STOP
11 410-00011 [1]   CYLINDER ASS'Y
113 408-00021 [1]   BUSH
114 129-00096 [9]   SPRING;CYLINDER
12 409-00033 [1]   PISTON ASS'Y
123 412-00034 [1]   PLATE;SET
13 423-00081 [1]   VALVE CASING ASS'Y
14 409-00034 [1]   TILTING PISTON ASS'Y
201 K9002262 [1]   PLATE;SWASH
22 424-00085 [1]   SPOOL;COUNTER BALANCE
22 424-00147 [1]   SPOOL;COUNTER BALANCE   424-00147A
22 424-00147A [1]
272 K9002263 [1]   CASING;SHAFT
272 110913-00097 [1]
350 420-00195 [2]   VALVE;RELIEF   420-00195A
350 420-00195A [2]
351 420-00196 [1]   VALVE;REDUCING
352 430-00025 [1]   COVER
361 114-00345 [2]   WASHER
362 129-00097 [2]   SPRING;COUNTER BALANCE
364 403-00005 [2]   COVER;COUNTER BALANCE
365 S8010451 [2]   O-RING
366 S2215561 [8]   BOLT;SOCKET
401 S2228671 [2]   BOULON A 6 PANS CREUX
402 S2227661 [4]   BOLT;SOCKET
435 S6510900 [1]   RING;SNAP
461 181-00519 [14]   PLUG   2181-1116D10
461 181-00318 [14]   BOLT;SOCKER
464 2181-1950D3 [2]   PLUG
472 1.180-00159 [1]   O-RING
485 S8000181 [2]   O-RING
491 2180-8002A [1]   JOINT TORIQUE
504 148-00019 [2]   BALL;PIVOT
509 S8000181 [1]   O-RING
509 S8000161 [1]   O-RING
531 424-00086 [1]   SPOOL;TILTING
533 129-00098 [1]   SPRING;TILTING
541 429-00021 [1]   SEAT
542 416-00012 [1]   STOPPER
543 S6250132 [1]   BALL;STEEL
545 415-00032 [1]   ORIFICE   430219-00013
545 430219-00013 [1]
546 415-00033 [1]   ORIFICE   430219-00012
546 430219-00012 [1]
547 S8000111 [2]   O-RING
564 2181-1116D2 [2]   PLUG
567 2181-1950D1 [4]   PLUG
569 2181-1890D2 [2]   PLUG
570 S8000111 [6]   O-RING
571 2181-1890D3 [1]   PLUG
572 S8000141 [1]   O-RING
702 452-00023 [1]   PISTON;BRAKE   452-00023A
702 452-00023A [1]
703 415-00034 [1]   ORIFICE
704 415-00035 [1]   ORIFICE
705 129-00062 [14]   SPRING;BRAKE
705 129-00062 [18]   SPRING;BRAKE
707 2180-1217D156 [1]   O-RING
708 1.180-00161 [1]   O-RING
741 412-00036 [3]   PLATE;SEPARATOR
742 412-00037 [2]   PLATE;FRICTION
31NA-40020BG 31NA-40021 31NA-40022 XKAH-00939 XKAH-01617 R360LC-7 R360LC-7A R370LC-7
Pos. Part No Qty Parts name Comments
*. 31NA-40020BG [1]   TRAVEL MOTOR      *-1,*-2
*. 31NA-40021 [1]   TRAVEL MOTOR      *-1,*-2
*. 31NA-40022 [1]   TRAVEL MOTOR      *-1,*-2
N*-1. XKAH-00939 [1]   TRAVEL MOTOR UNIT
N*-1. XKAH-01617 [1]   TRAVEL MOTOR UNIT
22 XKAH-00940 [1]   SPOOL-CBV
22 XKAH-01601 [1]   SPOOL-COUNTERBALANCE
101 XKAH-00941 [1]   SHAFT-DRIVE
101 XKAH-01602 [1]   SHAFT-DRIVE
102 XKAH-00942 [1]   BEARING-ROLLER
103 XKAH-00943 [1]   BEARING-NEEDLE
107 XKAH-00944 [1]   RING-SNAP
S111. XKAH-00945 [1]   BLOCK-CYLINDER
S111. XKAH-01603 [1]   BLOCK-CYLINDER
113 XKAH-00946 [1]   BUSHING-SPHERICAL
114 XKAH-00947 [9]   SPRING-CYLINDER
NS121. XKAH-00948 [9]   PISTON
NS122. XKAH-00949 [9]   SHOE
NS122. XKAH-00153 [9]   SHOE
123 XKAH-00950 [1]   PLATE-SET
S131. XKAH-00951 [1]   PLATE-VALVE
S131. XKAH-01604 [1]   PLATE-VALVE
201 XKAH-00952 [1]   PLATE-SWASH
NS272. XKAH-01436 [1]   CASING-SHAFT
NS303. XKAH-00954 [1]   CASING A-VALVE
NS303. XKAH-01599 [1]   CASING A-VALVE
350 XKAH-00955 [2]   VALVE-RELIEF
350 XKAH-01605 [2]   VALVE-RELIEF
351 XKAH-00956 [2]   VALVE-REDUCING
351 XKAH-00956 [1]   VALVE-REDUCING
352 XKAH-00957 [2]   COVER
352 XKAH-00957 [1]   COVER
361 XKAH-00958 [2]   WASHER
362 XKAH-00959 [2]   SPRING-COUNTERBALANCE
364 XKAH-00960 [2]   COVER-COUNTERBALANCE
K365. XKAH-00961 [2]   O-RING
366 XKAH-00962 [8]   BOLT-SOCKET
401 XKAH-00963 [2]   BOLT-SOCKET
402 XKAH-00964 [4]   BOLT-SOCKET
435 XKAH-00965 [1]   RING-SNAP
S451. XKAH-00187 [1]   PIN
S451. XKAH-00187 [2]   PIN
461 XKAH-00208 [14]   PLUG-PT
461 XKAH-00625 [14]   PLUG-PT
464 XKAH-00966 [2]   PLUG-VP
K472. XKAH-00967 [1]   O-RING
K485. XKAH-00035 [2]   O-RING
K491. XKAH-00968 [1]   SEAL-OIL
NS502. XKAH-00969 [1]   PISTON
NS503. XKAH-00153 [1]   SHOE
NS503. XKAH-01561 [1]   SHOE
504 XKAH-00970 [2]   BALL-PIVOT
504 XKAH-01606 [1]   BALL-PIVOT
K509. XKAH-00035 [1]   O-RING
531 XKAH-00971 [1]   SPOOL-TILTING
531 XKAH-01607 [1]   SPOOL-TILTING
533 XKAH-00972 [1]   SPRING-TILTING
541 XKAH-00973 [1]   SEAT-2A
542 XKAH-00974 [1]   STOPPER
543 XKAH-00199 [1]   BALL-STEEL
545 XKAH-00975 [1]   ORIFICE
545 XKAH-01566 [1]   ORIFICE
546 XKAH-00976 [1]   ORIFICE
546 XKAH-01565 [1]   ORIFICE
K547. XKAH-00261 [2]   O-RING
564 XKAH-00977 [2]   PLUG
567 XKAH-00136 [4]   PLUG-VP
569 XKAH-00710 [2]   PLUG-RO
K570. XKAH-00052 [6]   O-RING
571 XKAH-00978 [1]   PLUG-RO
K572. XKAH-00053 [1]   O-RING
K572. XKAH-00326 [1]   O-RING
702 XKAH-00979 [1]   PISTON-BRAKE
702 XKAH-01600 [1]   PISTON-BRAKE
703 XKAH-00980 [1]   ORIFICE
704 XKAH-00981 [1]   ORIFICE
705 XKAH-00127 [14]   SPRING-BRAKE
705 XKAH-00127 [18]   SPRING-BRAKE
K707. XKAH-00133 [1]   O-RING
K708. XKAH-00982 [1]   O-RING
741 XKAH-00983 [1]   PLATE-SEPARATION
741 XKAH-00983 [3]   PLATE-SEPARATION
742 XKAH-00984 [2]   PLATE-FRICTION
N801. XKAH-00985 [1]   NAME PLATE
801 XKAH-01482 [1]   NAME PLATE      SEE 4130
N802. XKAH-00986 [2]   SCREW-RIVET      SEE 4130
*-2. @ [1]   T/REDUCTION GEAR      SEE 4130
K. XKAH-01031 [1]   SEAL KIT      SEE ILLUST
11 XKAH-01030 [1]   SUB ASSY-TILTING PISTON      SEE ILLUST
12 XKAH-01029 [1]   SUB ASSY-VALVE CASING      SEE ILLUST
13 XKAH-01028 [1]   SUB ASSY-CYLINDER      SEE ILLUST
14 XKAH-01027 [1]   SUB ASSY-PISTON      SEE ILLUST



4688059 ROTARY GROUP 853403 ZX670LC-5B ZX670LC-5G ZX670LCH-5B ZX670LCH-5G ZX670LCR-5G ZX870-5G ZX870H-5G ZX870LC-5B ZX870LC-5G ZX870LCH-5G ZX870LCR-5G  EX1200-6
Pos. Part No Qty Parts name Comments
4688059 [1]   MOTOR;OIL (1/2)
1 +++++++ [1]   CASE
3 809501 [1]   SHAFT
4 +++++++ [1]   CYL.
5 +++++++ [1]   PLATE
6 +++++++ [9]   PISTON
7 +++++++ [1]   PLATE
8 +++++++ [1]   HOLDER
9 809502 [1]   PLATE ASS'Y
10 682706 [2]   BALL;STEEL
11 +++++++ [2]   PISTON
12 809503 [2]   SPRING
13 809504 [1]   BRG.;ROL.
14 809505 [1]   BRG.;ROL.
15 809506 [1]   COLLAR
17 806502 [9]   SPRING
18 979001 [2]   PLATE;FRICTION
19 419808 [5]   PLATE;DISC
20 981602 [4]   PLATE;FRICTION
21 809509 [1]   PISTON;BRAKE
22 411419 [1]   O-RING
23 809510 [1]   RING;BACK-UP
24 419806 [1]   O-RING
25 419812 [1]   RING;BACK-UP
28 979002 [1]   SEAL;OIL
29 A811260 [1]   O-RING
30 4506320 [4]   O-RING
31 809511 [2]   PLUG
32 4506424 [2]   O-RING
34 +++++++ [2]   PLUG
100 853403 [1]   CYL. ASS'Y
200 809513 [1]   RETAINER ASS'Y
300 809514 [1]   CASE
500 979004 [1]   KIT;SEAL
2-7. 806602 [2]   VALVE;RELIEF
