GM35VA GM40VC TM40VC travel motor cylinder block rotor barrel

GM35VA GM40VC TM40VC travel motor cylinder block rotor barrel

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
GM35VA (￠28.0)
GM40VC TM40VC K1000681A DX225 ROTARY GROUP 1.441-00291 PISTON SHOE KIT 1.409-00231/K9001814
Hitachi EX200-2,Kato HD1250，Hyundai R220、 R265-7，Daewoo DH225-7、DH225-9
Pos. Part No Qty Parts name Comments
-. K1000681A [2]   TRAVEL DEVICE
102 1.405-00022 [1]   SHAFT;MAIN
103 1.412-00202 [1]   PLATE;SWASH
104 1.441-00292 [1]   BLOCK;CYL'D
105 1.409-00232 [9]   PISTON
106 1.355-00011 [9]   SHOE
107 1.412-00093 [1]   PLATE;RETAINER
108 1.148-00016 [1]   BALL;THRUST
109 1.412-00203 [1]   PLATE;TIMING
110 1.114-00305 [2]   WASHER
112 1.409-00115 [1]   PISTON;PARKING
113 1.131-00055 [9]   SPRING;P/PISTON
114 1.129-00019 [1]   SPRING;FOR CYL'D
115 1.412-00061 [3]   PLATE;FRICTION
116 1.412-00072 [4]   PLATE;MATING
132 1.180-00631 [1]   SEAL;OIL
139 S8002101 [1]   O-RING
145 S6510700 [1]   RING;SNAP
149 1.109-00147 [1]   BEARING;BALL
150 1.109-00026 [1]   BEARING;BALL
151 1.109-00135 [6]   ROLLER
161 1.409-00116 [1]   PISTON
162 1.355-00012 [1]   SHOE
163 1.131-00042 [1]   SPRING
167 1.540-00006 [2]   PIVOT
178 S8011951 [1]   O-RING
181 S5701242 [2]   PIN
201 *NA00460 [1]   . FLANGE;REAR
218 1.427-00029 [1]   VALVE;SEAT T-TYPE
219 1.420-00009 [1]   VALVE;T-TYPE
220 1.131-00041 [1]   SPRING;T-TYPE
221 2181-1890D4 [1]   PLUG
222 1.115-00139 [1]   . RING;T-TYPE
223 1.424-00062 [1]   SPOOL;MAIN
224 1.181-00059 [2]   PLUG;FOR MAIN
226 1.181-00067 [2]   PLUG;CHECK
227 1.420-00013 [2]   VALVE;CHECK
228 1.131-00058 [2]   SPRING;FOR MAIN
230 1.129-00006 [2]   SPRING;CHECK
233 S8000091 [1]   O-RING
234 S8002731 [2]   O-RING
238 S8000181 [1]   O-RING
241 S5700891 [2]   PIN;PARALLEL
242 1.420-00014 [1]   VALVE;REDUCING
244 2181-1116D1 [1]   PLUG
252 2181-1116D2 [4]   PLUG
263 422-00031 [1]   VALVE;TWO SPEED
264 K9001047 [1]   PLUG
265 S8000111 [1]   O-RING
266 1.131-00099 [1]   . SPRING;TWO SPEED
268 S6250161 [2]   . BALL;STEEL
272 1.427-00031 [1]   SEAT;VALVE REDUCING
275 1.131-00062 [1]   SPRING;REDUCING V/V
276 1.115-00141 [1]   RING;REDUCING
279 S8000321 [2]   O-RING
282 S2221471 [9]   BOLT,SOCKET
294 1.416-00027 [1]   STOPPER
295 1.424-00063 [1]   SPOOL;MAIN
296 1.129-00018 [1]   SPRING
297 1.114-00542 [1]   WASHER
297 1.415-00005 [1]   ORIFICE
298 S6550100 [1]   RING;SNAP
301 1.429-00037 [1]   SEAT
302 1.424-00064 [1]   PLUNGER
303 1.424-00065 [1]   ROD
304 1.409-00233 [1]   PISTON
305 1.441-00295 [1]   BODY
306 1.181-00154 [1]   PLUG
307 1.129-00020 [1]   SPRING
308 1.114-00543 [1]   SHIM
309 S8000181 [1]   O-RING
310 S8000181 [1]   O-RING
311 S8060181 [1]   . RING;BACKUP
900 2401-9082K [1]   SEAL KIT
M. 1.401-00011 [1]   MOTOR PART
M1. 1.441-00291 [1]   KIT;CYL'D BLOCK & PISTON
M11. 1.409-00231 [1]   PISTON ASS'Y
M2. K9001814 [1]   PISTON ASS'Y
R-1. 1.426-00024 [2]   RELIEF VALVE ASS'Y
RL. K9001812 [1]   REAR FLANGE ASS'Y
RL1. K9001813 [1]   KIT;REAR FLANGE
RL2. 1.416-00026 [2]   STOPPER ASS'Y
