GM70 TM70 TM100VD XE335 DH340 travel motor valve plate

GM70 TM70 TM100VD XE335 DH340 travel motor valve plate

$200.00 USD
$200.00 USD
特價 售罄
結帳時計算運費。
DNB60 K1003132 DX340LC DX350LC
Pos. Part No Qty Parts name Comments
*. 2401-9264KT [1]   SEAL KIT;MOTOR
-. K1003132 [2]   TRAVEL MOTOR
-. 170403-00104 [2]
101 K9002261 [1]   SHAFT;DRIVE   K9002261A
101 K9002261A [1]   SHAFT;DRIVE
102 109-00143 [1]   BEARING;ROLLER   K9009896
102 K9009896 [1]   BEARING;ROLLER
103 109-00144 [1]   BEARING;NEEDLE
107 S6500500 [1]   RING;STOP
11 410-00011 [1]   CYLINDER ASS'Y
113 408-00021 [1]   BUSH
114 129-00096 [9]   SPRING;CYLINDER
12 409-00033 [1]   PISTON ASS'Y
123 412-00034 [1]   PLATE;SET
13 423-00081 [1]   VALVE CASING ASS'Y
14 409-00034 [1]   TILTING PISTON ASS'Y
201 K9002262 [1]   PLATE;SWASH
22 424-00085 [1]   SPOOL;COUNTER BALANCE
22 424-00147 [1]   SPOOL;COUNTER BALANCE   424-00147A
22 424-00147A [1]
272 K9002263 [1]   CASING;SHAFT
272 110913-00097 [1]
350 420-00195 [2]   VALVE;RELIEF   420-00195A
350 420-00195A [2]
351 420-00196 [1]   VALVE;REDUCING
352 430-00025 [1]   COVER
361 114-00345 [2]   WASHER
362 129-00097 [2]   SPRING;COUNTER BALANCE
364 403-00005 [2]   COVER;COUNTER BALANCE
365 S8010451 [2]   O-RING
366 S2215561 [8]   BOLT;SOCKET
401 S2228671 [2]   BOULON A 6 PANS CREUX
402 S2227661 [4]   BOLT;SOCKET
435 S6510900 [1]   RING;SNAP
461 181-00519 [14]   PLUG   2181-1116D10
461 181-00318 [14]   BOLT;SOCKER
464 2181-1950D3 [2]   PLUG
472 1.180-00159 [1]   O-RING
485 S8000181 [2]   O-RING
491 2180-8002A [1]   JOINT TORIQUE
504 148-00019 [2]   BALL;PIVOT
509 S8000181 [1]   O-RING
509 S8000161 [1]   O-RING
531 424-00086 [1]   SPOOL;TILTING
533 129-00098 [1]   SPRING;TILTING
541 429-00021 [1]   SEAT
542 416-00012 [1]   STOPPER
543 S6250132 [1]   BALL;STEEL
545 415-00032 [1]   ORIFICE   430219-00013
545 430219-00013 [1]
546 415-00033 [1]   ORIFICE   430219-00012
546 430219-00012 [1]
547 S8000111 [2]   O-RING
564 2181-1116D2 [2]   PLUG
567 2181-1950D1 [4]   PLUG
569 2181-1890D2 [2]   PLUG
570 S8000111 [6]   O-RING
571 2181-1890D3 [1]   PLUG
572 S8000141 [1]   O-RING
702 452-00023 [1]   PISTON;BRAKE   452-00023A
702 452-00023A [1]
703 415-00034 [1]   ORIFICE
704 415-00035 [1]   ORIFICE
705 129-00062 [14]   SPRING;BRAKE
705 129-00062 [18]   SPRING;BRAKE
707 2180-1217D156 [1]   O-RING
708 1.180-00161 [1]   O-RING
741 412-00036 [3]   PLATE;SEPARATOR
742 412-00037 [2]   PLATE;FRICTION
31NA-40020BG 31NA-40021 31NA-40022 XKAH-00939 XKAH-01617 R360LC-7 R360LC-7A R370LC-7
Pos. Part No Qty Parts name Comments
*. 31NA-40020BG [1]   TRAVEL MOTOR      *-1,*-2
*. 31NA-40021 [1]   TRAVEL MOTOR      *-1,*-2
*. 31NA-40022 [1]   TRAVEL MOTOR      *-1,*-2
N*-1. XKAH-00939 [1]   TRAVEL MOTOR UNIT
N*-1. XKAH-01617 [1]   TRAVEL MOTOR UNIT
22 XKAH-00940 [1]   SPOOL-CBV
22 XKAH-01601 [1]   SPOOL-COUNTERBALANCE
101 XKAH-00941 [1]   SHAFT-DRIVE
101 XKAH-01602 [1]   SHAFT-DRIVE
102 XKAH-00942 [1]   BEARING-ROLLER
103 XKAH-00943 [1]   BEARING-NEEDLE
107 XKAH-00944 [1]   RING-SNAP
S111. XKAH-00945 [1]   BLOCK-CYLINDER
S111. XKAH-01603 [1]   BLOCK-CYLINDER
113 XKAH-00946 [1]   BUSHING-SPHERICAL
114 XKAH-00947 [9]   SPRING-CYLINDER
NS121. XKAH-00948 [9]   PISTON
NS122. XKAH-00949 [9]   SHOE
NS122. XKAH-00153 [9]   SHOE
123 XKAH-00950 [1]   PLATE-SET
S131. XKAH-00951 [1]   PLATE-VALVE
S131. XKAH-01604 [1]   PLATE-VALVE
201 XKAH-00952 [1]   PLATE-SWASH
NS272. XKAH-01436 [1]   CASING-SHAFT
NS303. XKAH-00954 [1]   CASING A-VALVE
NS303. XKAH-01599 [1]   CASING A-VALVE
350 XKAH-00955 [2]   VALVE-RELIEF
350 XKAH-01605 [2]   VALVE-RELIEF
351 XKAH-00956 [2]   VALVE-REDUCING
351 XKAH-00956 [1]   VALVE-REDUCING
352 XKAH-00957 [2]   COVER
352 XKAH-00957 [1]   COVER
361 XKAH-00958 [2]   WASHER
362 XKAH-00959 [2]   SPRING-COUNTERBALANCE
364 XKAH-00960 [2]   COVER-COUNTERBALANCE
K365. XKAH-00961 [2]   O-RING
366 XKAH-00962 [8]   BOLT-SOCKET
401 XKAH-00963 [2]   BOLT-SOCKET
402 XKAH-00964 [4]   BOLT-SOCKET
435 XKAH-00965 [1]   RING-SNAP
S451. XKAH-00187 [1]   PIN
S451. XKAH-00187 [2]   PIN
461 XKAH-00208 [14]   PLUG-PT
461 XKAH-00625 [14]   PLUG-PT
464 XKAH-00966 [2]   PLUG-VP
K472. XKAH-00967 [1]   O-RING
K485. XKAH-00035 [2]   O-RING
K491. XKAH-00968 [1]   SEAL-OIL
NS502. XKAH-00969 [1]   PISTON
NS503. XKAH-00153 [1]   SHOE
NS503. XKAH-01561 [1]   SHOE
504 XKAH-00970 [2]   BALL-PIVOT
504 XKAH-01606 [1]   BALL-PIVOT
K509. XKAH-00035 [1]   O-RING
531 XKAH-00971 [1]   SPOOL-TILTING
531 XKAH-01607 [1]   SPOOL-TILTING
533 XKAH-00972 [1]   SPRING-TILTING
541 XKAH-00973 [1]   SEAT-2A
542 XKAH-00974 [1]   STOPPER
543 XKAH-00199 [1]   BALL-STEEL
545 XKAH-00975 [1]   ORIFICE
545 XKAH-01566 [1]   ORIFICE
546 XKAH-00976 [1]   ORIFICE
546 XKAH-01565 [1]   ORIFICE
K547. XKAH-00261 [2]   O-RING
564 XKAH-00977 [2]   PLUG
567 XKAH-00136 [4]   PLUG-VP
569 XKAH-00710 [2]   PLUG-RO
K570. XKAH-00052 [6]   O-RING
571 XKAH-00978 [1]   PLUG-RO
K572. XKAH-00053 [1]   O-RING
K572. XKAH-00326 [1]   O-RING
702 XKAH-00979 [1]   PISTON-BRAKE
702 XKAH-01600 [1]   PISTON-BRAKE
703 XKAH-00980 [1]   ORIFICE
704 XKAH-00981 [1]   ORIFICE
705 XKAH-00127 [14]   SPRING-BRAKE
705 XKAH-00127 [18]   SPRING-BRAKE
K707. XKAH-00133 [1]   O-RING
K708. XKAH-00982 [1]   O-RING
741 XKAH-00983 [1]   PLATE-SEPARATION
741 XKAH-00983 [3]   PLATE-SEPARATION
742 XKAH-00984 [2]   PLATE-FRICTION
N801. XKAH-00985 [1]   NAME PLATE
801 XKAH-01482 [1]   NAME PLATE      SEE 4130
N802. XKAH-00986 [2]   SCREW-RIVET      SEE 4130
*-2. @ [1]   T/REDUCTION GEAR      SEE 4130
K. XKAH-01031 [1]   SEAL KIT      SEE ILLUST
11 XKAH-01030 [1]   SUB ASSY-TILTING PISTON      SEE ILLUST
12 XKAH-01029 [1]   SUB ASSY-VALVE CASING      SEE ILLUST
13 XKAH-01028 [1]   SUB ASSY-CYLINDER      SEE ILLUST
14 XKAH-01027 [1]   SUB ASSY-PISTON      SEE ILLUST
