DNB60B travel motor parts

Name: DNB60B travel motor parts
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

DNB60B travel motor parts

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

EC360B TM60VC MBEB227 MBEB379 DNB60B GM50VA EC360 GM50VA TM50 DH280-3 DH300-5 DH340-3

DNB60 K1003132 DX340LC DX350LC

Pos.	Part No	Qty	Parts name	Comments
*.	2401-9264KT	[1]	SEAL KIT;MOTOR
-.	K1003132	[2]	TRAVEL MOTOR
-.	170403-00104	[2]
101	K9002261	[1]	SHAFT;DRIVE	K9002261A
101	K9002261A	[1]	SHAFT;DRIVE
102	109-00143	[1]	BEARING;ROLLER	K9009896
102	K9009896	[1]	BEARING;ROLLER
103	109-00144	[1]	BEARING;NEEDLE
107	S6500500	[1]	RING;STOP
11	410-00011	[1]	CYLINDER ASS'Y
113	408-00021	[1]	BUSH
114	129-00096	[9]	SPRING;CYLINDER
12	409-00033	[1]	PISTON ASS'Y
123	412-00034	[1]	PLATE;SET
13	423-00081	[1]	VALVE CASING ASS'Y
14	409-00034	[1]	TILTING PISTON ASS'Y
201	K9002262	[1]	PLATE;SWASH
22	424-00085	[1]	SPOOL;COUNTER BALANCE
22	424-00147	[1]	SPOOL;COUNTER BALANCE	424-00147A
22	424-00147A	[1]
272	K9002263	[1]	CASING;SHAFT
272	110913-00097	[1]
350	420-00195	[2]	VALVE;RELIEF	420-00195A
350	420-00195A	[2]
351	420-00196	[1]	VALVE;REDUCING
352	430-00025	[1]	COVER
361	114-00345	[2]	WASHER
362	129-00097	[2]	SPRING;COUNTER BALANCE
364	403-00005	[2]	COVER;COUNTER BALANCE
365	S8010451	[2]	O-RING
366	S2215561	[8]	BOLT;SOCKET
401	S2228671	[2]	BOULON A 6 PANS CREUX
402	S2227661	[4]	BOLT;SOCKET
435	S6510900	[1]	RING;SNAP
461	181-00519	[14]	PLUG	2181-1116D10
461	181-00318	[14]	BOLT;SOCKER
464	2181-1950D3	[2]	PLUG
472	1.180-00159	[1]	O-RING
485	S8000181	[2]	O-RING
491	2180-8002A	[1]	JOINT TORIQUE
504	148-00019	[2]	BALL;PIVOT
509	S8000181	[1]	O-RING
509	S8000161	[1]	O-RING
531	424-00086	[1]	SPOOL;TILTING
533	129-00098	[1]	SPRING;TILTING
541	429-00021	[1]	SEAT
542	416-00012	[1]	STOPPER
543	S6250132	[1]	BALL;STEEL
545	415-00032	[1]	ORIFICE	430219-00013
545	430219-00013	[1]
546	415-00033	[1]	ORIFICE	430219-00012
546	430219-00012	[1]
547	S8000111	[2]	O-RING
564	2181-1116D2	[2]	PLUG
567	2181-1950D1	[4]	PLUG
569	2181-1890D2	[2]	PLUG
570	S8000111	[6]	O-RING
571	2181-1890D3	[1]	PLUG
572	S8000141	[1]	O-RING
702	452-00023	[1]	PISTON;BRAKE	452-00023A
702	452-00023A	[1]
703	415-00034	[1]	ORIFICE
704	415-00035	[1]	ORIFICE
705	129-00062	[14]	SPRING;BRAKE
705	129-00062	[18]	SPRING;BRAKE
707	2180-1217D156	[1]	O-RING
708	1.180-00161	[1]	O-RING
741	412-00036	[3]	PLATE;SEPARATOR
742	412-00037	[2]	PLATE;FRICTION

Parts on group DX300LC-5(S/N:1001~1057):

Pos.	Part No	Qty	Parts name	Comments
*.	401107-01052	[1]
1	*NA00915	[1]	REAR FLANGE
12	110910-00379	[2]
13	S8010451	[2]	O-RING
14	S2215561	[8]	BOLT;SOCKET
2	410207-00242	[1]
200	150102-00381A	[1]
201	130602-00679	[1]
202	130712-00651	[1]
203	400901-00038	[1]
204	*NA00423	[1]
207	110943-00045	[1]
208	110202-00040	[1]
209	250201-01443	[1]
210	1.131-00042	[1]	SPRING
212	130602-00680	[1]
213	1.131-00049	[14]	SPRING
214	111601-00355	[9]
215	130113-00019	[4]
216	250201-01442	[3]
230	2180-1217D164	[1]
231	2180-1217D160	[1]	O-RING
232	401106-00204	[1]
233	S8000081	[2]	O-RING
236	S6511000	[1]	RING;LOCK
237	S6500550	[1]	RING;RETAINER
249	1.109-00066	[1]	BEARING;ROLLER
26	2180-1217D163	[1]
260	130602-00681A	[1]
267	101560-00006	[2]
41	123-00153	[1]
43	S2227561	[8]	BOLT;SOCKET
50	109-00144	[1]	BEARING;NEEDLE
500	420-00196	[1]	VALVE;REDUCING
501	430-00025	[1]	COVER
502	410127-00136	[2]
52	2181-1890D2	[4]	PLUG
54	181-00318	[6]	BOLT;SOCKER
56	2181-1950D1	[2]	PLUG
6	111601-00353	[2]
65	410207-00243	[1]
66	111601-00354	[1]	SPRING
68	S6250182	[2]	BALL
7	120808-00420	[2]
71	415-00034	[1]	ORIFICE
72	430219-00012	[1]
73	430219-00013	[1]
74	S8000111	[4]	O-RING
75	415-00035	[1]	ORIFICE
82	2181-1890D4	[1]	PLUG
83	S8000181	[1]	O-RING
C.	430215-00463A	[1]
