NABTESCO GM35VL travel motor set plate retainer plate retainer shoe

NABTESCO GM35VL travel motor set plate retainer plate retainer shoe

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
GM35VL R210LC-7 (EM140 & ￠25.5)
31N6-40010 31N6-40011 31EM-40011 XKAH-00373 XKAH-00455 CYLINDER KIT&PISTON KIT XKAH-00321 R210LC-3 R210LC-3H R210LC-7 R210NLC-7
Komatsu PC200-6 PC200-7 PC200-8
Hyundai R210-5 R210-7,Volvo EC210 EC240B,Daewoo DH220-3 DH220-5 DH225-5,Kobelco SK200-6 excavator
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL MOTOR ASSY      SEE ILLUST
*-1. @ [1]   TRAVEL MOTOR UNIT      SEE 4150
*-6. XKAH-00321 [1]   C/BLOCK & PISTON KIT
K*61. XKAH-00068 [1]   PISTON ASSY
N105. XKAH-00069 [9]   PISTON
N106. XKAH-00070 [9]   SHOE
104 XKAH-00071 [1]   BLOCK-CYLINDER
107 XKAH-00072 [1]   PLATE-RETAINER
108 XKAH-00073 [1]   BALL-THRUST
110 XKAH-00074 [2]   WASHER
111 XKAH-00318 [1]   COLLAR
114 XKAH-00076 [1]   SPRING
145 XKAH-00091 [1]   RING-SNAP
151 XKAH-00077 [5]   ROLLER
102 XKAH-00081 [1]   SHAFT-MAIN
103 XKAH-00082 [1]   PLATE-SWASH
109 XKAH-00083 [1]   PLATE-TIMING
112 XKAH-00084 [1]   PISTON-PARKING
113 XKAH-00085 [12]   SPRING
115 XKAH-00086 [2]   PLATE-FRICTION
116 XKAH-00087 [2]   PLATE-MATING
K132. XKAH-00088 [1]   SEAL-OIL
K135. XKAH-00089 [1]   O-RING
K139. XKAH-00090 [1]   O-RING
149 XKAH-00092 [1]   BEARING-BALL
150 XKAH-00093 [1]   BEARING-BALL
167 XKAH-00095 [2]   PIVOT
171 XKAH-00034 [2]   PIN-PARALLEL
193 XKAH-00094 [1]   SPRING
*-7. XKAH-00078 [1]   PISTON KIT-2 SPEED
N161. XKAH-00079 [1]   PISTON-2 SPEED
N162. XKAH-00080 [1]   SHOE-2 SPEED
N. @ [AR]   NOT INDIVIDUALLY SUPPLIED
K. XKAH-00111 [1]   SEAL KIT      SEE ILLUST
Pos. Part No Qty Parts name Comments
*. 31N6-40010 [1]   TRAVEL MOTOR ASSY
*. 31N6-40011 [1]   TRAVEL MOTOR ASSY      SEE ILLUST
*. 31EM-40011 [1]   TRAVEL MOTOR ASSY      SEE 4300-4310
*. 31N6-40011 [1]   TRAVEL MOTOR ASSY      SEE ILLUST,4151
N*-1. XKAH-00373 [1]   TRAVEL MOTOR UNIT
N*-1. XKAH-00455 [1]   TRAVEL MOTOR UNIT      SEE 4300-4310
N*-1. XKAH-00373 [1]   TRAVEL MOTOR UNIT
*-8. XKAH-00096 [2]   RELIEF VALVE ASSY
*-81. XKAH-00097 [2]   RELIEF VALVE KIT
201 XKAH-00098 [2]   VALVE
202 XKAH-00099 [2]   SLEEVE
203 XKAH-00100 [2]   RETAINER-SPRING
204 XKAH-00101 [2]   PLUG
205 XKAH-00102 [2]   SHIM
206 XKAH-00103 [2]   SPRING
K208. XKAH-00104 [2]   O-RING
K209. XKAH-00105 [2]   O-RING
K210. XKAH-00035 [2]   O-RING
K211. XKAH-00106 [4]   RING-BACK UP
K217. XKAH-00107 [4]   RING-BACK UP
K219. XKAH-00108 [1]   O-RING
K220. XKAH-00109 [1]   SEAL-PISTON
*-5. XKAH-00036 [1]   REAR FLANGE ASSY
*-51. XKAH-00374 [1]   REAR FLANGE KIT
301 XKAH-00038 [1]   REAR FLANGE
323 XKAH-00039 [1]   SPOOL
324 XKAH-00041 [2]   PLUG
325 XKAH-00042 [2]   STOPPER
326 XKAH-00043 [2]   PLUG
327 XKAH-00044 [2]   VALVE-CHECK
328 XKAH-00045 [2]   SPRING
330 XKAH-00046 [2]   SPRING
K336. XKAH-00047 [2]   O-RING
K337. XKAH-00048 [2]   O-RING
341 XKAH-00065 [1]   PIN-PARALLEL
343 XKAH-00066 [12]   BOLT-SOCKET
346 XKAH-00049 [2]   PLUG-PT
352 XKAH-00050 [2]   PLUG-RO
354 XKAH-00051 [8]   PLUG-NPTF
K355. XKAH-00035 [2]   O-RING
357 XKAH-00032 [2]   PLUG-RO
K358. XKAH-00052 [2]   O-RING
K359. XKAH-00053 [2]   O-RING
363 XKAH-00054 [1]   SPOOL-2 SPEED
366 XKAH-00055 [1]   SPRING
368 XKAH-00056 [2]   BALL-STEEL
379 XKAH-00057 [1]   FILTER
380 XKAH-00058 [2]   PLUG
381 XKAH-00040 [1]   PISTON
382 XKAH-00059 [2]   PLUG
K383. XKAH-00060 [2]   O-RING
K384. XKAH-00027 [2]   O-RING
385 XKAH-00061 [2]   BALL-STEEL
397 XKAH-00062 [1]   ORIFICE
398 XKAH-00063 [4]   PLUG-PT
399 XKAH-00064 [1]   PLATE-NAME
N. @ [AR]   NOT SUPPLIED PARTS
K. XKAH-00111 [1]   SEAL KIT      SEE ILLUST
VOE14533651  EC200B EC210B CYLINDER KIT SA8230-21631
Pos. Part No Qty Parts name Comments
  VOE14533651   [1]   Travel motor
1   SA8230-21631   [1]   Cylinder
2   SA8230-28900   [9]   Piston
3   VOE14500075   [1]   Piston
4   VOE14500076   [1]   Seat
5   SA8230-28890   [1]   Block
6   SA8230-21530   [1]   Plate
7   SA8230-21540   [1]   Ball
8   SA8230-31160   [2]   Washer
9   SA8230-21560   [1]   Washer
10   SA8230-21570   [1]   Spring
11   VOE14500077   [1]   Ring
12   VOE14500078   [5]   Bearing
13   SA8230-15140   [1]   Piston
14   VOE14500079   [1]   Piston
15   VOE14500080   [1]   Seat
16   SA8230-33140   [1]   Drive shaft
17   SA8230-21520   [1]   Protecting plate
18   SA8230-21550   [1]   Protecting plate
19   SA8230-21650   [1]   Piston
20   SA8230-21660   [12]   Spring
21   SA8230-21670   [2]   Friction plate
22   SA8230-03560   [2]   Plate
23   VOE14621703   [1]   Seal
24   VOE990656   [1]   O-ring
25   VOE990660   [1]   O-ring
26   VOE14551534   [1]   Ball bearing
27   VOE14531426   [1]   Bearing
28   SA8230-21600   [2]   Support
29   SA8230-21610   [4]   Pin
30   SA8230-15150   [1]   Spring
31   VOE14535473   [1]   Spindle
32   VOE983495   [2]   O-ring
33   VOE960259   [1]   O-ring
34   SA8220-13340   [1]   Pin
35   VOE14500083   [1]   Flange
36       [1]   Flange
37       [1]   Flange
38       [1]   Spool
39       [1]   Piston
40   SA8230-02710   [2]   Plug
41   SA8230-21700   [2]   Stop
42   SA8230-03590   [2]   Plug
43   SA8230-03600   [2]   Non-return valve
44   SA8230-02760   [2]   Spring
45   SA8230-03610   [2]   Spring
46   SA8220-14930   [4]   Plug
47   VOE990607   [2]   O-ring
48   VOE983523   [2]   O-ring
49   SA8230-30410   [2]   Plug
50   VOE14573795   [2]   Plug
51   SA8220-14920   [8]   Plug
52   VOE14573793   [2]   Plug
53   SA8230-21710   [1]   Coil
54   VOE14500087   [1]   Spring
55   SA9676-38000   [2]   Ball
56   VOE14617170   [1]   Filter
57   SA8230-23140   [2]   Plug
58   SA8230-21890   [2]   Plug
59   VOE990551   [2]   O-ring
60   VOE983495   [2]   O-ring
61   VOE14500088   [2]   Ball
62   VOE983502   [2]   O-ring
63   VOE990557   [1]   O-ring
64   VOE983505   [2]   O-ring
65   VOE14535474   [1]   Orifice
66   VOE14550652   [1]   Plug
67   VOE993321   [1]   O-ring
68   VOE13968816   [12]   Allen Hd Screw
69   SA8230-21640   [2]   Relief valve
  VOE14533743   [1]   Sealing ring
100   VOE14550656   [1]   Seal
