DOOSAN SOLAR 420LC-V EXCAVATOR SWING REDUCTION GEAR

DOOSAN SOLAR 420LC-V EXCAVATOR SWING REDUCTION GEAR

$5,500.00 USD
$5,500.00 USD
特價 售罄
結帳時計算運費。
Parts on group SOLAR 420LC-V:SWING REDUCTION GEAR 1001-1021
Pos. Part No Qty Parts name Comments
-. 2401-9290A [1]   GEAR;REDUCTION   404-00095
1 DS-32-01 [1]   SHAFT
10 DS-925-10 [1]   GEAR;SUN NO.1
11 DS-925-11 [4]   GEAR;PLANETARY NO.1
12 DS-32-12 [4]   PLATE;SIDE NO.1
13 DS-32-13 [4]   PIN ASS'Y
14 DS-32-14 [1]   GEAR;RING
15 DS-32-15 [1]   PLATE;THRUST
16 DS-32-16 [1]   COVER
17 DS-32-17 [4]   PIN;LOCK
18 DS-32-18 [1]   SPACER
19 DS-32-19 [1]   COLLAR
2 DS-32-02 [1]   CASE;GEAR
20 DS-32-20 [1]   PLATE
21 DS-32-21 [1]   RING;LOCK
22 DS-32-22 [1]   BEARING;SPHERICAL ROLLER
23 DS-32-23 [1]   BEARING;SPHERICAL ROLLER
24 DS-32-24 [1]   SEAL;OIL
25 DS-32-25 [4]   PIN;SPRING
26 DS-32-26 [1]   PLUG
27 DS-32-27 [2]   PLUG
28 DS-32-28 [1]   PLUG
29 DS-32-29 [16]   BOLT;SOCKET M16X180
3 DS-32-03 [1]   CARRIER NO.2
30 DS-32-30 [1]   PIPE
31 DS-32-31 [1]   BAR;LEVEL
32 DS-32-32 [4]   BOLT;SOCKET M16X40
33 DS-925-00-01 [1]   CARRIER NO.1 ASS'Y
34 DS-925-00-02 [1]   CARRIER NO.2 ASS'Y
4 DS-32-04 [1]   GEAR;SUN NO.2
5 DS-32-05 [4]   GEAR;PLANETARY NO.2
6 DS-32-06 [4]   PLATE;SIDE NO.2
7 DS-32-07 [4]   SHAFT FOR PIN NO.2
8 DS-32-08 [4]   BUSH NO.2
9 DS-925-09 [1]   CARRIER NO.1
Parts on group SOLAR 420LC-V: SWING REDUCTION GEAR 1022-
Pos. Part No Qty Parts name Comments
-. 404-00095 [1]   GEAR;REDUCTION   404-00095A
-. 404-00095A [1]   SWING REDUCTION GEAR   404-00095B
-. 404-00095B [1]   SWING REDUCTION GEAR   130426-00015
-. 130426-00015 [1]   130426-00015A
-. 130426-00015A [1]
1 105-00011 [1]   SHAFT   105-00011A
1 105-00011A [1]   SHAFT
10 104-00043 [1]   GEAR;SUN NO.1
11 104-00041 [4]   GEAR;PLANETARY NO.1
11 130413-00042 [4]
12 223-00044 [4]   PLATE;SIDE NO.1
12 250111-00371 [8]
13 123-00457 [4]   PIN ASS'Y   120501-00457
13 120501-00457 [4]
13 1.216-00017 [4]   CAGE,NEEDLE
14 104-00040 [1]   GEAR;RING
15 223-00045 [1]   PLATE;THRUST
16 621-02348 [1]   COVER   110508-17490
16 110508-17490 [1]
17 705-00008 [4]   PIN;LOCK
18 114-00543 [1]   SPACER
19 114-00544 [1]   COLLAR
2 423-00172 [1]   CASE;GEAR
20 159-00233 [1]   PLATE
21 278-00090 [1]   RING;LOCK
22 109-00168 [1]   BEARING;SPHERICAL ROLLER
23 109-00169 [1]   BEARING;SPHERICAL ROLLER
24 180-00444 [1]   SEAL;OIL   180-00472
24 180-00472 [1]   SEAL;OIL
25 S5741361 [4]   PIN;SPRING
26 S5810030 [1]   PLUG
27 S5810010 [2]   PLUG
28 S5810050 [1]   PLUG
29 120-00294 [16]   BOLT;SOCKET M16X180
3 230-00056 [1]   CARRIER NO.2   230-00056A
3 230-00056A [1]   CARRIER NO.2
30 140-01343 [1]   PIPE   140-01343A
30 140-01343A [1]   PIPE
31 119-00020 [1]   BAR;LEVEL
32 120-00293 [4]   BOLT;SOCKET M16X40
33 223-00046 [4]   PLATE;SIDE NO.3   250122-00098
33 250122-00098 [4]
33 140201-00074 [4]
34 S6500400 [4]   RING,RETAINING
35 230-00068 [1]   CARRIER NO.1 ASS'Y   230-00068A
35 230-00068A [1]   100502-00255
35 100502-00255 [1]
36 230-00065 [1]   CARRIER NO.2 ASS'Y
38 250201-02835 [1]
39 120-00144 [4]   BOLT
4 104-00039 [1]   GEAR;SUN NO.2
5 104-00037 [4]   GEAR;PLANETARY NO.2
6 223-00043 [4]   PLATE;SIDE NO.2
7 123-00459 [4]   SHAFT FOR PIN NO.2
8 110-00228 [4]   BUSH NO.2
9 230-00058 [1]   CARRIER NO.1   100502-00074
9 100502-00074 [1]
9 100502-00253 [1]
