DOOSAN SOLAR 420LC-V EXCAVATOR TRAVEL REDUCTION GEAR 1001-1051

DOOSAN SOLAR 420LC-V EXCAVATOR TRAVEL REDUCTION GEAR 1001-1051

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group SOLAR 420LC-V:
Pos. Part No Qty Parts name Comments
-. 2401-6357A [1]   TRAVEL DEVICE
-. 401-00005A [1]   REDUCTION GEAR;TRAVEL
1 2403-7007 [1]   COVER
10 2101-7028A [1]   SUN GEAR 2
11 2230-7024A [1]   CARRIER 2
12 2217-7009A [4]   PIN;CARRIER 2
13 2109-7045 [4]   BEARING;NEEDLE
14 2101-7029 [4]   PLANETARY 2
15 2123-7055A [4]   PIN;SPRING
16 2114-7114 [8]   WASHER;THRUST
17 2104-7010A [1]   RING GEAR
18 2402-7007 [1]   HOUSING
19 2109-7046 [2]   BEARING
2 2230-7023A [1]   CARRIER 1
20 114-00002 [1]   SHIM
21 2114-7115 [2]   WASHER;LOCK
22 2411-7004 [1]   RING;SUPPORT
23 2180-7134 [1]   SEAL;FLOATING
24 S2212261 [24]   SOCKET-HEAD BOLT
25 S2225661 [24]   BOLT;SOCKET M10X100
26 120-00001 [2]   SCREW;CAP TAPER
3 2217-7008A [3]   PIN;CARRIER 1
4 2109-7044 [3]   BEARING;NEEDLE
5 2114-7113 [6]   WASHER;THRUST
6 2101-7026 [3]   PLANETARY 1
7 2123-7056A [3]   PIN;SPRING
71 K9001037 [1]   KIT;HOUSING (18,25)
8 2412-7006 [1]   PLATE;THRUST
9 2101-7027A [1]   SUN GEAR 1
